Product and Recommended Application
1. Delivery Contents List:
- 1 x 680w LED Bar Fixture
- 1 x LED Driver Box
- 1 Set of 1/8 Hanging Kits
- 1 Set of Hooks
- 1 x Power Cord, 1 x Network Cable
- 1xInstruction Manual
Please keep the instruction manual and desist from throwing it away. It might come in handy with future
trouble shooting.
Instruction Manual
Model No.
OCL SKWID PRO
Product Size
1120*1100*105mm
True Power
680W
Application
Indoor Growing
Recommend
30-90cm
Height
Advertisement
Table of Contents
Summary of Contents for OCL SKWID PRO
- Page 1 Instruction Manual Product and Recommended Application Model No. OCL SKWID PRO Product Size 1120*1100*105mm True Power 680W Application Indoor Growing Recommend 30-90cm Height 1. Delivery Contents List: - 1 x 680w LED Bar Fixture - 1 x LED Driver Box...
-
Page 2: Product Structure
2. Product Structure: LED Driver Box AC Input Rod to Place LED Driver Box LED Bar Lights Signal Out Signal In Manual Dimming System, Compatible with OCL Controller When Dim to EXT... -
Page 3: Product Data Sheet
112*110*10.5cm Package Dimension 1170*130*615mm(Fixture), 860*170*125mm(LED Driver Box) Gross Weight About 19.5kg Operating Temperature -20~40℃ Control Manual Dimming System, Compatible with OCL Controller External Dim Yes with OCL Controller External Dim Connector RJ45 Connector Build-in 2x Housing Material Aluminum Alloy Lifetime L90: >50,000 Hours... -
Page 4: Control Diagram
3.2 Spectrum 4. Control 4.1 Control Diagram: 4.2 Control function: -Timer setting - Dimming Control - Over Temperature Protection - For Large Application up to 150 Units Daisy Chain - Perfect Simulation of Sunrise and Sunset... -
Page 5: Installation Instruction
5. Preparation •Transportation Improper transportation may harm or can even cause damage to LED lamp and power housing box. In case of obvious damage or incomplete scope of supply, please refer to your vendor and Haulage company immediately. •Unboxing Please handle and unbox the LED lamp with care! Check the delivery contents for completeness first. A detailed list of the product range is contained on the inner cover in this manual. -
Page 6: Operation
7. Operation 7.1 Safety Measures & Precaution Warning! This LED fixture is powered with electricity (AC 120-277V)! To prevent injury, we ask you to desist from improper use! •• Never open the case of the device! Health hazards await the consumer and the warranty of the device expires. 7.2 Putting into Service Operate the LED fixture only horizontally, while hanging or slightly angled (approx.
