Page 1 Shirt and Clip Shirt and Clip system Quick Start Guide...
Page 2 Subject to change without notice. We have taken great care in compiling the information in this document to ensure that it is as useful, accurate, and reliable as possible. However, ADRESYS assumes no responsibility for any inaccuracies it may contain.
Page 3: Table Of Contents
Table of contents Welcome About ANGEL React Safety Colors and icons Installation Operation Technical data...
Page 4: Welcome
Welcome Thank you for opting for an ANGEL React system, which we have developed to increase your safety at work. ANGEL React detects emergencies while working and activates the emergency call chain. No Motion (motionlessness) Elapsed Task Timer Fall accident...
Page 5: About Angel React
Manual alarm The ANGEL React Shirt system can be used with the ANGEL React T-Shirt. The ANGEL React Clip system can be used with either a clip or smart trousers. For more information about smart trousers contact us at angelreact@adresys.com.
Page 6: Safety
Safety This Quick Start Guide gives you a brief overview of the ANGEL React equipment and its handling. It contains important instructions for the safe, proper, and efficient use of this equipment. Any use of the ANGEL React equipment other than that described in this Quick Start Guide and the user manual is improper use.
Page 7: Safety Instructions
Neither we, nor the manufacturer, nor the supplier will be liable for any injury or damage resulting from the use of the ANGEL React system for purposes other than those for which it was intended. This section only contains some of the legal information and has been shortened to make it easier to read.
Page 8 Only use ANGEL React if the circumstances permit. If your ANGEL React system or any accessory does not seem to function properly, do not use it. If in doubt, contact our support. Contact our support immediately if you become aware of problems or damage.
Page 9: Colors And Icons
Colors and icons Colors of the ANGEL React system Our colors provide information about and reflect the status of the ANGEL React system. The Genius and the app communicate using the same color. Colors in Genius and app Green READY Genius and app are working correctly.
Page 10 Fall accident ANGEL React detects a free fall with impact. If this is fol- lowed by motionlessness, the system assumes a fall acci- dent. No Motion ANGEL React detects motionlessness if you do not move for an extended period.
Page 11: Installation
Place the Genius on the charging station during the update. Entering emergency contacts Your emergency contacts will be notified in the event of an emergency by the ANGEL React App. For this reason, choose people nearby that could quickly help in case of an accident.
Page 12: Operation
WARNING Risk due to lack of data or Bluetooth® connection The ANGEL React system may not work reliably or be able to place emergency calls if the data or Bluetooth® connection is not activated or if these connections are missing. You should not assume that the system can call for help in every situation.
Page 13 Electrical accident: no pre-alarm If the ANGEL React Shirt system detects an electrical accident, it raises an alarm immediately, there is no pre-alarm. Your smartphone requires a data connection to send emergency information. If this connection is unavailable, the data will be sent the next time you are connected.
Page 14 If your smartphone has no internet access or access to mobile data, you will not be able to extend or disable your Task Timer. The emergency call chain will be activated automatically when the programmed time has ended. Find a location with access to Wi-Fi or mobile data and extend or disable the Task Timer.
Page 15: Technical Data
Technical data The operating conditions define the physical environment and the parameters for using the Genius. You must only use the Genius under the following operating conditions: Temperature Operation -10 to +55 °C Storage -10 to +55 °C Storage: optimum storage temperature to max- +10 to +25 °C imize battery life While charging...
Page 16 Support Contact us: ADRESYS Adaptive Regelsysteme Gesellschaft m.b.H. Oberndorferstraße 35/C A-5020 Salzburg Contact: support@adresys.com Telephone: +43 59495 6969 We are available from Monday to Friday between 8:00 am and 6:00 pm. If you are unable to reach us, please leave us a message and we will get back to you directly.
Page 17 Location Beacon Quick Start Guide...
Page 18 Subject to change without notice. We have taken great care in compiling the information in this document to ensure that it is as useful, accurate, and reliable as possible. However, ADRESYS assumes no responsibility for any inaccuracies it may contain.
