- Page 1 FIBERMASTER OPTICAL TIME DOMAIN REFLECTOMETER, POWER METER AND LIGHT SOURCE MANUAL Depend On Us Depend On Us...
-
Page 2: Table Of Contents
Contents 3.1 OTDR Handset and Ports ......... 5 5.1 Battery . - Page 3 10.2 Least Squares Approximation (LSA) ......34 10.3 Loss Measurement Settings ........34 10.4 2-Point Connector Measurements .
- Page 4 15.3 Opening a Trace ..........56 15.4 Editing Trace Information .
-
Page 5: Chapter 1 Using This Manual
Chapter 1 Using This Manual This manual contains operation information for the TREND Networks, FiberMASTER Optical Time Domain Reflectometer. This includes the standard Dual and Quad wave OTDRs. For most situations the difference between these OTDRs are the available wavelengths. - Page 6 Chapter 2 Safety The information in this chapter pertains to safety consideration of OTDRs in general. This product has been designed and tested in accordance with the manufacturer’s safety standards, and has been supplied in a safe condition. This document contains information that must be followed by the user to ensure safe operation and to maintain the product in a safe condition.
- Page 7 Chapter 2 Safety Failure to follow these cautions statements may void the warranty of, or cause damage to this equipment. Caution Fiber-optic connectors are easily contaminated or damaged. The connection to the OTDR is physical contact type of connections and dirty or damaged connectors may impair the instruments capabilities at minimum and at worst result in the need to return the OTDR to the factory for expensive repairs.
-
Page 8: Chapter 2 Inspection
Chapter 2 Inspection Before shipment, this instrument was inspected and found to be in perfect working order and free of defects. The shipping carton contains the following: 1. OTDR with Protective boot 2. Hard carry case with shoulder strap 3. USB 5 Volt charger and cable 4. -
Page 9: Chapter 3 Physical Description
Chapter 3 Physical Description 3.1 OTDR Handset and Ports Instrument Enclosure The TREND FiberMASTER OTDR is packaged in a rugged housing which is further protected with a rubberized boot. Although the front panel is weather resistant, care must be taken to avoid liquids and contaminants around the fragile optical and electrical connectors, and the glass display. -
Page 10: Chapter 4 Main Screen
Chapter 4 Main Screen This unit is equipped with a 3.5 in (8.9 cm) color TFT resistive touch display. Settings Set language, date and time View Last Trace OTDR Opens the last run trace for Configure the OTDR settings viewing and analysis and run a test Scope Power Meter/Light Source... - Page 11 Warning To Prevent Fire or Shock Hazard: Do not install battery types other than those supplied by the manufacturer. Do not use the charger without the proper batteries installed. Do not expose the battery charger to rain or excessive moisture. ...
-
Page 12: Chapter 6 Otdr Operation
Chapter 6 OTDR Operation 6.1 Entering OTDR Function ress the power button the to turn on the FiberMASTER OTDR. Touch the OTDR icon to enter the OTDR function. 6.2 OTDR Setup The OTDR menu is divided into three sections. Setup OTDR Configures the parameters used to acquire a trace. -
Page 13: Launch / Tail Cable Selection
Press Setup OTDR to configure the OTDR acquisition parameters. Several pages are available. Press the < or > button to change pages and press to accept the configuration and return to the previous screen. 6.3 Launch / Tail Cable Selection The first setup screen is the Launch/Tail cable selection. - Page 14 Measurement Without vs. With Launch and Tail Cables Without Launch/Tail cables Last connector is First connector is not Measured not measured measured Connectors Splice Connectors Patch cord (2 meter typical) With Launch/Tail cables First connector is Last connector is Measured measured measured Connectors...
