PRC-Saltillo Liberator TOUCHCHAT Instruction Manual

TOUCHCHAT: Using 1 & 2 Switch Scanning
VOLUME UP/ DOWN
POWER/SLEEP
Technical Support:
Tel: +44 (0)1733 370 470 (Option 2)
Email: info@liberator.co.uk
Regional AAC Consultants:
If you wish to speak to your Regional AAC Consultant,
please call +44 (0)1733 370 470 (Option 3)
Setting up Switch Scanning
As an alternative to directly choosing each button on the
screen, TouchChat offers the ability to use single and two
switch scanning via Bluetooth AeroSwitch and standard
wired switches plugged into device switch jack A or B. The
touchscreen itself can be used as a single switch.
Switch Port A Switch Port B
Dialogue, LAMP Words for Life, TouchChat, and Via are trademarks of PRC-Saltillo. App Store, Guided Access, iPad, and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries and regions. All other
V1.1
Connect the Amp to the Device and TouchChat
To use wired external switches you will need to ensure that
the Amp is connected to the device and connected to the
software.
To Connect the Amp to the Device
1. Select Settings > Bluetooth.
2. Tap the Amp.
3. Connected will be displayed once connected.
To Connect the Amp to the TouchChat Software
1. Open TouchChat.
2. Select Menu > Settings.
3. Select the Amp.
4. Connected will be displayed once connected.
Plug the switch into either switch jack A or B. If you are using
two switches, plug a switch into each.
Using an AeroSwitch in TouchChat
To use an AeroSwitch with TouchChat, the AeroSwitch must
be set to 0, 1, or 2 on the Rotary Dial on the bottom of the
switch. To enable this:
1. Turn OFF the AeroSwitch.
2. Set the rotary dial to either 0,1 or 2.
3. Now turn the power button on the AeroSwitch to ON.
If you wish to use 2 different AeroSwitches in TouchChat
then they will have to be set to different numbers on the
rotary dial. E.g., the first AeroSwitch is set to 0 and the
second AeroSwitch is set to 1.
The AeroSwitch will allow up to 2 wired switches to be
plugged into its switch ports, and these can then be used
with TouchChat. To enable this:
1. Turn OFF the AeroSwitch.
2. Plug the wired switches into Jack A or B, or both if you
are wanting to use 2 switches with the AeroSwitch.
3. Turn the AeroSwitch ON again.
Enabling Scanning in iOS
1. Select Menu > Settings.
2. Set Scanning Enabled to ON.
trademarks and copyrights are the property of their respective owners. All rights reserved.
Setting 1- or 2-Switch Scanning
1. Select Menu > Settings > Configure Switches.
2. Select 1 Switch or 2 Switch depending on what is
required.
Configuring the Switches in TouchChat
You will need to program the wired switch, wireless switch,
or screen to the switch within the TouchChat software. To
do this:
1. Select Menu > Settings > Configure Switches > Switch
1: Start Scan / Activate.
2. Press the required wired switch, AeroSwitch or
screen*.
3. To set switch 2 select Switch 2: Activate.
4. Press the required wired switch or AeroSwitch.
5. Select Done.
* Note: Please be aware that the screen can only be used
for 1-switch access.
If you select 1-Switch configuration, Switch 1 will be active
and Switch 2 will be grayed out. If you select 2-Switch
configuration, both Switch 1 and Switch 2 will be active.
Scanning Methods
There are 3 types of scanning methods available within
TouchChat: Auto-Scan, Button Hold Scan, and Step-Scan.
Activating Auto-Scan
1. Select Menu > Settings.
2. Turn ON Auto-Scan.
Activating Button Hold Scan
Auto-Scan must be turned off to enable this option. To
activate Button Hold Scan:
1. Select Menu > Settings.
2. Ensure Auto-Scan is turned OFF.
3. Turn ON Button Hold Scan.
Activating Step-Scan
Auto-Scan and Button Hold Scan must be turned off. To
Activate Step-Scan:
1. Select Menu > Settings,
2. Ensure Auto-Scan is turned OFF.
© Liberator Ltd 2024
