Page 1 ClonerAlliance Screen-Cloner Dongle User Manual...
Page 2: Copyright Notice
ClonerAlliance Screen-Cloner Dongle User Manual This documentation describes how to use ClonerAlliance Screen-Cloner Dongle (Model: CA-1280SC) device. Copyright Notice Copyright © ClonerAlliance Inc. All rights reserved. Documentation Version 1.0.0 No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise, without the prior written permission of ClonerAlliance Inc.
Page 3: Safety Notices
Before using ClonerAlliance Screen-Cloner Dongle, please ensure that you read and understand the safety precautions below: 1. Do not attempt to open the case of ClonerAlliance Screen-Cloner Dongle or modify it in any way, as this will void the warranty.
Page 5: Table Of Contents
CONTENTS Introduction Product Overview ................1 Package Contents .
Page 6 System Requirements Minimum System Requirements ..............26 Supported Operating Systems and Ports.
Page 7: Introduction
INTRODUCTION 1.1 Product Overview The ClonerAlliance Screen-Cloner Dongle (Model: CA-1280SC) is a hardware screen recording tool designed for personal computers. It ensures long-term, stable recording of the entire desktop with 1080p@60fps quality. The dongle can record any content displayed on the desktop, including system internal audio, with seamless audio-video synchronization.
Page 8: Package Contents
ClonerAlliance Screen-Cloner Dongle User Manual 1.2 Package Contents The ClonerAlliance Screen-Cloner Dongle package includes: • a. Screen-Cloner Dongle • c. User Manual • b. Type-C (female) to USB-A + DP adapter 1.2. Package Contents...
Page 9: Product Diagram
ClonerAlliance Screen-Cloner Dongle User Manual 1.3 Product Diagram • 1. Type-C plug: Connect to the type-c port with Thun- • 3. Front heat dissipation holes: Do not cover this when derbolt. the device is working. • 2. LED indicator: When it lights up, it indicates the •...
Page 10: Getting Started
GETTING STARTED 2.1 Hardware Setup • Connecting via Type-C Port (Thunderbolt Supported) 1. Connect the ClonerAlliance Screen-Cloner Dongle to a Type-C port on your computer. 2. Ensure the Type-C port supports Thunderbolt. Fig. 1: Connecting via Type-C Port...
Page 11 If your computer’s Type-C port does not support Thunderbolt, use the provided USB-A + DP Adapter included in the package. • Connecting via USB-A + DP Adapter 1. Connect the Type-C (female) end of the adapter to the ClonerAlliance Screen-Cloner Dongle. 2.1. Hardware Setup...
Page 12: Software Installation
ClonerAlliance Screen-Cloner Dongle User Manual 2. Connect the USB-A and DP ends of the adapter to the respective ports on your computer. 2.2 Software Installation • Installing on Windows 1. Insert the Screen-Cloner Dongle into your computer. 2. A new external drive will appear. Open this drive.
Page 13: Open The Application
ClonerAlliance Screen-Cloner Dongle User Manual 2.3 Open the Application Launch the Screen-Cloner Application from your desktop or start menu. 2.4 Configure Settings • Go to the “Preferences”. • Select the desired video resolution (default is 1080p). • Choose the audio source (System Internal Audio, Microphone, or Mixed).
Page 14: Start Recording
ClonerAlliance Screen-Cloner Dongle User Manual • Set any additional preferences (e.g., file size limit, scheduled recording). 2.5 Start Recording • Click the “Start Recording”button or use the shortcut key (Ctrl + Shift + 0) to begin recording your screen. • The application will capture everything displayed on your desktop along with the selected audio sources.
Page 15: Stop Recording
ClonerAlliance Screen-Cloner Dongle User Manual 2.6 Stop Recording • Click the “Stop Recording”button or use the shortcut key (Ctrl + Shift + 0) to end the recording. • The recorded file will be saved automatically in the designated folder. 2.6. Stop Recording...
Page 16: Review And Edit
ClonerAlliance Screen-Cloner Dongle User Manual 2.7 Review and Edit • Open the saved recording from the designated folder. • Use the included MP4-Cloner software to edit and burn the recorded files if needed. 2.7. Review and Edit...
Page 17: Product Features
PRODUCT FEATURES 3.1 Screen Recording • Recording Desktop Video, Games, Online Meetings, and Courses Windows OS 1. Open ClonerAlliance Screen-Cloner Application. 2. Click the “Start Recording”button or use the designated hotkey to start recording.
