Page 1 V11S Moto Cam User Manual...
Page 2 Google Play Store before use. The Wi-Fi password is 12345678.  By default, Wi-Fi is ON for 3 minutes when the camera is powered on. If it doesn’t connect to the MUFU Video app within 3 minutes, the camera will disable Wi-Fi automatically to save...
Page 3 power. To turn on again Wi-Fi, simply power the camera OFF then ON again. NOTE: An active Wi-Fi connection will affect total recording time.  When the main unit connects USB cable for charging, the main unit will power on automatically and turn on Wi-Fi. It’s workable to connect app for setting camera or checking recorded files.
Page 4  The warranty doesn’t cover damages resulting from alteration, adjustment or repair by unauthorized person. Prohibition of co-location This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. WEEE Notice Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in private households in the European Union This symbol on the product or on the packaging indicates...
Page 5 Due to local laws and for your own safety, DO NOT operate the camera while riding.  Use MUFU Video to app to synchronize your date and time before first use.  The firmware function in the camera is for reference only, riders are advised to exercise discretion based on actual road conditions.
Page 6  Improper use or operation of the product may result in damage to the camera or its accessories and void the warranty.  This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. ...
Page 7 “Switch Off 2-way Radios” sign by switching off camcorders that may interfere with the radio frequency.  MUFU is NOT responsible for the loss of any data/content during operation. By using the product, it is assumed that you agree to...
Page 8: What's Inside
1. What’s Inside The package contains the following items. If any items are missing or damaged, please contact the original place of purchase immediately. Camera Main Unit USB Cable (Main Unit) Mount (type C) User Manual Warranty...
Page 9: Product Overview
2. Product Overview Description Description Reset USB type C port microSD slot Microphone Lens Bracket LED Indicator...
Page 10: Led Indicator
3. LED Indicator Indicator LED Status Description Blue, slow flashing Recording Camera power on, Blue, solid not recording Recording Blue, rapid flashing Emergency recording Red, solid Charging No Red light Fully charged Charging Green, rapid flashing Low battery Green, solid Full charged Battery Connect computer to...
Page 11: Beep Sound
4. Beep Sound Main Unit Description Beep~ (continuous 5 seconds) No card or card error Repeat every 30 seconds Total alert 3 times Beep 3 sounds Power on and start recording Beep~ (continuous 3 seconds) Low battery and beep 3 sounds (about 10 minutes to power off) total alert 2 times Power off because of low battery...
Page 12: Insert Microsd Card
5. Insert microSD Card Insert the microSD memory card with the pins facing forward. (See below for proper installation orientation.) Once the memory card locks into place, replace the slot cover securely over the slot.
Page 13 The slot cover must be tightly sealed to prevent moisture from entering, causing the lens to fog. Insert the left edge of the slot cover, and then press the right edge of the slot cover to create a good seal. See below.
Page 14: Download The App
6. Download the App When using the camera for the first time, use your smartphone to download and install the MUFU Video app. Scan the QR code or search “MUFU Video” in the iOS App Store or Google Play Store. Android App layout and features may be changed subject to different software versions.
Page 15: Power On And Off
7. Power On and Off Following is the way to power on/off the camera.  Buckle Detection Buckle the camera into the main unit mount, the camera will automatically power on and start recording. Remove the camera from the main unit mount, the camera will power off automatically.
Page 16 Note: 1. When the camera is buckled into the main unit mount, it will automatically power on and start recording, indicated by a slow-flashing Blue LED light. The recording file will be saved onto the microSD card. When the card reaches capacity, the loop recording function will overwrite the oldest file to make room for new files and continue recording.
Page 17 When secured into the main unit mount, the camera and its Wi-Fi will automatically power on. If the camera doesn’t connect with the MUFU Video app within 3 minutes, Wi-Fi will be disabled automatically to preserve battery life. If you want...
Page 18 9. Install & Uninstall 9.1 Install  Buckle the camera into main unit mount. Blue indicator lights up.   buckled camera and mount on the top of helmet. Temporarily fix it in order to adjust the best view angle.
Page 19  Make sure your phone is connected with MUFU_V11S_xxxxxx via Wi-Fi, and open the MUFU Video app to check preview image. Move right or left, forward or backward the mount to obtain the best recording image angle.  After the recording angle is confirmed, pull down the camera and the main unit mount from helmet.
Page 20 fixing. And then buckle the camera on the main unit mount and start using. 9.2 Uninstall Press the lock on right side of the main unit mount, push the camera to left side to remove it.