-
Page 15: Wavelength Selection
6.4 Wavelength Selection Touch the desired wavelength to test. Both wavelengths can be selected to perform a dual-wavelength test which can be helpful in locating macro bends in single mode cabling. When using a quad wavelength OTDR only one mode (multi-mode or singlemode) can be selected at a time. -
Page 16: Refractive Index And End Of Fiber (Eof) Threshold
6.5 Refractive Index and End of Fiber (EOF) Threshold The Refractive Index (RI) setting calibrates the OTDR so it measures the correct length of the fiber under test. The RI setting is a ratio of the speed of light in the fiber to the speed of light in a vacuum. -
Page 17: Launch Control Warning
6.7 Launch Control Warning Launch Control Warning evaluates the reflection of the front end connector to determine whether any parameters exceed thresholds that may cause an erroneous OTDR acquisition. Enabled: Provides a warning whenever any of these criteria are met, •... -
Page 18: Averaging Time
6.8 Averaging Time Averaging time is the amount of time that the OTDR runs and captures data during the test. During the test, thousands of samples are taken and averaged together to reduce noise in the traces. Reduced noise will make it easier for the OTDR to detect low loss events such as fusion splices that may be obscured by noise when the averaging time is too short. - Page 19 as a a result the noise floor will be very high. It is recommended that high pulse widths be used to compensate for the lack of overaging and the increased noise floor. Low loss events such as high-quiality fusion splices are likely to not be visible in real-time mode, it it best used for detecting reflective events or high-loss fusion splices or splitters.
-
Page 20: Event Sensitivity
6.9 Event Sensitivity Controls the noise filter in the OTDR firmware that minimizes false events from being detected. Low = events must be very discernible from noise to be detected. Medium = some amount of noise can be in the trace and the firmware will still identify them. -
Page 21: Pulse Width
6.11 Pulse Width Pulse Width (PW) setting adjusts the amount of power the OTDR sends into the fiber with each pulse. Rather than adjusting the brightness of the laser, power is controlled by the amount of time the laser fires for each pulse. The higher the PW, the more energy is input into the fiber and the farther the OTDR can measure. - Page 22 Range vs. Pulse Width Not all pulse widths can be selected on all ranges because a short pulse cannot reach the end of very long fibers, and long pulses can be too long for short fibers. The table below shows the allowable pulse widths depending on the selected range.
-
Page 23: Limits Setup
Chapter 7 Test Limit Selection 7.1 Limits Setup The Limits setup section determines the pass/fail parameters of each test. These limits are divided into two primary groups. There are four parameters that can be checked: • Connector - loss of connectors (reflective events) •... -
Page 24: Application Limits
7.3 Application Limits After the Cabling Limits page, there are several pages of application limits. Application limits are defined by the IEEE and provide the maximum loss and length for each Ethernet speed for a given fiber type and wavelength. The application names can be decoded to determine the speed, wavelength, and fiber type. -
Page 25: Manual Limit Selection
7.4 Manual Limit Selection Press the Manual button to enter custom pass/fail limits. Page 1 contains settings for the following limits: • Connector - loss of connectors (reflective events) • Splices - loss of fusion splices (non-reflective events) • Segment attenuation slope - loss of a section of cable vs. -
Page 26: Project Manager
Chapter 8 Project Management 8.1 Project Manager Press the folder icon in the OTDR Setup screen to open Projects. The Project folder is also available in other screens throughout the user interface. It operates the same regardless where the function is initiated. Projects contains a list of user created folders that can each store measurement results for OTDR tests, power meter tests and video inspection scope images. -
Page 27: Files List
8.2 Files List Displays a list of test files in the selected project. Preceding each file name is an icon that identifies the type of file. Test selection can be performed by scrolling within the list or using the arrow buttons above and below the list. Tap to scroll the selected test up Return to project list Open selected test... - Page 28 Create a new Project Press the '+' folder button to create a new project. Enter a name for the new project using the keyboard. Letters, numbers and punctuation are allowed. Press Save to create the new project. The new project will appear in the project list and any future tests can be saved to this or any existing project.
- Page 29 Continue with testing Once a project has been selected, press Test to begin the testing process. After pressing Test, the Test Parameters confirmation screen displays the selected settings for the limits and the OTDR configuration. Press to return to the OTDR Setup screen. Press ...
