Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear protective
instructions
gloves
1.
SAFETY
1.1.
UNDERSTANDING INSTRUCTIONS AND WARNINGS
The owner and/or operator shall understand the operating instructions and warnings before operating the chain block.
9
WARNING! Information must be emphasised and understood.
If the operator is not fluent in English, the product instructions and warnings must be read to, and discussed with, the operator in the
9
operator's native language by the owner, making sure the operator understands the contents.
Ensure that the chain block is in a good working order and condition. Follow the inspection requirements as described in Section
9
8 Maintenance. Take immediate action to repair or replace damaged parts by contacting your supplier. Ensure that all accessory
lifting devices are suitably certified. If the chain block is damaged, remove from service immediately.
Use recommended parts only. The use of unauthorised parts may be dangerous and will invalidate the warranty.
9
Wear goggles, hard hat, protective gloves, and steel-toed work boots during set up and use.
9
WARNING! Failure to heed safety and warning instructions may result in damage and/or personal injury and will invalidate the warranty.
This chain block is designed for lifting within a garage or workshop environment.
9
Ensure the support for the chain block is capable of withstanding a load of at least 1½ times the chain block safe working load.
9
Keep the chain block clean for the best and safest performance.
9
Locate the chain block in a suitable, well lit work area. Keep work area clean and tidy and free from unrelated materials.
9
Ensure all non-essential persons keep a safe distance whilst the chain block is in use.
9
Keep children and unauthorised persons away from the working area.
9
Store in a dry, childproof area when not in use.
9
To avoid injury, be fully aware of your own and other people's locations, in relation to the lifting, and lowering, of the load.
9
Keep a sound footing and balance, and ensure the floor is not slippery.
9
Ensure load sling(s) are fully engaged in the load hook and that the hook safety bar is in the closed position. Raise and lower in a
9
smooth, controlled manner and DO NOT shock load the chain block by allowing the attached load to fall freely, even for very short
distances. Lower load with care, ensuring that you are fully aware of the condition of the surface onto which the load is to be placed.
Check the brake operation by stopping when the load has been raised a short distance (100mm) and ensuring that it is held with no
9
downward creep.
Before operating inspect both hooks to ensure it is securely attached.
9
Ambient operating temperature is between -10°C and +50°C.
9
All moving parts should always be kept lubricated before operating. Use a qualified person to lubricate and maintain the various parts.
9
DANGER: Use the chain block for lifting only, NOT for supporting the lifted load.
DO NOT operate chain block with anything other than manual power (by hand).
8
DO NOT allow the load to swing during operation and DO NOT subject the equipment, chains or straps to shock loads.
8
DO NOT use the chain block in an explosive or corrosive atmosphere.
8
DO NOT operate the chain block if damaged.
8
DO NOT allow untrained persons to operate the chain block.
8
DO NOT exceed the rated capacity (safe working load) of the chain block.
8
DO NOT attempt to lift a load if the chain block is kinked or knotted.
8
DO NOT try to raise a load with two, or more, chain block - use a single block of adequate capacity.
8
DO NOT use the chain block to drag the load across the floor. Always position the load directly below the hoist.
8
DO NOT wrap the chain block around the load - always use separate and suitable slings/chains/ropes of the correct capacity.
8
DO NOT allow anyone to stand or pass beneath the raised load.
8
DO NOT use the chain block for purposes other than that for which it is designed.
8
DO NOT lift people or lift loads over people. DO NOT stand under load. Falling loads can injure or kill people.
8
DO NOT operate chain block with dangerous goods (e.g. molten masses, radioactive materials).
8
DO NOT use whilst under the influence of drugs, alcohol or intoxicating medication.
8
When not in use, store in a safe, dry, childproof location.
9
DO NOT remove or cover warning labels and/or tags. These carry important safety information. If unreadable or missing, contact
8
Sealey Customer Service Centre for a replacement.
WARNING! Failure to heed safety and warning instructions may result in damage and/or personal injury and will invalidate the
warranty.
NOTE: Ensure you have read and understood the safety instructions at the beginning of this section before you operate the chain
block.
© Jack Sealey Limited
CHAIN BLOCKS
MODEL NO's:
CB5000E
Wear safety
Wear head
footwear
protection
Original Language Version
CB500E CB1000E CB2000E CB3000E
Wear eye
protection
Page 1
CB500E, CB1000E, CB2000E, CB3000E, CB5000E
Issue 2 16/09/24
