Summary of Contents for PowerSonic POWERSTEADY 400
- Page 1 POWERSTEADY USER MANUAL 400/600/800/1000/1200/1500/2000/2400/3000 www.power-sonic.com...
-
Page 2: Safety Warning
SAFETY-WARNING • This UPS utilizes voltages that may be hazardous. Do not attempt to disassemble the unit. The unit contains no user serviceable parts. Only factory service personnel may perform repairs. • Internal battery voltage is 12Vdc. Sealed, lead-acid, 6 cells battery. •... - Page 3 • During the installation of this equipment it should be assured that the sum of the leakage currents of the UPS and the connected loads does not exceed 3.5mA. • Attention, hazardous through electric shock. Also with disconnection of this unit from the mains, hazardous voltage still may be accessible through supply from battery.
- Page 4 Packing contents The packaging includes the following items; The PowerSteady UPS • Serial cable • USB cable • Detachable power cable, EU and UK plug • Power cable IEC • Manual • Software download card • Working Principle AC mode When UPS is in normal working mode, AC goes through the filter and the harmful waves are filtered.
-
Page 5: Output Voltage
Display 1. Input voltage 2. Output voltage 3. AC mode (UPS in AVR mode, this LCD symbol flashes) 4. Battery mode (when AC input voltage is abnormal, this LCD symbol lights) 5. Battery level (Battery capability) 6. Low battery (when battery voltage is low, this LCD symbol flashes) 7. - Page 6 Installing the PowerSteady Install the UPS unit in any protected environment that provides adequate airflow around the unit, and is free from excessive dust, corrosive fumes and conductive contaminants. Do not operate your UPS in an environment where the ambient temperature or humidity is high. We advise to place the UPS away from the monitor at least 20cm to avoid interference.
- Page 7 UPSilon 2000 software The PowerSteady is supplied with UPSilon 2000 software. This software package enables you to view the status of the UPS and change multiple settings. During a long lasting power failure the software will correctly shut down your computer before the battery of the UPS is drained. Installing the software 1.
-
Page 8: Warning Message
UPSilon 2000 options and settings When starting UPSilon 2000 four tabs will appear. These tabs allow you to change the status view. You can choose, amongst others, between voltage meters (Meter) or graphs (Chart). In the status screen itself you can view items such as Input/Output voltage, temperature, battery status and power consumption. - Page 9 ACPI The option ‘ACPI’ (Advanced Configuration and Power Interface) provide the possibility to change the UPS Name/Manufacturer/Date of installation. And also provide a self-test function. Tasks The menu ‘Tasks’ allows you to plan when UPSilon 2000 will turn on the UPS or turn off both the computer and the UPS.
-
Page 10: Troubleshooting
TROUBLE SHOOTING Symptom Possible Cause Remedy 1. Battery weak. 1. Charge battery up to 8 hours. No LED display on the front panel. 2. Battery defect. 2. Replace with the same type of battery. 3. Power switch is not pressed. 3. -
Page 11: Specification
SPECIFICATION PowerSteady PowerSteady PowerSteady 1500 1000 PowerSteady MODEL PowerSteady PowerSteady PowerSteady 2000 1200 400VA 1500VA 1000VA CAPACITY 600VA 2000VA 1200VA 800VA Voltage 110VAC/120VAC or 220VAC/230VAC/240VAC INPUT Voltage Range 81-145VAC or 162-290VAC Voltage Regulation +/-10% (Batt. Mode) Frequency 50Hz or 60Hz OUTPUT Frequency Regulation +/-1 Hz... - Page 12 SPECIFICATION MODEL PowerSteady 2400 PowerSteady 3000 CAPACITY 2400VA 3000VA Voltage 110VAC/120VAC or 220VAC/230VAC/240VAC INPUT Voltage Range 81-145VAC or 162-290VAC Voltage Regulation +/-10% (Batt. Mode) Frequency 50Hz or 60Hz OUTPUT Frequency Regulation +/-1 Hz (Batt. Mode) Output Waveform Modified Sine wave Battery Type 12V/7.0AH x 4 12V/9.0AH x 4...
