CONTENTS Safety Precautions ··········································1/2 Recommendation Of Power Supply Cables ························2 Product Decomposition ·······································3 Status Indicator ··············································4 Product Features ·············································4 Touch Button Introduction ·····································4 Display ·····················································5 Screen Display Introduction ·······························6/7/8/9 Charging Failure ············································10 Timer Function(Basic Version) ·································11 APP Charging Guide ·······································12/13 Start Charging ··············································14... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Thank you for purchasing and using ZENCAR EV Charging Model 2 cable. In order to help you properly use this product, please read this user's manual carefully before charging. Caution It's not recommended to use the device for charging while raining due to the safe use of electricity. -
Page 4: Recommendation Of Power Supplycables
Cable length: 120m~200m 3*6.0mm²Copper wire 3*10.0mm²Copper wire 3*16.0mm²Copper wire 380V-16A-11kW Cable length:＜10m Cable length:10m~30m Cable length:30m~100m Cable length:＞100m 5*2.5mm² Copper wire 5*4.0mm² Copper wire 5*6.0mm² Copper wire 5*10.0mm² Copper wire 380V-32A-22kW Cable length:30m~120m Cable length:120m~200m Cable length:≤30m 5*10.0mm² Copper wire 5*16.0mm²... -
Page 5: Product Decomposition
PRODUCT DECOMPOSITION 3.5 inch LCD screen Controller EV Plug LED indicator Power plug Control Area ( 380V 32A red CEE) Brazil plug NEMA14-50 AU plug NEMA10-30 Schuko NEMA6-20 G piug NEMA5-15 380V16A T13 plug red CEE 220V16A Danish Plug blue CEE 220V32A NEMA10-50 blue CEE... -
Page 6: Status Indicator
STATUS INDICATOR Green on: Ready Green flash: EV connected / Red flash: Charging Error Charging completed Blue flow: Charging Blue on: Schedule charging( basic version)/ Waiting for sliding charging / Reservation on(WiFi version ) PRODUCT FEATURES Standard IEC 62752 AC 30mA + DC 6mA Voltage 220V士10%(single phase) 380V±10% ( three phase ) -
Page 7: Display
DISPLAY Date / Time WiFi Grounding Device Lock Charging ( Dynamic Guidance ) Charging Charging Mode Charging Time Charging Power Charging Energy Charging Voltage / Current of L1 L2 L3 Ta:Adapter Temperature Tc: Circuit Board Temperature Tp: CEE Plug Temperature Device Lock: No operation after charging starts 3 minutes, the device will be locked, and the buttons will not work. -
Page 8: Screen Display Introduction
SCREEN DISPLAY INTRODUCTION 2022-11-14 10:36 Waiting for connecting Power on, waiting for plugging into car. Connecting... 01:30:56 21.85 12.68 34.0 ℃ 2022-11-14 10:36 Waiting for responding Plugged into car, waiting for charging signal from the vehicle. Waiting... 01:30:56 21.85 12.68 34.0 ℃... - Page 9 2022-11-14 10:36 Charging In charging status, display shows charging data. Charging... 01:30:56 21.85 12.68 34.0 ℃ 2022-11-14 10:36 Reservation (WiFi version ) Screen shows reservation on after setting in APP. Reservation 01:30:56 21.85 12.68 34.0 ℃ Settings Settings Record Date/Time Before plugged in to car, click middle Brightiness Emergency mode...
- Page 10 SCREEN DISPLAY INTRODUCTION The charging device connected to the power socket, touch the middle button to enter the setting page. Charging Records Enter the [Charging Records] page, view max 30 charging records. Date & Time Enter the [Date Setting] page, use right button / left button /Middle button to set date and time.
-
Page 11: Screen Brightness
Screen Brightness Enter the [Screen Brightness] page,set bright- ness 1-6 levels. 2022-11-14 10:36 Emergency mode Emergency mode Enter the [Emergency mode] page, set emergen- State cy mode on, charge with ungrounding. Cancel Done 2022-11-14 10:36 Reset to factory defaults Reset Enter the [ Reset ] page，... -
Page 12: Charging Failure
CHARGING FAILURE 2022-11-14 10:36 Error 01:30:56 21.85 12.68 34.0 ℃ [Error] occurs on the device Error code details are as follows: Relay failure CP failure Ground protection RCD self-check abnormality (Ground Protection is turned on) Temperature sensor Undervoltage protection abnormal in power plug Overvoltage protection Leakage protection Leakage protection... -
Page 13: Timer Function(Basic Version)
TIMER FUNCTION (Basic version ) Before the charging is locked, click the middle button to enter the reservation charging.Click the right button once to increase by 1 hour, and exit the reservation after more thar12 hours; press the left button once to decrease by 1 hour, if the time is less than 1 hour,the left button has no response;... -
Page 14: App Charging Guide
APP CHARGING GUIDE 1. Search APP "Smart Life" from APP Store or Google Play, or Scan below QR code to download the APP. Smart Life QR Code 2. Turn on the WiFi, Bluetooth and Location on mobile phone. ZENCAR-Epro32 Add device ·... - Page 15 [Add Device] page, click "Add". · Enter name and password of WiFi, then click"Next". · The network configuration of device starts and takes 1-2 minutes to finish. · Contiguration complete, click "Done" to enter the APP and control the device on the mobile phone.
-
Page 16: Start Charging
② [Set amps] Set amps by clicking left and right buttons before plugging into the vehicle. ③ [Connection] Plug into the vehicle. ④ [Charging] Blue indicator flow, charging starts. Method 2 -APP ① [Power on] Firmly insert the plug into the power socket. ② [Connection] Plug into the vehicle, waiting for operation on APP. -
Page 17: Stop Charging
This warranty does not cover any damage due to the following cases: 1.Improper handling,installation, use and maintenance by users. 2.The break down and the failure caused by the force majeure, such as direct damage and inability to function properly caused by natural disasters. - Page 18 Shanghai Zencar IndustryCo., Ltd. Tel: 0086-519-68783066 Fax: 0086-519-68783077 Web: www.zencar.net Add: No.712, GaoxinSquare, No.518, Liaohe Road,Xinbei, Changzhou, Jiangsu, China 213032...
