- Page 1 DUKA ONE PRO 50 S User manual DUKA One Pro 50 S Ventilation Unit with Heat Recovery...
- Page 2 Indhold Information og Sikkerhed Garantibestemmelser Indhold i kassen Teknisk Information Opbygning Teknisk Data Dimensioner Montage El tilslutning Sammenkobling af enheder Indstillinger Betjening Vedligehold Fejl og problemløsning...
-
Page 3: Information And Safety
Information and Safety Transport and Storage The unit must be protected from shocks, impacts, and weather conditions during transport. Store the unit in its original packaging in a dry and ventilated room at temperatures between 5°C and 40°C. The storage room must not contain aggressive or chemical vapors or gases. Do not expose the stored unit to pressure or other loads. -
Page 4: Warranty Conditions
An additional 12-month warranty is provided if transport, storage, use, installation, operation, maintenance, and warranty conditions are followed. To maintain the warranty, filters must be replaced at least once per year with original DUKA Ventilation filters. (Keep receipts as proof.) The Warranty Does NOT Cover: Routine maintenance. -
Page 5: Technical Information
Technical Information Designed for indoor use at 1°C to 40°C, with up to 80% relative humidity. Air supply and exhaust range: -15°C to 40°C. Must operate continuously. Electrical Classification Class II IP Rating: IP 24 Structure The unit consists of: Front cover: Removable for servicing. -
Page 6: Technical Data
Technical Data DUK A ONE PRO 50 S Speed Voltage [V/Hz] 100-240V ~50/60 Hz Power [W] Current [A] 0,012 0,025 0,045 Air flow in ventilation mode [m3/h] Air flow in heat recover y [m3/h] 17,5 M2 v. 0,3 l/s Transpor ted air temperature [ºC] -15 ... - Page 7 Outer Hood Minimum wall thikness and placement Is the wall thickness below the minimum requirement is it recommended to purchase a DUKA One distance piece Placement of the ceramic core according to wall thickness. DUK A One Pro 50 S Wi-Fi...
-
Page 8: Installation
Installation 1 - Determine the location and drill the hole through the wall. Before placing the unit, minimum distances to the side wall, ceiling and any windows must be taken into account. The minimum distances are showed on the drawing. Also remenber to take into account the power supply for the unit when choosing a location. - Page 9 4 - Disassemble the front cover by pressing on the two buttons 5 - Install the electronic part with the supplied screws and disassemble the right cover plate. 6 - Connect the wires according to the wiring diagram and place them as shown below. Remember to place the wires in the clamps.
- Page 10 7 - After the unit has been connected to the power supply assemble the cover plate again. 8 - Install the core Install the core and connect it to the electronic part with the green plug. 9 - Install the silencer Place the silencer in the pipe an roll it to make sure it fits the diameter of the pipe.
- Page 11 11 - Remove the front cover on the outer hood before installing it. 12 - Install the outer hood and the drop plate. The supplied drop plate is installed on the back side of the outer hood as shown on the image to the right. The drop plate ensures that condensation water is lead away from the wall.
-
Page 12: Connection To Power Mains
Connection to power mains ALL CONNECTIONS TO POWER MAINS MUST BE DONE BY A CERTIFIED ELECTRICIAN. CONNECTION THAT HAVE BEEN MODIFIED OR ARE ILLEGAL WILL DISCONTINUE THE PRODUCT WARRANTY. NOTE: AS A PRIVATE PERSON IT IS ILLEGAL TO CARRY OUT A PERMANENT ELECTRICAL INSTALLATION. LEARN MORE AT THE DANISH SAFETY GOVERNMENT WWW.SIK.DK The unit must be connected to a single-phase AC 100-230 v / 50-60 Hz power supply. - Page 13 Connecting Multiple Units When multiple units are linked in a master/slave setup, they will operate in sync, ensuring balanced ventilation throughout the home. It is recommended to use a 0.25 mm² cable for the connection, and the cable length should not exceed 200 meters between units. It is not possible to have multiple master units within the same connection.
- Page 14 Settings Before starting the DUKA One unit, the operating settings must be adjusted to suit individual needs. This is done via the DIP switches located under the DIP switch cover. Standby settings ON - The unit cannot be turned off and will operating on level 1 in standby mode OFF - the unit can be turned off and put in standby mode.
-
Page 15: Operation
Operation Operation of the unit via buttons on the inner part FUNCTION Level setting: Level I – II – III or standby If the indicator shines the unit is operating at level I. If the indicator flashes night mode activated. I and II : If indicator I and II shines the unit is operating at level II. - Page 16 Operation of the unit with remote control FUNCTION Turn on or standby Will either turn on the unit or put it on standby unless this function have been deactivated via the DIP-switches, see more under the “Settings” section. Air speed level Level III - II - I Heat recovery The unit is operating 70 seconds in air supply mode and thereafter 70 seconds in air extraction mode.
-
Page 17: Maintenance
MAINTENANCE TASKS ON THE UNIT. A DUKA One unit must be inspected and maintained at least every three months. There may be conditions under which it is necessary to check the unit more often, e.g. in a dusty, dirty or humid environment. During maintenance the core must be removed. The ceramic core and silencer must cleaned and the filters must either be cleaned or replaced. - Page 18 The filters must be inspected at least every three months, where they either must be cleaned or replaced. The filters must be replaced with original filters from DUKA Ventilation at least once per year. It may happen that the unit is installed in an environment where a shorter interval between maintenance is required. This could be, for example, in a dusty, dirty or humid environment.
-
Page 19: Troubleshooting
Troubleshooting PROBLEM POSSIBLE ERRORS ERROR CORRECTION • Make sure the unit is connected to a power source and the power No power connection is turned on. Alternatively make sure the unit is correctly connect- The unit does not start • Power of the unit Fan is blocked or is encountering resistance •... - Page 20 DUKA ONE dukaventilation.dk...