-
Page 30: Otdr Result Screens
Chapter 9 OTDR Operation 9.1 OTDR Result Screens There are three views for the OTDR results, they are; Schematic, Trace, and Event Table The first view displayed after the test is run is the OTDR Schematic. The Schematic view is a linear map of the events detected by the FiberMASTER software which are classified as Launch, Splice, Connector, End, and Link. -
Page 31: Otdr Schematic Screen
9.2 OTDR Schematic Screen The schematic screen appears when the OTDR test is finished running. The schematic is a series of icons that represents events that the OTDR has analyzed from the raw trace data which are presented in an easy to understand format. An event can be activated by either tapping on it directly, or by tapping the left/right arrows to cycle through the list of events on the link. - Page 32 OTDR Schematic End Event The End event is where the OTDR detects the end of the fiber as set of the EOF setting the OTDR Setup configuration (described below). The End event displays the total distance of the link which in this example is 474.4 meters, and the reflectance of the last connector which is -26.5 dB.
-
Page 33: Otdr Trace Screen
9.3 OTDR Trace Screen Trace mode provides a classical OTDR trace that the user must interpret to find events, section losses, faults and other conditions. The appearance of the trace highly depends on the pulse width and averaging time of the test. If the trace is noisy, or there no events shown on the schematic when events are expected, try increasing the pulse width by one level. - Page 34 Central control buttons Splice Zone Setting Toggle Active Cursor When pressed (red when active), Press to change which cursor is sets the position of the four active. Cursor A is blue, cursor cursors that control the splice/ B is red. Touching the screen connector measurement zones.
-
Page 35: Event Table
9.4 Event Table Chapter 7 Fault Locator The Event Table is a view which displays the test results in event table with the schematic and a magnified view of the active event. Event Table Active event highlighted in blue Wavelength of active Fiber Map test. - Page 36 Fiber Map Range of the trace Fiber link length Red area is currently being displayed Event number Passing event Failing event is red is green Event location Reflective events Non-reflective event Note The End of Fiber is the last item in the Fiber Map view. It is labeled E in the event number position and displays a vertical bar instead of horizontal.
-
Page 37: Event Table Description
9.5 Event Table Description Event Table Field Description # Event Number: Indicates the event in sequence, where the higher the number the further distance from the OTDR the event occurs. “E” (End) which is the event determined to be the end of the fiber under test. The last column is labeled "L"... -
Page 38: Average Splice Loss
Chapter 10 Advanced OTDR Operation 10.1 Average Splice Loss The Average Splice Loss method is meant to be used on noisy traces when it is difficult to attain an LSA area that lays flat on the back scatter before and after the cursor. This method takes an average of the selected points before and after the active cursor and uses this average to make a good estimation of the event loss. - Page 39 Splice loss measurement zones The splice zones for Average and LSA measurements can be manually set in the Trace and Event Table modes. The process of setting the splice measurement zones involves positioning four cursors that define two zones. Cursor 1 and 2 define the zone to the left of the splice/connector. Cursor 3 and 4 define the zone to the right of the splice/connector.
- Page 40 Correct vs. Incorrect Splice Zone Setup Splice zones properly setup on each Splice cursor 3 is set on the reflection side of the event. The LSA lines are of the connector causing the LSA line flat on the back scatter before and on the right of the connector to not after the reflection of the connector.