Page 18 ClonerAlliance Screen-Cloner Dongle User Manual 3. Click the “Stop Recording”button or use the designated hotkey to stop recording. Mac OS 1. Open ClonerAlliance Screen-Cloner Application. 2. Click the “Start Recording”button or use the designated hotkey to start recording. 3.1. Screen Recording...
Page 19 ClonerAlliance Screen-Cloner Dongle User Manual 3. Click the “Stop Recording”button or use the designated hotkey to stop recording. 3.1. Screen Recording...
Page 20: Audio Recording
ClonerAlliance Screen-Cloner Dongle User Manual 3.2 Audio Recording Windows OS 1. Open ClonerAlliance Screen-Cloner Application. 2. Go to Preferences->Device Settings->Audio device options 3. Select the desired audio input (system audio, microphone, or audio input device). 3.2. Audio Recording...
Page 21 ClonerAlliance Screen-Cloner Dongle User Manual Mac OS In the Mac system, it is not possible to directly record system sound and virtual sound devices need to be installed to achieve system sound recording. 1. When starting the software for the first time, it will prompt you to install a third-party virtual sound device.
Page 22 ClonerAlliance Screen-Cloner Dongle User Manual 3.2. Audio Recording...
Page 23: Using The Virtual Sound Card
ClonerAlliance Screen-Cloner Dongle User Manual 3.3 Using the Virtual Sound Card • The Screen-Cloner Application supports recording via a virtual sound card. • Set up the virtual sound card and configure it as the audio source in the application settings.
Page 24: Operating Instructions
OPERATING INSTRUCTIONS 4.1 Using Shortcut Keys • To start recording: Press Ctrl + Shift + 0 • To stop recording: Press Ctrl + Shift + 0 You can customize these shortcut keys in the Screen-Cloner Application settings.
Page 25: Scheduled Recording Setup
ClonerAlliance Screen-Cloner Dongle User Manual 4.2 Scheduled Recording Setup 1. Open the Screen-Cloner Application. 2. Go to the Preferences->Schedule. 3. Set the start and stop time for the recording. 4.2. Scheduled Recording Setup...
Page 26: Multi-Monitor Recording
ClonerAlliance Screen-Cloner Dongle User Manual 4. It will active scheduled recording task when exit the schedule setup menu. 4.3 Multi-Monitor Recording When there are multiple monitors connected to your computer. 4.3. Multi-Monitor Recording...
Page 27: Customizing Recording File Size
ClonerAlliance Screen-Cloner Dongle User Manual 1. Go to Windows “System settings->Displays”, choose the monitor you want to record and set it clone with Screen- Cloner . 2. Start recording. 4.4 Customizing Recording File Size 1. Open the Screen-Cloner Application. 2. Go to “Preferences”and select “Record”.
Page 28: Software Updates And Registration
ClonerAlliance Screen-Cloner Dongle User Manual 4.5 Software Updates and Registration • The Screen-Cloner Application checks for updates each time it starts. • Users are prompted to download and install new versions manually. • No registration is required when using the Screen-Cloner Dongle with the application.
Page 29: Firmware Updates
ClonerAlliance Screen-Cloner Dongle User Manual 4.6 Firmware Updates 1. Open the Screen-Cloner Application. 2. Go to Preferences->About. 4.6. Firmware Updates...
Page 30 ClonerAlliance Screen-Cloner Dongle User Manual 3. Click “Update Firmware” ，choose the firmware file and start to update. 4.6. Firmware Updates...
Page 31 ClonerAlliance Screen-Cloner Dongle User Manual 4. Once the firmware update is complete, reinsert the Screen-Cloner Dongle. 4.6. Firmware Updates...
Page 32: System Requirements
SYSTEM REQUIREMENTS 5.1 Minimum System Requirements • OS: Windows 7 or later, Mac OS 10.15 or later • CPU: Intel i3 or higher • Memory: 4GB RAM or higher • Hard Disk: 512MB free hard disk space for installation • Ports: USB-C with Thunderbolt, or USB-A 2.0 + DP •...
Page 33: Frequently Asked Questions (Faq)
FREQUENTLY ASKED QUESTIONS (FAQ) 6.1 Windows OS Troubleshooting “Please set display mode to Duplicate”Message If you see this message, set the display mode to “Duplicate”: 1. Press Windows + P.
