Included Hardware:
1. Qty 2: Locking screws
2.
Qty 4: Driver Moun>ng Bolts
Tools Needed: Phillips Screwdriver (Not Included)
The HLG Tomahawk is folded within the packing box.
Locate the PEM set locking holes on the rails of the HLG
01/21/2025
Unfolding and Assembly of the HLG Tomahawk
Tomahawk.
HLG Tomahawk
Assembly Instruc/ons
Remove lamp and unfold it face down on a level
Using a Phillips screwdriver insert the two locking
screws in the PEM sets. Tighten each nut completely
to secure the lamp open.
surface
1
Advertisement
Related Manuals for Horticulture Lighting Group Tomahawk
Summary of Contents for Horticulture Lighting Group Tomahawk
- Page 1 Qty 4: Driver Moun>ng Bolts Tools Needed: Phillips Screwdriver (Not Included) Unfolding and Assembly of the HLG Tomahawk The HLG Tomahawk is folded within the packing box. Remove lamp and unfold it face down on a level surface Locate the PEM set locking holes on the rails of the HLG Using a Phillips screwdriver insert the two locking Tomahawk.
- Page 2 Moun;ng the Driver on the HLG Tomahawk Locate the driver mounIng PEM sets inside the rail of the Using a Phillips head screwdriver, insert the four Tomahawk. Align the driver channels with the PEM sets. driver mounIng bolts (3) and Ighten to secure the driver.
