Summary of Contents for Ravendo CLM LS 200 ERGO
- Page 1 El sækkevogn clm ls 200 ergo Powered Sack Truck CLM LS 200 ERGO 164780...
-
Page 2: Table Of Contents
INDHOLD OM PRODUKTET SIKKERHED BRUG CHECKLIST FOR ÅRLIG KONTROL EU DECLARATION OF CONFORMITY... -
Page 3: Om Produktet
Ravendo A/S. Sækkevognen med motor sikrer en sikker og let transport af tunge emner i Forsøg aldrig at ombygge eller tilpasse... - Page 4 Udstyret med frem-og-til- bage styring samt døde- Ergonomiske håndtag mandsknap Malet 30 mm stel Genopladeligt Litium-Ion batteri 24V, 10 Ah indbyg- 250W akselmotor Udfaldsramme 3.00 x 4 luftgummihjul Fast bæreplade...
-
Page 5: Brug
BRUG Før brug 1. Påbudt sikkerhedsbeklædning: Sikkerhedsfodtøj og arbejdshandsker. 2. Check at produktet er intakt 3. Produktet må ikke bruges i ATEX-zoner 4. Opladerstikket fjernes 5. Tænd produktet Under brug Tænd/sluk med nøglen: Pos. 0) Slukket med nøgle isat —batteri kan fjernes. Pos. - Page 6 Efter brug/parkering 1. Sluk produktet på afbryder (nøgle). 2. Kontroller at produktet er intakt (ingen løse ledninger). 3. Sæt til ladning ved endt arbejdsdag. 4. Opladning må kun ske i tørt miljø og/eller indendørs. Batteri kan fjernes når nøgle er i Pos 0). Vedligeholdelse: 1.
-
Page 7: Checklist For Årlig Kontrol
Checkliste for årlig kontrol 1. Sikre at oplader er taget fra og produktet er slukket. 2. Kontroller ledninger og gashåndtag er intakt. 3. Kontroller at frikobling virker. 4. Kontroller konstruktionen for øvrige defekter. 5. Kontroller at ce-mærkning er intakt. Varenr. 164780 Model CLM 200 LS... -
Page 8: Eu Declaration Of Conformity
Pneumatic wheels 3.00 x 4/4, steel rim with ____________________________ Country of Origin: Denmark Date: 01.05.2022 Producer: _______________________________ CEO, Ravendo A/S Ravendo A/S • Klokkestøbervej 3-5 • DK-8800 Viborg • CVR-nr 29604045 • Tel. +45 86 44 73 11 • www.ravendo.com • ravendo@ravendo.com... - Page 9 CONTENTS ABOUT THE PRODUCT SECURITY CHECKLIST EU DECLARATION OF CONFORMITY...
-
Page 10: About The Product
Ravendo A/S. The powered sack truck ensures a safe Never attempt to remodel or adapt the and easy transport of heavy items in product for any use other than that terrain and on ramps. - Page 11 Equipped with BACK and FORTH control and dead- Ergonomic handles man button Painted 30 mm frame Rechargeable Lithium-Ion battery 24V, 10 Ah built-in 250W shaft motor Mounted with support plate and folding frame 3.00 x 4 pneumatic wheels...
-
Page 12: Use
Before use 1. Mandatory safety clothing: Safety footwear and work gloves. 2. Check that the product is intact 3. The product must not be used in ATEX zones 4. Remove the charger plug 5. Switch on the product During use Switch the key on/off: Pos. - Page 13 After use / parking 1. Switch off the product on the switch (key). 2. Check that the product is intact (no loose wires). 3. Set for charging at the end of the working day. Charging may only take place in a dry environment and / or indoors. Batte- ry can be removed when key is in Pos 0).
-
Page 14: Checklist
Checklist for annual inspection 1. Make sure the charger is unplugged and the product is turned off. 2. Check wiring and throttle lever are intact. 3. Check that the release works. 4. Check the construction for other defects. 5. Check that the CE marking is intact. Item No. -
Page 15: Eu Declaration Of Conformity
Pneumatic wheels 3.00 x 4/4, steel rim with ____________________________ Country of Origin: Denmark Date: 01.05.2022 Producer: _______________________________ CEO, Ravendo A/S Ravendo A/S • Klokkestøbervej 3-5 • DK-8800 Viborg • CVR-nr 29604045 • Tel. +45 86 44 73 11 • www.ravendo.com • ravendo@ravendo.com... - Page 16 www.ravendo.com...