Page 19 Table of contents Welcome Safety Installation Operation Technical data...
Page 20: Welcome
Thank you for opting for an ANGEL React Location Beacon. The Location Beacon is part of the Indoor Positioning System (IPS) for the ANGEL React system. It transmits location information and is used together with other ANGEL React products like the ANGEL React Shirt or Clip system.
Page 21: Safety
This Quick Start Guide contains important instructions for the safe, proper, and efficient use of an ANGEL React Location Beacon. Any use of the device other than that described in this Quick Start Guide and the user manual is improper use. Improper use may impair the safety of the equipment and result in property damage or personal injury.
Page 22: General Instructions
Neither we, nor the manufacturer, nor the supplier will be liable for any injury or damage resulting from the use of the ANGEL React system for purposes other than those for which it was intended. This section only contains some of the legal information and has been shortened to make it easier to read.
Page 23: Installation
If you do not mount your Location Beacon properly, it might fall from the wall/ ceiling. Make sure you slide the ANGEL React Location Beacon into the rail from top to bottom or sideways. This will ensure that it is fixed, i.e., that it cannot be moved without releasing the attachment.
Page 24 Connect your Location Beacon to the POE adapter. Connection to the ANGEL React system Once the ANGEL React Location Beacon is mounted and connected to a power supply, the operator needs to set it up. Data entered in the Location Beacon is broadcasted in the near vicinity Nearby devices have free access to this data.
Page 25 Once you have scanned the QR code of your Location Beacon, it might need a firmware update. This might take several minutes. After the connection process, check the location data of the beacon.
Page 26: Operation
Operation For users the Location Beacon is very easy to handle. It works automatically with every Genius in its vicinity and sends location information to every ANGEL React system nearby. Daily use In daily use you have to do nothing but the following: Make sure the Location Beacon is permanently connected to a power source.
Page 27: Technical Data
Technical data The operating conditions define the physical environment and the parameters for using the Location Beacon. Only use it under the following operating conditions: Temperature Operation/Storage -10 to +55 °C Rated current 500 mA Rated voltage 5 V ±10% Maximum operating height 2000m above sea level Usage...
Page 28 Support Contact us: ADRESYS Adaptive Regelsysteme Gesellschaft m.b.H. Oberndorferstraße 35/C A-5020 Salzburg Contact: support@adresys.com Telephone: +43 59495 6969 We are available from Monday to Friday between 8:00 am and 6:00 pm. If you are unable to reach us, please leave us a message and we will get back to you directly.
Page 29 ANGEL React Watchdog Quick Start Guide Watchdog Quick Start Guide...
Page 30 Subject to change without notice. We have taken great care in compiling the information in this document to ensure that it is as useful, accurate, and reliable as possible. However, ADRESYS assumes no responsibility for any inaccuracies it may contain.
Page 31 Table of contents Welcome Usage Safety Technical data Space for your notes...
Page 32: Welcome
Welcome Thank you for opting for an ANGEL React Watchdog. As part of the ANGEL React program, we developed the Watchdog to make your working environment safer. ANGEL React notices whenever you get into a dangerous situation while working and immediately reacts by calling for help.
Page 33: Usage
Usage power supply or power bank for USB ANGEL React Genius ANGEL React Watchdog Scenarios for non-stationary power Scenarios for existing stationary source with switch-off functionality emergency-off circuit...
Page 34: Safety
ANGEL React Watchdog. Designated use The ANGEL React Watchdog helps you in critical work situations and can save lives. It is based on the ANGEL React Shirt or Clip system and is an additional component that provides added safety. In cases of emergency (e.g., electrical accident) the ANGEL React Watchdog has a potential free contact, which can be used to command to power off e.g.
