Speedata J-COM SD60PRT Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

SD60PRT
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J-COM SD60PRT and is the answer not in the manual?

Questions and answers

Related Manuals for Speedata J-COM SD60PRT

Summary of Contents for Speedata J-COM SD60PRT

  • Page 1 SD60PRT Quick Start Guide...
  • Page 2 SD60PRT Quick start guide V1.0 Appearance SIM Card 1 Both SIM cards use standard Nano-SIM cards. Please use professional equipment to open the SIM card warehouse, so as not to damage the equipment and affect the protection performance. 2 When the SIM1 card is placed, the SIM1 card is placed horizontally in the upper right corner of the second layer of the slot, which is flat with the slot, and the SIM1 card is successfully placed.

  • Page 3: Wifi & Network

    SD60PRT Quick start guide V1.0 5 Double PSAM Intelligent Encryption Card. WIFI & Network Connect to a Wi-Fi network 1 Swipe down from the status bar to open the notification panel. 2 Press to enter the WLAN settings interface. 3 Turn on the WLAN switch. The system will list the detected WLAN networks in tabular form.
  • Page 4 SD60PRT Quick start guide V1.0 Scan Sound:After the barcode scanning is finished, the tone will sound. Scan Vibrate:Vibration alert after barcode scanning. Save Image:Save the barcode picture to album. Scan mode:The device has a built-in three-minute scan mode. Select the fast scan mode you are used to.
  • Page 5 SD60PRT Quick start guide V1.0 Continuous Scan Internal:Setting the continuous Scan Internal(ms). Attached key value: Special keys are added after the barcode output, such as "Enter" and "Line Feed". With table With enter Add custom prefix: add custom characters, numbers, letters, etc. before the barcode output (add "#"...
  • Page 6 SD60PRT Quick start guide V1.0 Choose code-1d-EAN-13-Enable such as the scan result after scanning "EAN-13" barcode, one less. You can select "EAN-13" type, enable "Check transmit Digit", and scan later the results show normal. Example1:EAN-13 barcode:6456813472345;When the "Check transmit Digit"not enabled,the result show 645681347234 ;and when the "Check transmit Digit"...
  • Page 7 SD60PRT Quick start guide V1.0 Example1:UPC-A barcode:123456789012;When the "Check transmit Digit"not enabled,the result show 12345678901,and when the "Check transmit Digit" is enable,the result show 123456789012. Choose code-1d-Code39-Enable such as the scan result after scanning "Code39" barcode, one less. You can select "Code39" type, enable "Transmit Start/Stop Characters ", and scan later the results show normal.
  • Page 8 SD60PRT Quick start guide V1.0 Click "Settings"-"Scan" to slide to the bottom, and click "More". Show scan hand type.And can check update after connecting to Check update: the internet. Note: "Check update"requires the scanning service version 5. 1 or higher. This is used to set a custom broadcast.

  • Page 9: Printer Settings

    SD60PRT Quick start guide V1.0 Printer Settings Basic setting Swipe up on the home screen,and find”JXPrintDemo”iron ,click to enter the application interface. Note:The ”JXPrintDemo”is installed by default on the device.If you cannot find the relevant application,please contact technical support. Connect Printer Click “CONNECT PRINTER”on the main interface to start printing;You can click “DISCONNECT PRINTER”on the main interface to stop printing.
  • Page 10 SD60PRT Quick start guide V1.0 Paper type Page 10...
  • Page 11 SD60PRT Quick start guide V1.0 This setting item can select paper type(thermal paper,label paper),click “SET” to save after modification. Note:Paper specification:paper roll diameter=40mm\paper width=57mm,paper that does not exceed this parameter can be used. Density This setting item can set the density of the printed image,the maximum density is 5,but for different types of paper,it is necessary to adapt,not necessarily the maximum density will be the best effect.
  • Page 12 SD60PRT Quick start guide V1.0 This setting can control the printer for paper back operation. Printer self-check page This setting can print a test page to determine whether the printer is functioning normally and related firmware information. Start fatigue test This setting can test the compatibility of the hardware and the stability of the device by allowing the printer to print uninterruptedly.This is a performance stability test item for the manufacture and is not recommended for customer.
  • Page 13 SD60PRT Quick start guide V1.0 Start printing Text printing Receipt printing example Click “receipt printing example” to print example receipt. Code page printing Click”code page printing”to enter the code selection interface,after selecting the code type,you can print the example code page. Page 13...
  • Page 14 SD60PRT Quick start guide V1.0 Table printing example Click”table printing example”to print example table. Custom text printing Enter the text you want print in the “edit the text”,and click “SEND PRINT”to print the content of the “edit the text”. Page 14...
  • Page 15 SD60PRT Quick start guide V1.0 Barcode printing Page 15...
  • Page 16 SD60PRT Quick start guide V1.0 1D code printing Click “1D code printing” to print 1D code. QR code printing Click “QR code printing” to print QR code. Scan printing Click “scan printing” ,Put the QR code into the camera frame and it will be automatically scanned and printed.
  • Page 17 SD60PRT Quick start guide V1.0 Click to select the type of 1D code Click to edit barcode content Click to print barcode Custom QR code printing Click to edit barcode Click to select content the type of QR code Click to print barcode Page 17...
  • Page 18 SD60PRT Quick start guide V1.0 Picture printing The text can be printed out in the form of pictures. Click to print the preset binary diagram. Click to choose picture print locally. Charging & attention Please use the supplied charger and USB (Type-C) cable. Otherwise, the fast charging mode cannot be enabled.
  • Page 19 SD60PRT Quick start guide V1.0 case of damage to the battery, charging head and charging cable, please contact us in time to purchase, do not repair it yourself, so as to avoid danger and cause extra loss. Page 19...

  • Page 20: Product Parameters

    SD60PRT Quick start guide V1.0 Product parameters Size 174*82*35mm Weight About 460g (with battery) (Note: Differences in different functional modules will cause actual weight differences, please refer to the actual product.) IP Code IP65 Color Black Screen Size: 6 inches, 18：9 Resolution 1080 * 2160 Type: IPS...
  • Page 21 SD60PRT Quick start guide V1.0 Camera Rear camera : 1300MP，AF Front camera : 500MP，FF WWAN Dual SIM dual standby single pass, support for Nano SIM card FDD-LTE： B1/B3/B5/B7/B8 TDD-LTE： B38/B39/B40/B41 TDSCDMA： B34/B39 WCDMA： B1/B2/B5/B8 GSM： B2/B3/B5/B8 CDMA：1x/CDMA2000 BC0/BC1 Data connect WI-FI: 802.
  • Page 22 SD60PRT Quick start guide V1.0 PDF417、 QR Code、Data Matrix、etc. Standard Range (SR) Optics Typical Range* Symbology/X-Dim mm – 419 mm (1.8” – 16.5”) 64 100% U.P.C mm - 163 mm (2.5" - 6.4") mil Code 39 mil Code 39 mm – 338 mm (1.1” – 13.3”) mill PDF 417 mm - 185 mm (1.8"...
  • Page 23 SD60PRT Quick start guide V1.0 Beijing Headquarters: Office 01-2 08, Block D, 8 / F, Building 1-4, Yard A, 18 Zhongguancun South Street, Haidian District, Beijing,China,100085 Shenzhen Office 2nd Floor, Building 4, Jinyuan Technological Zone, Banli Avenue, Longgang District, Shenzhen, China, 518129 Page 23...
