DanEI-300 Electronic Inclinometer
Operation and Service Manual
Document No. DanEI-300 UM1
Revision 1.6
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DanEI-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Daniamant DanEI-300

  • Page 1 DanEI-300 Electronic Inclinometer Operation and Service Manual Document No. DanEI-300 UM1 Revision 1.6...

  • Page 2: Revision History

    Revision History Revision Date Description Initials 14 SEP 2012 Initial release. Revised for software update. Added description of the 15 FEB 2013 digital interface. 3 MAY 2013 New features: Ethernet interface and slave display. 21 JUN 2013 New feature: trend plots. 14 OCT 2013 Revised for software update.

  • Page 3: Table Of Contents

    Contents 1. Introduction....................1 1.1. DanEI-300 Overview ................1 1.2. System Composition ................1 1.2.1. Sensor Unit ..................1 1.2.2. Display Unit ..................2 1.2.3. Multiple Displays................. 2 2. Operating Instructions ................3 2.1. Switching ON/OFF ................3 2.2. Operation Panel ..................3 2.3.
  • Page 4 3.1. General Instructions ................13 3.2. Mounting the Display Unit ..............13 3.2.1. Flush Mounting ................. 13 3.2.2. Desktop, Wall or Roof Mounting ............14 3.2.3. Embedded Wall Mounting ..............14 3.3. Mounting the Sensor Unit ..............15 3.3.1. Orientation and Alignment ..............15 3.3.2.

  • Page 5: Introduction

    1.2. System Composition The standard configuration of DanEI-300 Electronic Inclinometer comprises of a Sensor Unit and a Display Unit. Figure 1 shows the standard configuration of the DanEI-300. 24V DC Power Supply HRM, ALC, ALF, HBT...

  • Page 6: Display Unit

    DanEI-300 Electronic Inclinometer Daniamant Electronics The heel angle and pitch angle data is calculated by an advanced sensor fusion and motion processing algorithm using the raw data from both the accelerometer and gyroscope. This enables reliable estimation of the ship’s attitude in the presence of various linear and rotational movements, and thus ensures the accuracy of measurement under any possible situation that the ship may encounter.

  • Page 7: Operating Instructions

    2. Operating Instructions 2.1. Switching ON/OFF The DanEI-300 Electronic Inclinometer has a power switch on the back side of the Display Unit. By turning on the switch, both the Display Unit and the Sensor Unit will be powered To shut down the inclinometer, turn the switch to OFF position.

  • Page 8: Screen Display

    2.3. Screen Display Figure 4 shows the main screen of DanEI-300 graphical user interface. Numeric Display of Power Supply Status Heel Angle Pitch Angle E I-1 E lectronic Inclinometer - v1.6 R oll Period Pitch Angle Display Roll Period Display +0.9 °...

  • Page 9: Heel Angle

    DanEI-300 Electronic Inclinometer Daniamant Electronics The following readings are available on the main screen: 2.3.1. Heel Angle Instantaneous heel angle is displayed in two different forms: ◾ Numeric display Heel angle is indicated by the numeric display at the center of the screen and is refreshed every 0.1 second.

  • Page 10: Roll Amplitude

    Power supply status is indicated on the top of the screen. When the main power supply is in normal condition, the text “POWER OK” will be displayed. Otherwise, if the main power supply fails, the DanEI-300 Electronic Inclinometer will operate on the emergency power supply and the text “MAIN POWER FAILURE” will be displayed.

  • Page 11: Alerts

    DanEI-300 Electronic Inclinometer Daniamant Electronics ◾ Brightness level The current brightness level is shown on the lower left corner of the screen. Refer to section 2.6.4 for more information about brightness adjustment. ◾ Running Indication A rotating line is shown on the lower left corner of the screen as a running indication. It shall be always rotating as long as the display unit is running properly.

  • Page 12: Sensor Failure Warning

    Sensor Failure Warning will not be generated unless the Display Unit fails to receive valid sensor data for more than 5 seconds. NOTICE 2.4.4. Power Failure Warning When the main power supply fails, the DanEI-300 Electronic Inclinometer will operate on DanEI-300 UM1 v1.6...

  • Page 13: Warnings On The Slave Display Unit

    This warning can be acknowledged locally. 2.5. Trend Plots The DanEI-300 Electronic Inclinometer provides the following trend plots: ◾ Heel angle, for the last 3 minutes; ◾ Roll amplitude to port and to starboard, for the last 30 minutes.

  • Page 14: Settings And Adjustments

    DanEI-300 Electronic Inclinometer Daniamant Electronics Press ALARM/ACK. key to return to the main screen. 2.6. Settings and Adjustments 2.6.1. Settings Menu Settings menu can be accessed by pressing MENU/ENTER key twice from the main screen, or by pressing MENU/ENTER key once from the trend plots.

  • Page 15: Heel Angle Warning Settings

    2.6.3. Language Setting The user interface of DANEI-300 is available in multiple languages. To change the language setting, move the cursor to the desired language option and press MENU/ENTER key.

  • Page 16: Settings For Slave Display Unit

    DanEI-300 Electronic Inclinometer Daniamant Electronics 2.7. Settings for Slave Display Unit Figure 12 shows the settings menu on Slave Display Unit. E I-1 E lectronic Inclinometer - S lave Display Network C onfiguration IP Address 172 . 016 . 000 . 002 S ubnet Mask 255.255.0.0...

  • Page 17: Installation Instructions

    DanEI-300 Electronic Inclinometer Daniamant Electronics 3. Installation Instructions 3.1. General Instructions In general, the following instructions should be applied: ◾ In order to get best performance and longest life, it is recommended to install the equipment in air-conditioned rooms to keep its operating temperature neither too low nor too high.