-
Page 41: 2-Point Connector Measurements
10.4 2-Point Connector Measurements The 2-point measurement mode measures the total loss between cursors A and B, including the loss of all fiber, splices and connectors. This is a quick method of measuring the link loss using the OTDR trace mode. Care must be taken when using the 2-point mode to ensure the cursors are not placed on the slope of a reflective event or a noise dip/spike. -
Page 42: 2-Point Link Measurements
10.5 2-Point Link Measurements A quick way to check the link loss is to change to 2-point mode and set cursor A at the beginning of the link, just after the dead zone, and cursor B just before the end-of-fiber event. The 2-Point box will provide the loss of the total link (not including the first connector), including the two connectors and the splice in this example. -
Page 43: Slope / Orl Measurements
10.6 Slope / ORL Measurements The 2-point cursor mode can be used to measure the attenuation slope of a section of fiber. Slope is defined as the attenuation per kilometer (dB/km) of fiber. This measurement can be directly compared to the specifications of the installed cabling to check for installation stress or damage that may be causing high loss along the entire length of the cable, not just in one spot. -
Page 44: Video Inspection Probe Operation
Chapter 11 Video Inspection Probe 11.1 Video Inspection Probe Operation The video inspection probe allows magnified end-face inspection of fiber optic connectors check for contaminates or damage. Proper cleaning and end-face inspection is a critical practice each time a connector is plugged into a mating connection or piece of fiber optic equipment. Fiber optic connectors are physical contact, meaning the faces touch each other when mated. -
Page 45: Video Inspection Probe Display
11.2 Video Inspection Probe Display To operate the video scope, from the home screen, touch the Scope icon. If a probe is not connected already, connect the R-240-VIP video inspection probe to the video probe port on the top of the OTDR. -
Page 46: Video Inspection Probe Functions
11.3 Video Inspection Probe Functions Rings Used to turn on and off the rings that indicate the IEC 61300-3-35 grading zones. The rings do not need to be turned on for the automatic image grading test, they are for reference only. -
Page 47: Using The Video Inspection Probe
11.4 Using the Video Inspection Probe Centering a Connector Image Once the image is stable and focused, use the stylus to touch the approximate center of the connector to snap the image as close as possible to the center of the display and the center of the grading rings. It may be necessary to adjust the adapter tip if centering is not possible. -
Page 48: Connector Pass/Fail Criteria
11.5 Connector Pass/Fail Criteria Fiber End Face Criteria Table for Angled PC Polished Connectors Zone Description Diameter Allowable Scratches Allowable Defects (Width) (Diameter) ≤ 4 Critical Zone m to 25 None Cladding Zone m to 120 No limit No Limit < 2 5 from 2 m to 5 None >... -
Page 49: Chapter 12 Loss Test Set
Chapter 12 Loss Test Set 12.1 Loss Test Set Operation The loss test set includes two components; an optical source and an optical power meter. On FiberMASTER, the OTDR port is also the optical source used for taking power loss measurements. It can be operated in continuous wave (CW) mode, or modulated at various frequencies for use with industry standard fiber identification devices and power meters that support modulation detection. -
Page 50: Loss Test Set Display
12.2 Loss Test Set Display Press to activate open Press to open the source light source wavelength modulation options selection Current measurement reading Unit of measure Press to open power Press to open the power meter wavelength meter set reference selection options Save current... -
Page 51: Power Meter Operation
12.3 Power Meter Operation The FiberMASTER power meter can be used with any light source to measure the amount of power entering the port. When used with the OTDR light source, the power meter's wavelength is automatically set to match the output of the OTDR source. When used with other light sources, the wavelength must be set manually. -
Page 52: Light Source Operation
12.4 Light Source Operation The light source is located in the top left portion of the display. The current status is displayed, example, 1310 is displayed when the 1310 nm SM source is active, OFF is displayed when no source is active. -
Page 53: Setting A Reference Value And Testing A Cable
12.5 Setting a Reference Value and Testing a Cable When testing a cabling link for dB loss, the starting power level going into the cable under test must be known, excluding the loss of any test jumpers. This process is known as setting a reference. Failure to set the reference will result in inaccurate loss readings. - Page 54 3. Disconnect jumper 1 from the power meter. Do not disconnect the jumper from the light source once the reference has been set. 4. Connect jumper between power meter jumper using coupler. The loss value shown here is the loss of jumper 2 and coupler. Ensure that the value is less than 0.75 dB.
