1. PRODUCT GENERAL INFORMATION...........................................................2
1.1. Product Description.................................................................................................2
1.2. Product Feature......................................................................................................2
1.3. Product Application......................................................................................................2
2. PRODUCT GENERAL................................................................................3
2.1.
General Specifications...................................................................................... 3
2.2. LED Indicator.....................................................................................................3
2.3. Interface............................................................................................................3
3. PRODUCT HARDWARE SPECIFICATION......................................................3
3.1. RF Specification.........................................................................................................3
3.1.1. General........................................................................................................3
3.1.2. Transmitter...................................................................................................3
3.1.3. Receiver.....................................................................................................4
3.1.4. Antenna Type................................................................................................4
3.1.5. Typical Operating Range.................................................................................4
3.2. H/W Specification.....................................................................................................4
3.2.1. MAC Controller..............................................................................................4
3.2.2. Memory........................................................................................................4
3.2.3. Power..........................................................................................................4
4. PRODUCT SOFTWARE SPECIFICATION.......................................................4
4.1. Driver......................................................................................................................4
4.2. Configuration Utility..................................................................................................4
5. PRODUCT COMPLIANCE...........................................................................5
6. OPERATING CONDITION......................................................................5
6.1. Drop and Vibration test...................................................................................5
6.1.1. Anti-Static Voltage...........................................................................................5
6.1.2. Vibration Test................................................................................................5
6.1.3. Package Drop Test..........................................................................................5
6.2. Operation Environment ..............................................................................................5
6.2.1. Temperature Range........................................................................................5
6 . 2 . 2 . R e l i a b i l i t y Te s t ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . ... ... ... ... ... . 5
6.2.3. Humidity........................................................................................................5
7. INSTALLATION AND CONFIGURATION......................................................6
7 . 1 . I n s t a l l a t i o n ... ... ... ... . ... ... ... ... ... ... ... ... ... ... ... ... . ... ... ... ... ... ... ... ... ... ... ... . . . ... ... ... . 6
7.2. Configuration.......................................................................................................6
CONTENTS
1
Advertisement
Table of Contents
Related Manuals for Global Sun GL242201-MT
Summary of Contents for Global Sun GL242201-MT
- Page 1 CONTENTS 1. PRODUCT GENERAL INFORMATION..……………………………………………..….2 1.1. Product Description…………………………………………………………………………………….2 1.2. Product Feature…………………………………………...……………………………………………2 1.3. Product Application………………………………………………………….……………………………..2 2. PRODUCT GENERAL………………………………………………………………….….3 2.1. General Specifications………………………….………………..…………………………..… 3 2.2. LED Indicator………………………………………………………..…………..….………………3 2.3. Interface………………………………………………………….…….………………………..…..3 3. PRODUCT HARDWARE SPECIFICATION……………………….………………….….3 3.1. RF Specification…………………………………………………….………….….…………………..….3 3.1.1. General……………………………………………………….………………..………………..3 3.1.2. Transmitter…………………………………………………….…………..……………………3 3.1.3. Receiver…………………………………………………………………..……………………4 3.1.4. Antenna Type………………………………………………….…………..…………………...4 3.1.5.
-
Page 2: Product General Information
WLAN PC Card 1. Product General Information 1.1. Product Description GL242201, the wireless Ethernet adapter for Card bus- compliant notebook PCs, is fully compatible with IEEE 802.11b standard and supporting higher data rate to 22Mbps. Using Direct Sequence spread spectrum technology for immunity from interference, it will automatically fallback to lower data rate in the environment of interference. -
Page 3: Product General
2. PRODUCT GENERAL 2.1. General Specifications Standards: IEEE802.11b Compliant PC Card standard Ver 7.0 Data Rate: 22Mbps / 11Mbps / 5.5 Mbps / 2Mbps / 1 Mbps auto fallback Security: 64/128/256 bit Wired Equivalent Privacy (WEP) Dimension: 128 x 54 x 5.0 mm (Non-detachable card) 2.2. - Page 4 3.1.3 Receiver Sensitivity -80 dBm (Typically @25 +5 ) 3.1.4 Antenna Type Antenna Type Built in diversity patch antenna Antenna Gain 2 dBi max. 3.1.5. Typical Operation Range 22Mbps 100M 11Mbps 150M 5.5Mbps 250M 2Mbps 300M 1Mbps 350M 3.2 Hardware Specification 3.2.1 MAC controller TI ACX100 3.2.2 Memory...
-
Page 5: Regulation Compliance
Link Quality Receiving AP link quality on infrastructure networking mode Signal Strength Receiving AP signal strength on infrastructure networking mode 5. REGULATION COMPLIANCE Compliant with FCC Part 15 Class B and C ETSI EN 300 328-2 and ETSI EN 301 489-1, -17, EN60950, CE-Mark Telec (Japan, Customized) WiFi Compliant 6. -
Page 6: Installation And Configuration
Storage 0% to 95% Non-condensing 7. INSTALLATION AND CONFIGURATION 7.1. Installation 1. Start the computer 2. Insert the PC CARD to the slot of computer 3. Run ”E:\ Wlan PC Card\Utility\Setup.exe”. Windows will automatically start Installshield Wizard and then insert the PC CARD into the slot of the computer. - Page 7 4.Click the “Configuration”. The Configuration page will appear. Enter your wireless network’s SSID, select the BSS Type, suggest you use default “Infrastructure”, Then click “Apply”. 5. Click the “Security”. From the security setting screen, you can set the Wired Equivalent Privacy (WEP) encryption by checking the “Data Encryption”. Then change the “Key Format”...
- Page 8 If you have an access point and enable the security function, please follow the access point “Network Key”. 6.Click “SiteSurvey”. Select one of SSID from “Available Network” Block. Then click “Connect” button to enter Profile page. 7. You can set all parameters or click “OK” to back to previous page. If you click “OK” directly, then you finish the connect action.
- Page 9 8.Click “About”. It will show you Software Version of this Wireless Lan PC Card. Notice : Our company reserves the right to change specifications detailed in this document at any time without notice, and assumes no responsibility for any errors within this document.
- Page 10 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if t not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