Page 21 10. Calibrate and Format After adjusting your viewing angle, tap in the MUFU Video app to enter [Camera Setting]. On first use, be sure to calibrate the “Tilt Sensor” and “Format” the microSD card.  Calibrate the Tilt Sensor Hold your motorcycle upright, straight, and as still as possible.
Page 22 Note: 1. DO NOT remove or insert memory card when the camera is in power-on status. This may cause memory card damage or data loss. 2. Memory cards have a service life. Long-term use may lead to write speed degradation and file save failure. If this happens, it is recommended that you purchase a new memory card.
Page 23: Change Password
11. Change Password To change the Wi-Fi password, follow the steps below. If leave it unchanged, the default password is 12345678.  Open MUFU Video app , and tap to enter [Camera Setting], Next, tap [Wi-Fi Password Setting]. → Enter your new password.
Page 24 “Forget This Network” and confirm your decision. *Note: Android phone user can skip this step.  Next, tap the V11S network again to re-enter your new password and reconnect your smartphone to the MUFU Video. Note: Be sure to remember your new password. If you forget...
Page 25: App Operation
12. App Operation  Main Screen...
Page 26 圖示敘述 MUFU logo / microSD card message Preview image Switch front and rear preview image Rotate 180°preview image Full screen preview Start / Stop recording Take snapshot Camera Files (review recorded files in V11S’s microSD) Camera Setting...
Page 27 Note: 1. The MUFU Video App will auto sync the camera's date/time with your smartphone. 2. App layout and features are subject to change, depending on the software version. Refer to the Google Play Store or iOS App Store for...
Page 28 Tap the icon [Camera File] to enter file playback list. Recording will stop. The files save in the V11S’ microSD card will be listing on your smartphone. There are three folders, Loop, Snapshot and Locked. Tap the preview thumbnail to...
Page 29 Tap the right top corner “Select” and pick up the files that you want to delete or download and tap below icon to execute. Icon Description Download the file to smartphone.
Page 30 3. The snapshot is activated by app. The image file will be stored both in microSD card in the camera and “Album” folder of MUFU Video app. The file will be marked as “Downloaded” on preview thumbnail. 4. If you plan to download a large number of videos and photos, we...
Page 31  Album Use this feature to playback or delete the file that you download to your smartphone. The file can be opened and reviewed without Wi-Fi connection to the camera. Tap the icon [Album] below the home page. The camera will stop recording if it’s connected with app.
Page 32 Tap the file from preview thumbnail to playback, delete or edit.
Page 33 “Save to smartphone's album successfully.” and smartphone’s album will automatically create a folder named “MUFU Video”. Delete the file downloaded in App’s Album. The file in the microSD card in the camera is still existed.
Page 34  Camera Setting Use this feature to set up your preferred options. Tap icon [Camera Setting] on main screen. The camera will stop recording. See available settings below and adjust to your preferred options. Menu Description Options When pick up the helmet with camera mounted, the camera will automatically power on Vibration...
Page 35 Format the memory card in the Format camera. This will delete all Yes / No contents permanently. Set the Wi-Fi activation Wi-Fi Turn-on Always on / 3min duration. *Active Wi-Fi will Time decrease total recording hours Watermark includes brand, Watermark model, car speed, longitude On / Off and latitude, and date/time.
Page 36: Final Check
13. Final Check □ Peel off lens protective films □ Fully charge the camera □ Tilt sensor calibration done □ Format microSD card done □ MicroSD card slot cover is closed tightly □ The main unit mount is fixed tightly...
Page 37: Specifications
Specifications Item Description Image Sensor 2MP CMOS sensor Effective Pixels 1920 (H) x 1080 (V) Storage Media Suggest V30 or higher microSD card, up to 128GB Wide angle fixed focus waterproof lens Lens Aperture ： up to F/1.8 Resolution ： 1080P/ 30 fps Video File Format ：...
Page 38 Item Description Storage -20° ~ 70° C Temperature Size 45.0 x 72.1 x 30.0 mm Weight Approximately 88g Built-in IEEE 802.11g/n (HT20) Wi-Fi chip: RTL8188FTV Wi-Fi Frequency 2412~2462MHz Wi-Fi Channel Ch1~Ch11...
Page 39: Optional Accessories
Optional Accessories Contact distributor to purchase additional accessories for the camera. GoPro Type Rear-view Helmet Mount Mount Mirror Mount License Plate Moto/Car Mount Mount...
Page 40 DIY quick installation Hall sensor detection, buckle and record. Dedicated app for preview and playback. Built-in 2000mAh battery Tilt Sensor detects if the motorcycle has toppled over and automatically locks the recording. Camera IP66 Waterproof...
