PCB Piezotronics IMI SENSORS ICP M601A92 Installation And Operating Manual page 18

Model Number
601A92
Performance
Sensitivity(± 20 %)
Measurement Range
Frequency Range(± 5 %) 28 to 240,000 cpm
Frequency Range(± 10 %) 20 to 300,000 cpm
Frequency Range(± 3 dB) 10 to 480,000 cpm
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material 316L Stainless Steel
Sealing
Electrical Connector
Electrical Connection Position
[6]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
INDUSTRIAL ICP® ACCELEROMETER
EN GLISH SI
500 mV/g 51 mV/(m/s²)
± 10 g ± 98 m/s²
0.47 to 4,000 Hz
0.33 to 5,000 Hz
0.17 to 8,000 Hz
960 kcpm 16 kHz
2
35 µg
343 µm/sec
± 1 % ± 1 %
≤ 7 % ≤ 7 %
5,000 g pk 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
IP68, IP69K IP68, IP69K
≤ 10 sec ≤ 10 sec
≥ 1.0 sec ≥ 1.0 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
< 150 Ohm < 150 Ohm
8 to 12 VDC 8 to 12 VDC
3 µg/√Hz 2
29.4 (µm/sec )/√Hz
2
0.7 µg/√Hz
6.9 (µm/sec )/√Hz
2
0.5 µg/√Hz
4.9 (µm/sec )/√Hz
8 8
> 10 Ohm > 10 Ohm
7/8 in x 1.82 in 22.2 mm x 46.3 mm
2.8 oz 80 gm
1/4-28 Female No Metric Equivalent
2 to 5 ft-lb 2.7 to 6.8 Nm
Ceramic Ceramic
Shear Shear
316L Stainless Steel
Welded Hermetic Welded Hermetic
4-Pin, M12 4-Pin, M12
Top Top
Optional versions have identical specifications and accessories as listed for the standard model except
[1]
where noted below. More than one option may be used.
[2] - Metric Mount
M
Supplied Accessory: Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1) replaces Model 081A40
[3]
[3]
[4]
[3]
[3]
[3]
[3]
[5]
N OTES:
[1]Conversion Factor 1g = 9.81 m/s².
[2]The high frequency tolerance is accurate within ±10% of the specified frequency.
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]1/4-28 has no equivalent in S.I. units.
[6]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Model ICS-2 NIST-traceable single-point amplitude response calibration at 6000 cpm (100 Hz) for
each axis (1)
Entered: ND Engineer: NJF
Date: 12/19/2024 Date: 12/19/2024 Date: 12/19/2024 Date: 12/19/2024 62202
3425 Walden Avenue, Depew, NY 14043
Revision: D
ECN #: 55435
OPTION AL VERSION S
Sales: EGY Approved: NJF Spec Number:
Phone: 800-959-4464
Fax: 716-684-3823
E-M ail: imi@ pcb.com
