Osawa & Company SC200-50D W/F Instructions Manual

① Please make sure the following parts are contained inside the package:
Silent-Cleaner ·················································· 1
Suction Pipe ···················································· 1
Hose ······························································ 1
Hose Clamp ····················································· 2
Spare Filter (for fine dust collection) ······················ 1
② Put the Silent-Cleaner on top of any available 200L open top drum and fasten well.
(If there are any available bands attached with the open top drum, fasten well.)
③ Attach the hose with the suction mouth of the Silent-Cleaner and fasten well with the hose clamp.
(It can be made easier by turning the hose clockwise while attaching.)
④ Connect the suction pipe with the hose and fasten well with the hose clamp.
(It can be made easier by turning the hose clockwise while attaching.)
⑤ Connect the air hose (ID over 19mm) with the Silent-Cleaner. For optimal performance, while
connecting, please make sure that the air filter is present in between the connection to prevent
rust entering into the device.
Please make sure that the air valve is closed when connecting the air hose.
⑥ Suction will start as soon as the air cock is turned open on the Silent-Cleaner.
★ Peep Hole can be easily taken off for inspection.
★ When the vacuum power is low, please check for the following:
(1) If air pressure is at sufficient level, or air volume is sufficient.
(2) If the appropriate air hose is connected, not too long or too thin.
(3) Connecting with the minimum numbers of couplers, or connecting the inappropriate couplers
lead to insufficient airflow and may not be able to maintain optimal performance.
★ Feature
Silent-Cleaner has the following extraordinary feature:
● The Safety valve prevents the sudden vacuum level increase when the suction mouth
is blocked and avoids damage to the device or the drum.
● Please do not randomly adjust the safety valve to prevent any damage or danger.
★ Caution
● When the vacuum level decreases it indicates that the filters require replacement.
Fine Dust Filter
● The fine dust is caught at the cloth cover(exterior) primarily and then at the fine dust filter inside.
Please replace the fine dust filter occasionally to prevent the filter from clogging causing
excessive vacuum level at the suction area, or the dust flowing to the silent filter.
Silent Filter
● Please make sure to supply clean compressed air to prevent the silent filter from getting
clogged with rust or oil in addition to the dust discharged through the fine dust filter.
In case you have any inquiry, please contact the dealer or the manufacturer.
Silent-Cleaner SC200-50D W/F
Instructions
Please take off the fine dust filter for the liquid suction.
TEL: +81-6-6572-1207
FAX: +81-6-6572-1256
E-mail: osawa@osawa-company.co.jp
2025.02.26
