Royale S13279 User Manual

User Manual
Royale Medical Transfer
Bench Swivel & Sliding
SKU
Overall Width
Overall Depth
Seat Width
Width Between Arms
Seat Height
Armrest Height
Weight
Safe Work Load (SWL)
Independent Living Specialists
S13279
84cm
52cm
40cm
51cm
50-60cm
12cm
7kg
130kg
1
Royale Medical Transfer Bench Swivel & Sliding Manual
Safety & Precautions
User Safety: It is recommended that the below safety checks are completed
prior to each use:
• All locking pins must be fully protruding.
• Adjusted to appropriate height for user.
• Legs are in a secure position with anti-slip rubber tips attached.
• Weight on chair does not exceed safe work load.
Weight Capacity: the maximum safety weight limit for the product is 130kg.
If the maximum safety weight limit is exceeded, this can increase the risk of
damage to the product and/or risk of serious injury to the user and others.
Instructions for Use
Product Assembly
1. Remove contents from packaging.
2. Insert backrest into holes on rear of the bench by pressing down
on the locking pin.
3. Insert armrest onto the right hand side by pressing down on the
locking pin.
4. Attach all four legs by sliding leg component into main frame receiver
until the locking pin is secured and protruding at the appropriate
height for the user.
5. Ensure legs are stable and secure.
Adjusting the Height
1. Push locking pin in and slide internal leg up or down to the appropriate
height. Ensure all locking pins are fully protruding prior to use.
2. Please note that one leg has additional holes, to assist with stabilising
product on uneven floors.
Independent Living Specialists
2