  • Page 18: Desktop, Wall Or Roof Mounting

    DanEI-300 Electronic Inclinometer Daniamant Electronics Figure 13: Flush Mounting 3.2.2. Desktop, Wall or Roof Mounting When equipped with the EI1U01K01 mounting kit, the Display Unit can be installed on the desktop, wall or roof, as shown in Figure 14. Mounting Procedure ◾...

  • Page 19: Mounting The Sensor Unit

    DanEI-300 Electronic Inclinometer Daniamant Electronics a thick wall, as shown in Figure 15. Mounting Procedure ◾ Prepare a cutout at the place of installation to embed the Display Unit; ◾ Mount the Display Unit onto the plate using six M3 flat head screws;...

  • Page 20: Mounting Kit

    ◾ Connect the wires to the ship’s 24V DC main and emergency power supply, or to terminal blocks and then to the ship’s 24V DC main and emergency power supply using additional cable; ◾ If possible, ground the shielding of the cable. 3.4.2. Data Connection DanEI-300 provides IEC 61162-1/-2 and Ethernet interfaces. DanEI-300 UM1 v1.6...

  • Page 21: Sensor Unit

    DanEI-300 Electronic Inclinometer Daniamant Electronics To connect the IEC 61162-1/-2 talker output and listener input signals to VDR, INS and other devices: ◾ Get the “Serial Interface” cable from the cable kit; ◾ Insert and fasten the plug at one end of the cable into the 6-pin circular connector receptacle on the Display Unit;...

  • Page 22: Finalizing The Installation

    DanEI-300 Electronic Inclinometer Daniamant Electronics 3.5. Finalizing the Installation After the mechanical and electrical installation is finished, the following tasks need to be performed to finalize the installation. 3.5.1. Initialization and General Examination Turn on the power switch and perform the following tasks: ◾...

  • Page 23: Alignment Error Correction

    DanEI-300 Electronic Inclinometer Daniamant Electronics simultaneously. The operating of the service menu is similar to the user menu. Figure 18 shows the screen display of the service menu. E I-1 E lectronic Inclinometer -S ervice Menu Alignment E rror C orrection Heel anglecorrection value 0.2 °...
  • Page 24 DanEI-300 Electronic Inclinometer Daniamant Electronics The Ethernet configuration menu will be shown when enabling the Ethernet interface in the service menu. Figure 19 shows the screen display of the Ethernet configuration menu. E I-1 E lectronic Inclinometer - Ethernet Interface...

  • Page 25: Appendix A. List Of Installation Drawings

    EI1U01MD01 DanEI-300 Display Unit Outline Drawing EI1U01MD02 DanEI-300 Display Unit Flush Mounting EI1U01MD03 DanEI-300 Display Unit Desktop Mounting EI1U01MD04 DanEI-300 Display Unit Embedded Wall Mounting EI1U02MD01 DanEI-300 Sensor Unit Outline Drawing EI1U02MD02 DanEI-300 Sensor Unit Installation Drawing DanEI-300 UM1 v1.6...

  • Page 26: Appendix B. Iec 61162 -1 And -2 Digital Interface

    DanEI-300 Electronic Inclinometer Daniamant Electronics Appendix B. IEC 61162 -1 and -2 Digital Interface B.1. General Specifications IEC 61162-1 Ed.4 (2010) Compliant with IEC 61162-2 Ed.1 (1998) Talkers Listeners Talker Identifier Talker: HRM, ALF, ALC, HBT Supported Sentences Listener: ACN, HBT...
  • Page 27 DanEI-300 Electronic Inclinometer Daniamant Electronics HRM Sentence Examples Sentence $ICHRM,-2.2,11.1,3.3,4.4,A,,,,,*00 Information Heel angle: 2.2 degrees, to port Roll period: 11.1 seconds Roll amplitude to port: 3.3 degrees Roll amplitude to starboard: 4.4 degrees Data is valid Sentence $ICHRM,-2.2,11.1,3.3,4.4,V,,,,,*17 Information Data is temporarily out of date...
  • Page 28 IRT , ,x.x *hh<CR><LF> Additional alert entries. Alert entry 1. For DanEI-300, the number of alert entries can be 0, 1, 2 or 3. ALC Sentence Examples Sentence $ICALC,1,1,1,0*45 Information Number of alert entries: 0, i.e. all alerts are in normal state...
  • Page 29 The blank field of release time is also accepted by DANEI-300. ◾ HBT – Acknowledge alarm DanEI-300 receives the HBT sentence from INS. If an alert is in responsibility transferred state but DANEI-300 does not receive HBT sentence within a minute, it will automatically set the alert to active –...

  • Page 30: Appendix C. Iec 61162-450 Digital Interface

    (refer to B.2 for detail) (refer to C.3 for detail) The DanEI-300 Master Display Unit transmits HRM, ALF, ALC and HBT sentences to VDRD Transmission Group. The source identification (s) and line-count parameter (n) are used in the TAG block of the transmitted UDP datagrams.
  • Page 31 DanEI-300 Electronic Inclinometer Daniamant Electronics This sentence is used to transmit necessary information from Master Display Unit to Slave Display Unit, with a constant update rate of 10 Hz. $PIRTEID, x.x ,x.x x.x , a,a,a *hh<CR><LF> Audible signal, A=active, V=inactive...
  • Page 32 DanEI-300 Electronic Inclinometer Daniamant Electronics This page is with purpose left blank for making user notes. § DanEI-300 UM1 v1.6...
