PV1200 12" SCREEN

SOFTWARE GUIDE

–––

CXO300 – designed for purpose

coxmarine.com

Table of Contents

Need help?

Do you have a question about the PV1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for COX PV1200

Page 1 PV1200 12” SCREEN SOFTWARE GUIDE ––– CXO300 – designed for purpose coxmarine.com...
Page 2: Table Of Contents
TABLE OF CONTENTS INSTALLATION SCREEN STARTUP WARNING HOME SCREEN GAUGES SCREEN ERRORS NOTIFICATION ALARMS SCREEN OPTIONS SCREEN ENGINE POSITION AND SOURCE ADDRESS CAN REFERENCE LATEST UPDATES...
Page 3: Installation Screen
 Figure : Selectable Item Action table Installation Screen – Select Language screen  NOTE Currently the only option in the table is English (UK). In the future Cox intends to offer support for more languages. PV1200 12” SCREEN SOFTWARE GUIDE...
Page 4 Sets the engine number at 5 engines. 6 engines icon Sets the engine number at 6 engines. Continue button Confirms the engine number selected.  Figure : Selectable Item Action table Installation Screen – Select Engine Number screen PV1200 12” SCREEN SOFTWARE GUIDE 1.0 INSTALLATION SCREEN...
Page 5 Minute setting arrows - fast through the values. Set time button Confirms the time and date setting and saves it to internal memory.  Figure : Selectable Item Action table Installation Screen – Time Setting screen PV1200 12” SCREEN SOFTWARE GUIDE 1.0 INSTALLATION SCREEN...
Page 6: Startup Warning
 Figure : Startup Warning screen Selectable Items Action Accept button Accepts the risks and continues to show the Home screen.  Figure : Selectable Item Action table Startup Warning screen PV1200 12” SCREEN SOFTWARE GUIDE 2.0 STARTUP WARNING...
Page 7: Home Screen
Once the Startup Warning has been has been accepted, the Home screen is shown. 3.1.1 The user is displayed the basic engine and fuel information. 3.1.2  Figure : Default Home screen Light  Figure : Default Home screen Dark PV1200 12” SCREEN SOFTWARE GUIDE 3.0 HOME SCREEN...
Page 8  Figure : Info-graphic Description table Home screen  NOTE Some of the data shown on this screen is dependent on external devices to those offered by COX PT e.g., Vessel speed. If this information is not readily available on the CAN bus, the graphic is not shown.
Page 9 PGN 129025  Figure : Additional Data External PGN requirement table  Figure : Default Home screen – with External PGNs Light  Figure : Default Home screen – with External PGNs Dark PV1200 12” SCREEN SOFTWARE GUIDE 3.0 HOME SCREEN...
Page 10 Service required on outboards. warning. Battery warning. Glow plugs active. Oil pressure warning. Fuel filter warning. Oil temperature warning. Emmissions warning. Water in fuel warning.  Figure : Info-graphic Description table Home screen Warning lamps PV1200 12” SCREEN SOFTWARE GUIDE 3.0 HOME SCREEN...
Page 11: Gauges Screen
 NOTE There are two ways to view this information, the data can be viewed for all engines at once or displayed for Individual engines at a time as in Section 4.2. PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 12 Shows the current system time. Heading Shows the current system heading if available. Vessel speed Shows the current vessel speed if available.  Figure : Info-graphic Description table Gauges screen - All Engines PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 13 Single Engine is shown. The user is displayed more detailed information for Single engines. 4.2.2  Figure : Gauges Screen - Single Engine Light  Figure : Gauges Screen - Single Engine Dark PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 14 Shows the current system time. Heading Shows the current system heading if available. Vessel speed Shows the current vessel speed if available.  Figure : Info-graphic Description table Gauges Screen - Single Engine PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 15 The user is displayed additional Trip Computer control buttons and detailed Trip Computer 4.3.2 information.  Figure : Gauges Screen - Trip Computer Light  Figure : Gauges Screen - Trip Computer Dark PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 16 Shows the current system time. Heading Shows the current system heading if available. Vessel speed Shows the current vessel speed if available.  Figure : Info-graphic Description table Gauges Screen - Trip Computer PV1200 12” SCREEN SOFTWARE GUIDE 4.0 GAUGES SCREEN...
Page 17: Errors Notification
 Figure : Errors Notification –Non-Critical screen Light  Figure : Errors Notification –Non-Critical screen Dark Selectable Items Action Error notification Dismisses the error.  Figure : Selectable Item Action table Errors Notification –Non-Critical screen PV1200 12” SCREEN SOFTWARE GUIDE 5.0 ERRORS NOTIFICATION...
