Summary of Contents for AMD DIrect IM-15N
- Page 1 NUGGET ICE MAKER USER MANUAL...
- Page 3 IM-15N THANK YOU Thank you for your purchase. We’d like to welcome you to the AMD Direct family of luxury outdoor kitchen products and look forward to being a part of your home for years to come. As a family business with over 20 years of industry experience, we aim to deliver exceptional quality and personal service.
- Page 4 NUGGET ICE MAKER USER MANUAL...
-
Page 5: Table Of Contents
NUGGET ICE MAKER USER MANUAL TABLE OF CONTENTS SAFETY AND INSTALLATION INSTRUCTIONS GENERAL SAFETY REQUIREMENTS BEFORE OPERATING INSTALLATION OPERATING YOUR APPLIANCE TROUBLESHOOTING LINE DRAWING SAFETY WARRANTY... -
Page 6: Safety And Installation Instructions
SAFETY AND INSTALLATION INSTRUCTIONS WARNING CAUTION Before the appliance is used, it must be properly 1. Stainless steel exposed to chlorine gas positioned and installed as described in this and moisture – such as areas with spas manual, so read the manual carefully. To reduce or swimming pools –... -
Page 7: General Safety Requirements
GENERAL SAFETY REQUIREMENTS ENERGY SAVING TIPS WARNING • The appliance should be located in the coolest area of the room or outdoor location, away from heat-producing FOLLOW WARNING CALLOUTS BELOW appliances and out of direct sunlight. ONLY WHEN APPLICABLE TO YOUR •... -
Page 8: Before Operating
BEFORE OPERATING Shipment Arriving Damaged: WARNING VISIBLE DAMAGE If your shipment arrives with visible damage to the ELECTRICAL PARTS & COMPONENTS box/carton, be sure the damage is noted on the bill of freight or express receipt and signed by the Disconnect all power supplies and batteries person making the delivery. -
Page 9: Installation
INSTALLATION EXTENSION CORD ELECTRICAL CONNECTION Because of potential safety hazards under certain All electrical connections must conform to local conditions, it is strongly recommended that you regulations and be carried out by a qualified do not use an extension cord with this appliance. engineer. - Page 10 +10% to -5% of the rated voltage. WARNING If the ice machine is turned off, wait at least 3 minutes before restarting to avoid compressor damage. ELECTRICAL SPECIFICATION MODEL VOLTAGE WATT CURRENT US - 110V/60Hz IM-15N 160W 1.5A EU - 220V/50Hz NUGGET ICE MAKER USER MANUAL...
-
Page 11: Operating Your Appliance
OPERATING YOUR APPLIANCE It is recommended that you install the appliance in NOTE: a place where the ambient temperature is between It is recommended that you do not install the 41°F and 89.6°F (5°C and 32°C). If the ambient appliance near an oven, radiator or other heating temperature is above or below recommended source, as heat sources may increase electrical temperatures, the performance of the unit may... - Page 12 OPERATING YOUR APPLIANCE NOTE: Pressing the start/standby button does not turn off the power to the ice machine. The machine WARNING must be unplugged and disconnected from the main power supply before any servicing or cleaning. After turning off your ice maker, please wait ICE FULL at least 3 minutes before restarting to avoid When the ice bin reaches full capacity, the ice maker...
- Page 13 OPERATING YOUR APPLIANCE HOW TO SET THE ICE-MAKING CYCLE TIME CONDENSER CLEANING Press the up/down button to adjust the ice-making A dirty or clogged condenser restricts airflow, cycle time, displayed in the window. The cycle time reducing efficiency, ice production performance, and can be set between 0 and 45 minutes, with a default raising operating temperatures, which can lead to time of 16 minutes to maximize ice production.
-
Page 14: Troubleshooting
TROUBLESHOOTING Many common problems can be solved easily, saving you the time spent communicating with customer service. Try the suggestions below to see if the issue has a simple solution. ERROR SYMPTOM PROBABLE CAUSE SOLUTION CODE Ice damper or ice full Ice damper dislodged or ice full Check ice damper and ice full sensor, sensor fault... - Page 15 TROUBLESHOOTING ERROR SYMPTOM PROBABLE CAUSE SOLUTION CODE Out of the pressure limit Condenser termperature too high Make sure the unit meets sufficient clearance requirements for proper air circulation, Check the pressure of refrigeration system Blockage of cooling system Clean the condenser Pressure switch fault Check switch and replace if necessary Condenser sensor open...
-
Page 16: Line Drawing
LINE DRAWINGS NUGGET ICE MAKER USER MANUAL... -
Page 17: Safety
SAFETY IM-15N ANTI-MICORBIAL ICE SAFETY SYSTEM FEATURES • Ensure safe, sanitary ice for use • Kills bacteria, viruses, and other microorganisms • Reduces the formation of slime, mold, and yeast • Keeps ice machines and ice bins cleaner for longer •... -
Page 18: Warranty
NUGGET ICE MAKER USER MANUAL... - Page 20 CONTACT US 14520 Delta Ln, Suite 105 Huntington Beach, CA 92647 AMDDirect.com (800) 966-8126 M–F 6:00 am – 4:30 pm (PST) VER.021225...
