HERO S13966 User Manual

User Manual
Hero Medical Collapsible
Shower Chair
SKU
Overall Depth
Seat Width
Arm Width
Seat Height
Armrest Height
Weight
Safe Work Load (SWL)
Independent Living Specialists
S13966
55cm
44cm
47.5cm
41-55cm
20cm
3.6kg
115kg
1
Safety & Precautions
User Safety: It is recommended that the below safety checks are completed
prior to each use:
• All locking pins must be fully protruding.
• Adjusted to appropriate height for user.
• Legs are in a secure position with anti-slip rubber tips attached.
• Weight on chair does not exceed safe work load.
Weight Capacity: the maximum safety weight limit for the product is 205kg.
If the maximum safety weight limit is exceeded, this can increase the risk of
damage to the product and/or risk of serious injury to the user and others.
Instructions for Use
Product Assembly
1. Remove contents from packaging.
2. Slide side frame components onto seat frame
3. Pressing down on the locking pin, slide receiving component into the
main frame. Ensure locking pin is secured and protruding.
4. Attach all four legs by sliding leg component into main frame receiver
until the locking pin is secured and protruding at the appropriate height
for the user.
5. Ensure legs are stable and secure.
Adjusting the Height
1. Push locking pin in and slide internal leg up or down to the appropriate
height. Ensure all locking pins are fully protruding prior to use.
2. Please note that one leg has additional holes, to assist with stabilising
product on uneven floors.