Page 18 Accepts the restriction placed on the outboard and dismisses the error message. Accept restriction  Figure : Selectable Item Action table Errors Notification –Semi-Critical screen PV1200 12” SCREEN SOFTWARE GUIDE 5.0 ERRORS NOTIFICATION...
Page 19 The user is displayed the Home Screen with highlighting. 5.3.2  Figure : Errors notification –Semi-Critical –Home screen highlighting Light  Figure : Errors notification –Semi-Critical –Home screen highlighting Dark PV1200 12” SCREEN SOFTWARE GUIDE 5.0 ERRORS NOTIFICATION...
Page 20  Figure : Errors notification –Critical screen Light  Figure : Errors notification –Critical screen Dark Selectable Items Action Close window button Closes the error notification window.  Figure : Selectable Item Action table Errors notification –Critical screen PV1200 12” SCREEN SOFTWARE GUIDE 5.0 ERRORS NOTIFICATION...
Page 21 The user is displayed the Home Screen with highlighting. 5.5.2  Figure : Errors notification –Critical –Home screen highlighting Light  Figure : Errors notification –Critical –Home screen highlighting Dark PV1200 12” SCREEN SOFTWARE GUIDE 5.0 ERRORS NOTIFICATION...
Page 22: Alarms Screen
The timestamp the error was received. „ The time the error has been active. „ The error codes. „ A description of the error. „  Figure : Alarms screen Light  Figure : Alarms screen Dark PV1200 12” SCREEN SOFTWARE GUIDE 6.0 ALARMS SCREEN...
Page 23 If the error is a semi-critical error, the button to try and clear the restriction will be shown.  Figure : Alarms Screen – Clear Restrictions button Light  Figure : Alarms Screen – Clear Restrictions button Dark PV1200 12” SCREEN SOFTWARE GUIDE 6.0 ALARMS SCREEN...
Page 24 Clear restriction button. This will display feedback messages to the user as to the progress and success of the request.  Figure : Selectable Item Action table Alarms Screen – Clear Restrictions button PV1200 12” SCREEN SOFTWARE GUIDE 6.0 ALARMS SCREEN...
Page 25: Options Screen
The user is displayed the Options screen. 7.1.2  Figure : Options screen – Upper Light  Figure : Options screen – Lower Light PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 26 Shows the current system time. Top bar - Heading Shows the current system heading if available. Top bar - Vessel speed Shows the current vessel speed if available.  Figure : Info-graphic Description table Options screen PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 27 Takes user to alarms page. Options navigation button No function. Up arrow Scrolls Up through the options table. Down arrow No function.  Figure : Selectable Items Action table Options screen – Lower PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 28 The user can confirm the time and date setting by pressing the ‘Set time’ button. The user is displayed the Options Screen – Time Setting screen. 7.2.2  Figure : Options screen – Time Setting Light  Figure : Options Screen – Time Setting Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 29 Takes user to the gauges page. Alarms navigation button Takes user to alarms page. Options navigation button Takes user to the options page.  Figure : Selectable Item Action table Options Screen – Time Setting PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 30 Shows the current system time Heading Shows the current system heading if available Vessel speed Shows the current vessel speed if available  Figure : Info-graphic Description table Options screen– Select Language screen PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 31 Scrolls Up through the table Down arrow Scrolls Down through the table Return arrow Returns the user to the options page  Figure : Selectable Item Action table Options Screen – Select Language screen PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 32 The current version of the SW that the GDU is running is listed on this page in the bottom GDU SW version right-hand corner of the screen.  Figure : Info-graphic Description table Options screen – Engine Details PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 33 Takes user to alarms page. Options navigation button Takes user to the options page. Return arrow Returns the user to the options page.  Figure : Selectable Item Action table Options screen – Engine Details PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 34 The user is displayed the Options screen – Change Number of Engines screen. 7.5.2  Figure : Options screen – Change Number of Engines Light  Figure : Options screen – Change Number of Engines Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 35 Sets the engine number at 6 engines. Continue button Confirms the engine number selected. Return arrow Returns the user to the options page.  Figure : Selectable Item Action table Options screen – Change Number of Engines PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 36 7.0 OPTIONS SCREEN 7.6 OPTIONS SCREEN – FUEL TANK CALIBRATION The PV1200 GDU has 3 analogue inputs which COX PT intend to use for fuel gauge senders. These 7.6.1 fuel gauge senders have standard resistance levels but can be installed in a wide variety of fuel tanks.
