VariDesk
Premier Electric Single-Monitor and Dual-Monitor
®
COMPONENTS
BASE
x1
POWER CORD
x1
DESKTOP
x1
KEYBOARD TRAY
COLUMN
x1
x1
KEYBOARD
TRAY
BRACKET
M4 THUMB
x2
SCREW
x4
V1.1. Patent and trademark information: vari.com/patents | ©2024 Varidesk, LLC All rights reserved.
M6 x 8
M6 x 12
SCREW
SCREW
x4
x16
M6 X 14
M6 X 25
SCREW
SCREW
x4
x4
SINGLE MONITOR
BRACKET
x1
DESKTOP
MOUNT
x1
2.5MM ALLEN KEY
x1
4MM ALLEN KEY
x1
NOTE: If you purchased the VariDesk®Premier Electric Dual-Monitor, the Dual-Monitor
Mounting Bracket and components below will ship and arrive in a separate box.
4MM ALLEN KEY
x1
MONITOR BRACKET
x1
M6 x 12
M4 THUMB
SCREW
SCREW
x4
x4
Weight Capacities
Desktop = 55 lbs (25 kg)
Keyboard Tray = 11 lbs (5 kg)
Single-Monitor = 20 lbs (9 kg)
One Person
Assembly
DUAL-MONITOR
MOUNTING BRACKET
x1
M6 THUMB
SCREW
x4
Max Monitor Screen Size = 24"
Dual-Monitor = 20 lbs (9 kg)
per Monitor Mount
Advertisement
Summary of Contents for Vari VariDesk 402616
- Page 1 Max Monitor Screen Size = 24” Keyboard Tray = 11 lbs (5 kg) Dual-Monitor = 20 lbs (9 kg) Single-Monitor = 20 lbs (9 kg) per Monitor Mount V1.1. Patent and trademark information: vari.com/patents | ©2024 Varidesk, LLC All rights reserved.
- Page 2 *Note: We recommend assembling the desktop converter on a smooth, debris-free, flat surface to prevent scratches. STEP 1: 1. Remove all items from the box. 2. Place the BASE and DESKTOP side by side, and then flip the BASE over to access the control box and cords. 3.
- Page 3 STEP 2: 1. Insert the COLUMN into the BASE. 2. Insert (4) M6 x 14 SCREWS into the screw holes. 3. Secure them using the provided 4MM ALLEN KEY. 4. Connect the COLUMN CABLE to the M1 PORT of the CONTROL BOX. 5.
- Page 4 STEP 4: STEP 3: 1. Plug the converter in. 1. Flip the assembled BASE upright. 2. Press the UP button on the Control Panel to raise the COLUMN to the desired height for installing the DESKTOP. 2. Align the DESKTOP MOUNT with the COLUMN screw holes. 3.
- Page 5 STEP 5: 1. Carefully place the DESKTOP onto the COLUMN until it contacts the DESKTOP MOUNT. 2. Insert (4) M6 x 25 SCREWS into the DESKTOP MOUNT. 3. Secure the DESKTOP in place with the 4MM ALLEN KEY.
- Page 6 STEP 6: 1. Place the SINGLE MONITOR BRACKET on top of the COLUMN and align the screw holes. 2. Insert (4) M6 x 12 SCREWS into the BRACKET. 3. Secure it to the COLUMN using the 4MM ALLEN KEY.
- Page 7 Note: If you purchased the VariDesk® Premier Electric Dual-Monitor, follow the steps below to install the Dual-Monitor Mounting Bracket. STEP 6a: 1. Place the DUAL-MONITOR MOUNTING BRACKET on top of the COLUMN and align the screw holes. 2. Insert (4) M6 x 12 SCREWS into the BRACKET. 3.
- Page 8 STEP 8: 1. Place the KEYBOARD TRAY on top of the KEYBOARD TRAY BRACKETS and align the screw holes. 2. Insert (3) M6 x 12 SCREWS into each BRACKET, for a total of (6). 3. Secure the KEYBOARD TRAY in place using the provided 4MM ALLEN KEY. STEP 7: 1.
- Page 9 Use caution when lowering desk. conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. (800) 207-2587 Patent and trademark information: vari.com/patents | ©2024 Varidesk, LLC All rights reserved.
- Page 10 Over current protection feature triggered, over current always caused by over loading. Remove items or reduce weight from Over Current concentrated area (rated loading is average distribution). Follow the reset instruction to reset the system. If error persists, contact Vari. Protection E07 will display if the cable connected to the M1 port is not fully secured.