Page 35: General Instructions
If your Watchdog or any accessory does not seem to function properly, do not use it. If in doubt, contact our support. Contact our support immediately if you become aware of problems or damage. Only have the equipment repaired by ADRESYS or a service contracting party listed on our website. Environmental conditions Do not use the ANGEL React Watchdog under ambient conditions that exceed the...
Page 36: Technical Data
250W limited by internal fuse Data of the connection cable to the potential- 250 Vrms/5A, 2x0,5mm2, 2m length free contact with Sub-D-connector: AD-S04128 with ANGEL React Connector: AD-S04130 with open end: AD-S04131 The Watchdog requires no maintenance and must not be cleaned.
Page 37: Space For Your Notes
Space for your notes...
Page 40 Support Contact us: ADRESYS Adaptive Regelsysteme Gesellschaft m.b.H. Oberndorferstraße 35/C A-5020 Salzburg Contact: support@adresys.com Telephone: +43 59495 6969 We are available from Monday to Friday between 8:00 am and 6:00 pm. If you are unable to reach us, please leave us a message and we will get back to you directly.
Page 41 ANGEL React Restart Inhibit Quick Start Guide Restart Inhibit Quick Start Guide...
Page 42 Subject to change without notice. We have taken great care in compiling the information in this document to ensure that it is as useful, accurate, and reliable as possible. However, ADRESYS assumes no responsibility for any inaccuracies it may contain.
Page 43 Table of contents Welcome Safety Installation Emergency detection Technical data...
Page 44: Welcome
Welcome Thank you for opting for an ANGEL React Restart Inhibit. Combine it with an ANGEL React Watchdog, and it enables the Watchdog to be correctly connected to an existing emergency-off circuit. power supply or power bank for USB ANGEL React...
Page 45: Safety
Safety This Quick Start Guide gives you a brief overview of the ANGEL React Restart Inhibit and its handling. It contains important instructions for the safe, proper, and efficient use of this equipment. Any use of the ANGEL React equipment other than that described in this Quick Start Guide and the user manual is improper use.
Page 46: Operator Qualifications
Some of the preconditions for the use and performance of the ANGEL React systems are outside ADRESYS's sphere of influence. ADRESYS aims to ensure high availability of the services but is dependent on third party services (network operator, GPS signal) over which ADRESYS has no influence.
Page 47 Notes for safe operation The Restart Inhibit and its accessories may only be used if they are in perfect technical condition. Do not install the Restart Inhibit if the housing has been damaged during transport. Take the device out of operation and have it uninstalled by a qualified electrician if you notice mechanical or other damage, or any unusual conditions.
Page 48: Installation
The Lemo socket on the top of the Restart Inhibit is used to connect it to the Watchdog via the ANGEL React Watchdog Connection Cable. If no suitable cable is enclosed for connecting the Watchdog to the Restart Inhibit, one must be ordered from ADRESYS. The order number is AD-S04130. Do not use a different cable.
Page 49 Connections inside the Restart Inhibit: Connect the power cable wires (100-240 VAC) for the Restart Inhibit according to the connection diagram on the inside of the cover. Wire the cables of the emergency-off circuit(s) to the red and yellow terminals according to the connection diagram on the inside of the cover...
Page 50: Emergency Detection
Emergency detection If your ANGEL React system detects an emergency (No Motion, fall accident, electrical accident, manual alarm, or elapsed Task Timer), it sounds a local alarm using acoustic and optical signals, the ANGEL React App informs your emergency contacts, and the Watchdog commands the Restart Inhibit to interrupt the emergency-off circuit.
Page 51: Technical Data
Technical data You can find the complete technical data in the user manual. Only the most important data is listed here. Operating conditions Temperature Operation/Storage -10 to +55 °C Rated current 500 mA Rated voltage 5 V ±10% Maximum operating height 2000m above sea level Usage Indoors...
Page 52 otes...
Page 53 Support AD-S04147-00 Art.Nr.: AD-S04147-00 9 120116 812548 GTIN-Nr.: 9120116812548 ENU 1.1...