Page 37  Figure : Options screen – Fuel tank calibration main menu screen Resistive Fuel senders Dark  Figure : Options screen – Fuel tank calibration main menu screen CAN bus data Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 38 The user is displayed the Fuel tank calibration main menu screen. 7.6.10 PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 39 7.0 OPTIONS SCREEN  Figure : Options screen – Fuel Tank calibration main screen Sensor Input Light  Figure : Options screen – Fuel Tank calibration main screen Sensor Input Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 40 7.0 OPTIONS SCREEN  Figure : Options screen – Fuel Tank calibration main screen Manual Light  Figure : Options screen – Fuel Tank calibration main screen Manual Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 41 Deﬁnes the tank source instance to use for the NMEA transmission. Return arrow Returns the user to the Fuel Tank Calibration Main Menu.  Figure : Selectable Item Action table Options screen – Fuel tank calibration main menu screen Resistive Fuel senders PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 42 Takes user to the Fuel Tank Calibration Main Menu. Recalibrate button Returns the user to the calibration screen for further editing.  Figure : Selectable Item Action table Options screen – Calibrated notification screen PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 43 Shows the current system time. Heading Shows the current system heading if available. Vessel speed Shows the current vessel speed if available.  Figure : Info-graphic Description table Options screen – Select Brightness PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 44 Increases the brightness level of the screen. Continue button Saves the brightness level of the screen and returns the user to the main menu.  Figure : Selectable Item Action table Options screen – Select Brightness PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 45 The user can define if the gauges are shown if the data is available or permanently hidden. The user is displayed the Options screen – Gauge Options screen. 7.8.2  Figure : Options screen – Gauge Options Light  Figure : Options screen – Gauge Options Dark PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 46 The user can define if the Outboard fuel use on the gauges page gauge is displayed or Outboard fuel use hidden. Return arrow Returns the user to the Fuel Tank Calibration Main Menu.  Figure : Selectable Item Action table Options screen – Gauge Options PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 47  Figure : Options screen – Device List Dark Selectable Items Action Return button Takes user back to the Options page  Figure : Selectable Item Action table Options screen – Device List PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 48 <11.5V for 10s 0.75 <0.5 bar Oil pressure 101.5 10.87 72.51 <7.25 PSI <50kPA Deg C >80 Deg C Engine temp Deg F 136.4  Figure : Options screen – Gauge Limits PV1200 12” SCREEN SOFTWARE GUIDE 7.0 OPTIONS SCREEN...
Page 49: Engine Position And Source Address
4 up install Instance SA Engines 1 2 3 3 up install Instance SA Engines 1 2 2 up install Instance SA  Figure : Engine Position and Source Address Table PV1200 12” SCREEN SOFTWARE GUIDE 8.0 ENGINE POSITION AND SOURCE ADDRESS...
Page 50: Can Reference
Water depth, transducer Water depth Position, Rapid Update 129025 Longitude GPS position longitude Position, Rapid Update 129025 Latitude GPS position latitude System Time 126992 Time Time  Figure : CAN Reference Table PV1200 12” SCREEN SOFTWARE GUIDE 9.0 CAN REFERENCE...
Page 51: Latest Updates
Error Logs can be viewed „ Error logs can be exported „ Cox operator menu added 10.2.8 Error logs can be deleted „ Reset to reset all the faults can be made to an outboard. „ PV1200 12” SCREEN SOFTWARE GUIDE 10.0 LATEST UPDATES...
Page 52 Unit options is now broken into a dedicated page 10.3.3 10.4 Fixes Fixed a bug on the homepage which would cause the water depth to be displayed incorrectly, and 10.4.1 overlap with the location data PV1200 12” SCREEN SOFTWARE GUIDE 10.0 LATEST UPDATES...
