Disclaimer
The product name and brand name may be registered trademark of related
manufactures. ™ and ® may be omitted on the user manual. The pictures in
this user manual are just for reference. We reserve the rights to make
changes without further notice to a product or system described herein to
improve reliability, function or design.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI
Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
User Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Delta HDMI-EX-6IR-V4
Summary of Contents for Delta HDMI-EX-6IR-V4
- Page 1 User Manual Disclaimer The product name and brand name may be registered trademark of related manufactures. ™ and ® may be omitted on the user manual. The pictures in this user manual are just for reference. We reserve the rights to make changes without further notice to a product or system described herein to The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI improve reliability, function or design.
- Page 2 · Important Safety Notice 1. Please distinguish the transmitter and receiver before installation. 2. Do not disassemble the machine to repair the product during the working process to avoid electric shock. 3. Please cut off the power before installation. Live installation may damage the equipment.
- Page 3 · Package Contents · Interfaces Transmitter unit x1pc Receiver unit x1pc User manual x1pc ① DC 5V input Connect to the 5V/500mA DC power adapter. · Installation Requirements ② HDMI input Connect to a HDMI source device. 1. HDMI source device (compute graphics card, DVD, PS4, HD Connect the IR blaster extension cable, please keep the infrared transmitter as close as possible ③...
- Page 4 · Installation Procedures 1. The network cable should follow the standard of IEEE-568B. It is recommended to select a network cable with less loss and crosstalk. 1-Orange/white 2-Orange 3-Green/white 4-Blue 5-Blue/white 6-Green 7-Brown/white 8-Brown 2. Connection Network cable HDMI IN HDMI OUT HDMI Display ①...
- Page 5 3. Connection instruction 1) Connect the HDMI port of the source device to the HDMI IN port of Q：Why there is no image/image or sound is not played smoothly? the transmitter via an HDMI cable. A：Press the “RESET” b utton of the receiver to restart the device. 2) Connect the CAT6 OUT port of the transmitter and the CAT6 IN port Reconnect the devices with a shorter network cable of the receiver via a network cable.
- Page 6 · Specification Items Specification Voltage/Current DC5V/500mA Power consumption TX<1.5W； RX<1.5W HDMI compliance HDMI 1.4 HDCP compliance 800x600、1024x768、1280x720、 1280x960、1366x768、1440x900、 1680x1050、1920x1080、480i@60Hz、 HDMI resolution 480p@60Hz、576i@50Hz、 576p@50Hz、720p@50/60Hz、 1080i@50/60Hz、 1080p@24/25/30/50/60Hz、 3840x2160@24/25/30Hz Audio formats DTS、DTS-HD、PCM、LPCM Support Support EDID through IR Pass-back Frequency Range：20~60KHz Input and output TMDS signal 0.7~1.2Vp-p(TMDS) Input and output DDC signal 5Vp-p(TTL)