-
Page 55: Chapter 13 Visual Fault Locator
Chapter 13 Visual Fault Locator 13.1 VFL Safety Caution This Visual Fault Locator is classified as a Class II laser system and must be used with all commensurate safety precautions. Never view the light emanating from the fiber directly. Place a white piece of paper at the end of the fiber and look for the presence of a red spot on the paper. -
Page 56: Otdr Specifications
Chapter 14 Specifications 14.1 OTDR Specifications Wavelength 850, 1300, 1310,1550 and 1625 ±20 nm Multi-mode: 29 dB @ 850 nm, 30, dB @ 1300 nm Dynamic Range SInglemode: 37 dB @ 1310 nm, 38 dB @ 1550 nm PON: 36 dB @ 1625 nm Pulse Width 5 - 20,000 ns Units of Measurement... -
Page 57: Power Meter Specifications
14.2 Power Meter Specifications Detector Type InGaAs Connector Type 2.5mm Interchangeable Dynamic Range +5 to -77dB (CATV - +25 to -57dB) Calibrated 850, 1300, 1310, 1490, 1550, 1625 nm (standard wavelengths) Wavelengths Power Measurement ± 0.18 dB under reference conditions, ± 0.25 dB from 0 to -65 dBm, Uncertainty ±... -
Page 58: Description
Chapter 15 CertSoft 2 PC Software 15.1 Description CertSoft2 is a Windows PC software application used to transfer test files from the FiberMASTER OTDR to the PC for archival and generation of test reports. Download and install the software from www.trend-networks.com/support Requirements: •... -
Page 59: Transferring Files
16.2 Transferring Files 16.2 Transferring Files 15.2 Transferring Files Connect the OTDR to the PC using a USB cable. Verify that the OTDR connection status icon turns Connect the OTDR to the PC using a USB cable. Verify that the OTDR connection status icon turns Connect the OTDR to the PC using a USB cable. -
Page 60: Opening A Trace
15.3 Opening a Trace Double-click a file in the list to open a trace. • Double-click the same file to close the trace. • A second trace can be opened to compare two traces in the window. • The trace color matches the color of the file name in the test list. •... -
Page 61: Editing Trace Information
15.4 Editing Trace Information Information can be applied to the header for fiber(s) in the active folder. This information will appear on the printed/PDF reports. • Click the General Information box to edit the Header Information. • Update the desired information. •... -
Page 62: Adding Connector Images
15.5 Adding Connector Images A connector image from the video inspection probe can be attached to each trace file. The image will appear on the printed/PDF reports. • Click on the Connector Image tab. • Click in the box to add an image. •... -
Page 63: Adding Loss Test Set Measurements
15.6 Adding Loss Test Set Measurements Loss test sets measurements are light source/power meter measurements made with the OTDR that can be attached to a trace. • Click on the LTS Measurement tab. • Click the Link LTS File button. •... -
Page 64: Loss Test Set Mode
15.7 Loss Test Set Mode The Loss Test Set tab is used to open LTS files that are not associated with an OTDR trace. This mode is compatible with the FiberMASTER OTDR and the FiberMASTER Power Meter/Light Source test kit. •... -
Page 65: Generating Test Reports
15.8 Generating Test Reports The Loss Test Set tab is used to open LTS files that are not associated with an OTDR trace. This mode is compatible with the FiberMASTER OTDR and the FiberMASTER Power Meter/Light Source test kit. • Click on the Loss Test Set tab. -
Page 66: Updating Instrument Firmware
15.9 Updating Instrument Firmware The FiberMASTER firmware is routinely updated to add or improve functionality. Updating the firmware requires a Windows PC with an available USB port and the CertSoft2 PC software. Updating the firmware does not delete any files or settings from the OTDR. - Page 67 DO NOT DISCONNECT THE USB CABLE OR POWER OFF THE OTDR DURING THE UPDATE PROCESS. If the update process stops responding during the update: 1. Wait 5 minutes 2. Power OFF the OTDR 3. Disconnect the USB cable 4. Clear any warnings on CertSoft2 5.
- Page 68 Stokenchurch, High Wycombe, Bucks, HP14 3SX, United Kingdom Tel. +44 (0)1925 428 380 Specification subject to change without notice. E&OE uksales@trend-networks.com © TREND NETWORKS LIMITED 2022 TREND Networks and FiberMASTER are www.trend-networks.com Publication no.: 240812 Rev 1. registered trademarks of TREND Networks.
