9. Attach the adjustable swivel bracket to loudspeaker requirements. 10. Attach the loudspeaker to the wall mounting bracket 3. Accountability: AtlasIED will not be held liable for any damages resulting 11. Connect loudspeaker wire to loudspeaker and attach weatherproof from incorrect installation procedures.
Page 3
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE TOOLS REQUI RED / PACKAGE CO N T EN TS AS Series Surface Mount Loudspeakers: Included Contents / Required Tools INCLUDED PART QTY PER LOUDSPEAKER Grommet assembly front cover / plate Grommet assembly back cover...
Page 4
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 1 - SE PARAT E SWIVE L B RAC K ET FRO M M OUN TI NG PL AT E Firmly press the release button at the bottom of the mounting plate then pull away the swivel bracket (Figure 1).
Page 5
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 2 - REMOVE THE LO UDSPEA KE R CON NECTOR COVE R A ND R UBB ER GR O M ME T Using a Phillips screwdriver, remove the four (4) screws covering the grommet plate to remove both the grommet plate and rubber grommet (Figure 2).
Page 6
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 3 - AT TAC H MOUN T I N G PL AT E TO WA L L A N D R U N WI R ES T HR O UGH Mount the bracket to the wall using fasteners appropriate for the wall material and loudspeaker weight (Figure 3). Ensure proper fasteners are used.
Page 7
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 4 - DRIL L LOUDSPE AK E R WI RE HO L ES T H R OU GH R U BB ER G R O M ME T ( OPTIO N A L) Required for weatherproofing in outdoor installations: On the grommet, determine which pilot hole locations will be used to feed wire through.
Page 8
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 5 - PUL L WI RE S T H RO UG H T H E MO U NT ING PL AT E A SS EM B LY Pull loudspeaker wires from inside the wall through the hole in both the wall mounting plate and grommet plate (Figure 6) Secure grommet plate to mounting plate using the four (4) screws removed in step 2.
Page 9
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 6 - PUL L TH E WI RE S T H RO UGH WEAT HER PR O O F LO U DS PE A KE R GR O MM E T ASSE MBLY ( OPTI O N AL) Required for weatherproofing in outdoor installations: Pull the loudspeaker wires through the weatherproof loudspeaker grommet assembly.
Page 10
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 7 - CONNECT T H E LO U DSPE AK ER WIR E TO E UR O B LO C K CO NNECTO R Strip off an appropriate amount of insulation from each wire and insert the wire into the correct pin opening on the Euroblock connector. Use a small flat head screwdriver to tighten the corresponding screw to secure the wire (Figure 9).
Page 11
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 8 - SET TRAN SFO RME R WAT TAGE TA P Determine the proper wattage setting and slide the transformer tap switch to the desired value (Figure 11). Note: 70.7V tap settings shown on top in black, and the 100V settings shown on bottom in white. The 8Ω bypass setting is the left-most setting.
Page 12
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 9 -AT TACH T HE ADJU STAB LE S WIVEL BRACKE T TO LO UD SPE A KE R Place the flat end of the swivel bracket onto the matching VESA connector on the back of the loudspeaker. Use the UP arrow printed on the swivel bracket to properly align the bracket and connector.
Page 13
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 10 - AT TAC H TH E LO UD SPE AK ER TO T HE WA L L M O UNT ING B R AC KET Carefully align swivel bracket to the mounting plate and press firmly until you hear an audible click (Figure 13).
Page 14
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 11 - CONN ECT LOU DSPE AK E R WIRE TO LO UD SPEA KER A N D ( O PT IO NA L LY ) AT TAC H WE AT HE R PROO F GRO MM E T A SSEM BLY ( O PT IO NA L )
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 12 - ADJUST TH E AN G LE O F T H E LO U DSPEA KER Tilt the loudspeaker to different angles by using the angle adjustment notches provided on both parts of the swivel bracket (up / down; left / right). Partially loosen, but do not fully remove the screws shown in the figures below using a 5/32”...
Page 16
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 13 - ENSURE “ SE RVI CE LOO P ” IN PL ACE TO PR EVEN T WATE R DA MAGE ( O PTIO N A L) Required for weatherproofing in outdoor installations: Ensure that one point of the loudspeaker wire (“service / drip loop”) is below the point where the wire is fed through the mounting plate.
Page 17
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 14 - ROTATE LOGO B ADGE FO R HO R IZO NTA L I NSTA L L AT IO NS If the loudspeaker is installed in the horizontal orientation, the logo should be rotated 90 degrees (Figure 17).
Page 18
AS Series UNIVERSAL SWIVEL MOUNT INSTALLATION GUIDE STEP 15 - DRIVE LOC KI N G SC REW T HR O UGH TH E S WIVEL BR AC KET A ND I NTO WA LL BRAC KE T Drive the locking screw through the swivel bracket and wall bracket using a 90-degree Allen wrench, then tighten (Figure 18).
Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. AtlasIED will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
