Flex FXA6151 Operator's Manual

24v brushless mixer
Hide thumbs

Advertisement

Table of Contents

OPERATOR'S MANUAL
Model:
FXA6151
24V BRUSHLESS MIXER
WARNING: To reduce the risk of injury, the user must read and understand the
Owner's Manual before using this product. Save these instructions for future reference.
Please contact FLEX customer service in Australia 1300 000 346 or
New Zealand 0508 000 346 any time you have questions or warranty claims.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FXA6151 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flex FXA6151

  • Page 1 WARNING: To reduce the risk of injury, the user must read and understand the Owner’s Manual before using this product. Save these instructions for future reference. Please contact FLEX customer service in Australia 1300 000 346 or New Zealand 0508 000 346 any time you have questions or warranty claims.

  • Page 2: Safety Symbols

    SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 3: General Power Tool Safety Warnings

    GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings, instructions, illustrations and specifications WARNING provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. The term “power tool”...
  • Page 4 Power tool use and care Battery tool use and care Do not force the power tool. Use the correct Recharge only with the charger specified by power tool for your application. The correct the manufacturer. A charger that is suitable for power tool will do the job better and safer at the one type of battery pack may create a risk of fire rate for which it was designed.
  • Page 5 SAFETY WARNINGS FOR MIXER Do not process explosive materials (e.g. Hold the tool with both hands at the highly inflammable solvents). Power tools intended handles. Loss of control can cause generate sparks that could ignite the vapor personal injury. given off. Ensure sufficient ventilation when mixing Have the power tool checked by customer flammable materials to avoid a hazardous...
  • Page 6 SYMBOLS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. Symbol Name Designation/Explanation Volts Voltage Amperes Current Hertz...
  • Page 7 Symbol Name Designation/Explanation Wear eye protection symbol Alerts user to wear eye protection This product complies with applicable Regulatory compliance mark Australian standards.

  • Page 8: Functional Description And Specifications

    Gear Head Button Spindle Mixer Paddle (Not Included) Gear Selector Switch Open-end Wrench Model no. FXA6151 Rated voltage 24 V d.c. – 1st gear 0~210/0~325/0~530 /min (RPM) No load speed – 2nd gear 0~320/0~490/0~780 /min (RPM) Tool capacity Max. mixer paddle diameter...
  • Page 9 For use with mixer paddles and accessories which are indicated in these instructions or • recommended by the manufacturer. The mixer is not to be used for mixing foodstuffs. Using accessories not designed for this tool can cause serious injury. WARNING ASSEMBLY Depress the battery-release button located...
  • Page 10 ADJUSTMENTS GEAR SELECTOR (FIG. 5) "I" – Low gear with higher torque NOTICE: Change gears only when the motor "II" – High gear with higher speed is off. " " - Spindle lock for changing mixer paddle Press the gear-selector release button (1) and turn the gear selector counterclockwise to the desired gear setting –...
  • Page 11 Use tool. of this product with damaged or missing parts This Mixer must be used only with the FLEX could result in serious personal injury. 24V series battery packs and chargers NOTICE: Please refer to the battery pack and charger manuals for detailed operating information.
  • Page 12 OPERATING (FIG. 9) Fig. 9 a. Only turn on the tool after the mixer paddle has been immersed in the product to be mixed. When doing this, slowly press the switch and wait until the tool has reached maximum speed. b.

  • Page 13: Maintenance

    We recommend that all tool service be plastic parts. Some of these are: gasoline, performed by a FLEX Factory Service Centre or carbon tetrachloride, chlorinated cleaning Authorized FLEX Service Station. solvents, ammonia and household detergents that contain ammonia.

  • Page 14: Warranty Statement

    If the Customer registers its purchase of the Product online at www.flex-tools.com.au or by calling • 1300 000 346 in Australia or www.flex-tools.co.nz or by calling 0508 000 346 in New Zealand within 30 days of the date of its purchase (Registration), the Warranty Period for the following Products is as follows: FLEX 24V Tools: 5 years;...

  • Page 15: Warranty Claims

    The Warranty does not apply if: a) the Product is not supplied in its final shape and form by Chervon or an authorised FLEX Dealer, which can be confirmed on the website store locator (for avoidance of doubt, third party online stores such as eBay, Gumtree, Amazon, etc.
  • Page 16 *Original purchaser must register the product(s) within 30 days of purchase and retain their receipt as proof of purchase. This warranty applies only to the original purchaser from an authorised FLEX dealer and may not be transferred. If original purchaser does not register their product within 30 days, the warranty will apply for the duration set out in table above in column ‘LIMITED...