Page 34 ClonerAlliance Screen-Cloner Dongle User Manual 2. Select “Duplicate”from the display menu. “Check if the USB-C port supports Thunderbolt with Displayport Alt mode”Message If you see this message, check if the USB-C port supports Thunderbolt with DisplayPort Alt mode: 1. Ensure the USB-C port is Thunderbolt capable.
Page 35: Mac Os Troubleshooting
ClonerAlliance Screen-Cloner Dongle User Manual 6.2 Mac OS Troubleshooting “Use Screen-Cloner as a Mirror display”Message If you see this message, set Screen-Cloner as a mirror display: 1. Press Command + Shift + P. 2. Alternatively, go to Apple menu > Preferences > Displays.
Page 36 ClonerAlliance Screen-Cloner Dongle User Manual 3. Select “Screen-Cloner”and use as “Mirror for …”. Use Screen-Cloner as a Mirror Display “Please check the USB-C port”Message If you see this message, check if the USB-C port supports Thunderbolt 3 or 4: 1. Use a Thunderbolt 3 or 4 (USB-C) port.
Page 37: Common Device Errors
• Ensure all connections are secure and the ports are functioning. • Update the Screen-Cloner Application to the latest version. 6.4 Mobile Device Screen Recording Support Currently, the ClonerAlliance Screen-Cloner Dongle does not support mobile device screen recording. Mobile application development is in progress. 6.5 Setting Up Audio Source Recording •...
Page 38 ClonerAlliance Screen-Cloner Dongle User Manual 3. Select the desired audio input (system audio, microphone, or audio input device). • Mac OS In the Mac system, it is not possible to directly record system sound and virtual sound devices need to be installed to achieve system sound recording.
Page 39 ClonerAlliance Screen-Cloner Dongle User Manual 2. After the software starts, it will adjust the system’s default sound output device. 3. In the software, it is necessary to ensure that sound monitoring has been turned on, otherwise no sound can be heard.
Page 40: Advanced Settings
ADVANCED SETTINGS 7.1 Configuring Multi-Monitor Environments 1. Connect all monitors to the computer. 2. Connect the Screen-Cloner Dongle device to the computer. 3. Go to the system display settings and set the monitor you want to record and the Screen-Cloner Dongle as duplicate mode.
Page 41: Selecting And Mixing Audio Sources
ClonerAlliance Screen-Cloner Dongle User Manual 7.2 Selecting and Mixing Audio Sources • Windows OS 1. Open ClonerAlliance Screen-Cloner Application. 2. Go to Preferences->Device Settings->Audio device options 7.2. Selecting and Mixing Audio Sources...
Page 42 ClonerAlliance Screen-Cloner Dongle User Manual 3. Select the desired audio input (system audio, microphone, or audio input device). • Mac OS In the Mac system, it is not possible to directly record system sound and virtual sound devices need to be installed to achieve system sound recording.
Page 43 ClonerAlliance Screen-Cloner Dongle User Manual 2. After the software starts, it will adjust the system’s default sound output device. 3. In the software, it is necessary to ensure that sound monitoring has been turned on, otherwise no sound can be heard.
Page 44: Product Specifications
PRODUCT SPECIFICATIONS 8.1 Specifications • Model: CA-1280SC • Dimensions: 90mm x 30mm x 10mm • Weight: 50g • Interface: - Type-C (Thunderbolt 3/4 supported) - USB-A 2.0 + DP (via included adapter) • Power Supply: USB-powered • Video Resolution: 1080p (1920x1080) •...
Page 45: After Sales Warranty
AFTER SALES WARRANTY ClonerAlliance Inc. provides 90-Day No Hassle Return(No Additional Fee) and 2-Year Replacement Warranty Service for all hardware. Please rest assured to use ClonerAl- liance products.
Page 46: Contact Us
CONTACT US If you encounter any problem when using our products, please contact us by support@cloner-alliance.com or call 1-844-9-CLONER (toll-free) and we will serve you with utmost satisfaction. We’ll offer a satisfying discount on batch purchase and affiliate program. If you are interested, please contact us by marketing@cloner-alliance.com.
Page 47: Disclaimer
DISCLAIMER HDMI is a registered trademark of HDMI Licensing, LLC. USB is a registered trade- mark of USB Implementers Forum. HDMI and USB are registered trademarks of their respective companies. ClonerAlliance Inc. is not affiliated with those companies.
