  • Page 1 Hardware Manual of SMH-35/35-100-M 匯出日期：2025-02-16 修改日期：2021-04-19...
  • Page 2 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Revision Table Document Content •...
  • Page 3 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M  – 3...
  • Page 4 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 1 Preface       Thank you for your continued support of our products. Our servo team is forever committed to the research and development of new products;...
  • Page 5 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 2 Application This manual is only applicable to Syntec SMH-35/35-100-M Multi-Axis Servo Drive...

  • Page 6: Hardware Specification

    伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 3 Hardware Specification 3.1 Description Each drive undergoes strict quality inspection and anti-collision packaging before leaving the factory.
  • Page 7 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Item Module Description Drive Function...

  • Page 8: Specification

    伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Item Module Description I/O Signal Port Connects to I/O equipment (emergency stop, warning light…etc.)
  • Page 9 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Output Rated Axis1~Axis2: 8.4 A, Axis3: 27 A...
  • Page 10 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Weight 9.5 kg Hardware Specification – 10...
  • Page 11 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 4 Transportation and Installation 4.1 Transportation The entire body of the drive must be held during transportation.
  • Page 12 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M • Do not drop or impact the drive.
  • Page 13 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 5 Wiring and Signal 5.1 Wiring Diagram SMH-35/35-100-M ※Recommended encoder wiring: 22AWG×2C+24AWG×2P...
  • Page 14 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M ※Recommended UVW wiring: Axial: 14AWG or 2.0mm  ...
  • Page 15 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 2 Safety inputs (STO-A, STO-B)

  • Page 16: Connector Pin Define

                                 –                              Hardware Manual of SMH-35/35-100-M a signal line with twice the wire diameter in order to minimize signal attenuation.
  • Page 17 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Name Description Differential Signal (+)
  • Page 18 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M USB Differential Signal (+) Power Reference GND...
  • Page 19 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Name Description Differential Signal (+)
  • Page 20                              –                              Hardware Manual of SMH-35/35-100-M 5.4.2 Syntec Encoder External Analogy Temperature Wiring Diagram...
  • Page 21 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M • On the label of KTY84 temperature sensor signal line, "KTY84" is labelled right underneath "Thermal Protection,"...
  • Page 22 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M 5.4.3 Multi-drives Serial Wiring Guide Like OpenDrive, this 3-in-1 drive has the multi-drive serial function, as follows: The drives of the Multi-axis Servo Drive series has a multi-drive serial function, activated by using an M3 cable to...
  • Page 23                              –                              Hardware Manual of SMH-35/35-100-M The DIP switch has four PINs, where each PIN has the two states ON and OFF. The switch can therefore represent 16 distinct station numbers, as shown in the table below.
  • Page 24                              –                              Hardware Manual of SMH-35/35-100-M The controller's corresponding axis number should be set in the form MMnn: MM denotes the main station number, or the DIP switch's corresponding station number, which can be obtained from the table in the last section above or from Pn-031 of the tuning software;...
  • Page 25 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Drive Model No. Internal Regenerator...
  • Page 26 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Resistor Type Wirewound  Ripple  Aaluminum-Housed...
  • Page 27                              –                              Hardware Manual of SMH-35/35-100-M       In addition, according to the application of the spindle cover, the allowable frequency index is provided for the user to select.
  • Page 28 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Drive Model Milling Rotor Rotor...
  • Page 29 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M S08-SP-L5.5-12 Resistor Power  Allowable Frequency (times/min)
  • Page 30 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Resistor Power  Allowable Frequency (times/min) Operating Speed 2 Times the Rated Speed...
  • Page 31 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Resistor Power  Allowable Frequency (times/min) Operating Speed...
  • Page 32 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Resistor Power Allowable Frequency of the Motor's External Regenerator under 2 Inertia Ratio (N)

  • Page 33: Installation

    伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Resistor Power Allowable Frequency of the Motor's External Regenerator under 2 Times the Inertia Ratio (N)
  • Page 34 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Pn-744 Encoder Ext.(2) KTY84 Protection Lv.
  • Page 35 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Alarm 220 Motor Over Temperature...
  • Page 36 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Pn-D61 Measured Temperature via Feedback Syntec Encoder Internal KTY84...
  • Page 37 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M   Reconnect the brass strips to the U, V, W terminals; the resulting Connector Delta circuit is represented by the diagram on the right.
  • Page 38 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M   Click on "Open File" and select the Syntec package parameter file for Connector Delta. Parameter files with "wye" in the file name are for Connector Y, and those with "delta"...
  • Page 39                              –                              Hardware Manual of SMH-35/35-100-M After successfully importing the parameters, the parameters "Pn-710 Rated Current," "Pn-712 Rated Voltage for Induction Motor,"...
  • Page 40 伺服產品/Servo Products                              –                              Hardware Manual of SMH-35/35-100-M Pn-712 Rated Voltage for Induction R2 /1.732...
