USER MANUAL

GEARBOX WASHER

IMPORTANT SAFETY INSTRUCTIONS

Before using this product, please read this user manual, if you do not understand any of the instructions within, please do not use

the product and consult your retailers or the manufacturer. Failure to follow these instructions may result in damage to the product,

property and/or cause personal injury to the user or bystanders.

Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use or

subsequent owners. Apart from the notes contained herein the general safety provisions and rules for the prevention of accidents of

the legislator must be observed.

JEFWASPGR090HP-DL

v.1.1

JEFFERSON

JEFWASPGR090HP-DL

www.jeffersontools.com

JEFWASPGR130HP-PT

Need help?

Do you have a question about the JEFWASPGR090HP-DL and is the answer not in the manual?

Questions and answers

Summary of Contents for Jefferson JEFWASPGR090HP-DL

Page 1 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 JEFFERSON GEARBOX WASHER JEFWASPGR090HP-DL JEFWASPGR130HP-PT IMPORTANT SAFETY INSTRUCTIONS Before using this product, please read this user manual, if you do not understand any of the instructions within, please do not use the product and consult your retailers or the manufacturer. Failure to follow these instructions may result in damage to the product, property and/or cause personal injury to the user or bystanders.
Page 2 IMPORTANT SAFETY INSTRUCTIONS AND GUIDELINES WARNING- Read and follow all instructions. Failure to follow all instructions in this manual may result in severe personal injury or death. Keep this manual and refer to it for Safety Instructions, Operating Procedures, and Warranty. This manual contains information that is important for you to know and understand.
Page 3 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 IMPORTANT SAFETY INSTRUCTIONS AND GUIDELINES CONT. WARNING - Risk of fall hazard • Use of pressure washer can create puddles and slippery surfaces. • Kickback from spray gun can cause you to fall. Keep the area of operation clear of all persons,particularly small children,pets and obstacles.
Page 4 IMPORTANT SAFETY INSTRUCTIONS AND GUIDELINES DANGER - Risk of hot surfaces • Contact with hot surfaces, such as engines exhaust components, could result in serious burn. During operation,touch only the control surfaces of the pressure washer. Keep children away from the pressure washer at all times. They may not be able to recognize the hazards of this product.
Page 5 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Parts Identification and Features www.jeffersontools.com...
Page 6 Parts Identification and Features Triplex Pump Gear-reduction Box www.jeffersontools.com...
Page 7 USER MANUAL JEFWASPGR090HP-DL JEFWASPGR130HP-PT v.1.1 Parts Identification and Features Petrol Engine Diesel Engine www.jeffersontools.com...
Page 8 Parts Identification and Features General Technology PSI: Pounds per square inch - common unit measure used for water pressure,air pressure, hydraulic pressure and pounds of force GPM: Gallons per minute (litres per minute [metric]) - common unit measure used for flow rate of water. Bypass Mode: In bypass mode,high pressure pump recirculates water because spray gun trigger is not pulled.
Page 9 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Unpacking and Assembly 7.Assembly the Mounting Base Put the two base onto the plate as shown,insert the bolt,put the nut on and tighten. 8.Put the Hose Reel Onto the Frame. Pull the Locking Pin out,put the hose reel inside the base and place under the hooker, alignment the locking hole and put back the locking pin to lock the hose reel in place.
Page 10 Setting Up Before Use (Petrol Engine) Add Oil To The Petrol Engine 1.Place pressure washer on a flat, level surface. 2.Clean area around oil fill and remove yellow oil fill cap. 3.Using oil funnel (optional),slowly pour contents of provided oil bottle into oil fill opening. 4.Replace oil fill cap and fully tighten.
Page 11 USER MANUAL JEFWASPGR090HP-DL JEFWASPGR130HP-PT v.1.1 Setting Up Before Use (Diesel Engine) Notice! Improper treatment of pressure washer can damage it and shorten its life. DO NOT attempt to crank or start the engine before it has been properly serviced with the recommended oil.
Page 12 Setting Up Before Use (Diesel Engine) cont. Attaching The Other Side Of The Connection Hose To Reel. Similarly, attach other end of connection hose to water inlet on the hose reel. Pull down on collar of quick connect, slide onto hose reel inlet and let go of collar. Pull on hose to be sure of tight connection.
Page 13 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Setting Up Before Use (Diesel Engine) cont. Connecting Spray Wand to Spray Gun Thread spray wand onto spray gun Connect Hose and Water Supply to Pump Similarly, attach other end of high pressure hose to high pressure outlet on pump. Pull down on collar of quick connect, slide onto pump and let go of collar.
Page 14 Safe Working Environment Pressure Washer Location Clearances and Air Movement WARNING! Exhaust heat / gases can ignite combustibles, structures or damage fuel tank causing a fire. Keep at least 5 ft. (1.5m) clearance on all sides of pressure washer including overhead. Place pressure washer in a well ventilated area, which will allow for removal of deadly exhaust gas.
Page 15 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Start up and Stopping Procedure (Petrol Engine) How to Start Your Pressure Washer To start your pressure washer for the first time, follow these instructions step-by-step. It is also applies if you have let the pressure washer sit idle for at least a day.
Page 16 Start up and Stopping Procedure (Diesel Engine) How to Start Your Pressure Washer 1. Place pressure washer near an outside water source capable of 2. Rotate fuel valve to “On” position 3. Turn the engine speed control knob (A) to the left (B). Slide the engine speed control knob to the START position (C).
Page 17 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Using Nozzles Attaching Pressure Nozzles to Spray Wand 1. Engage trigger lock on spray gun. 2. Pull slip ring on female quick-disconnect fitting of spray wand back. 3. Insert nozzle into female quick-disconnect socket on spray wand.
Page 18 Adjusting Spray Pressure Pressure Rinsing 1. Remove black spray tip from nozzle extension. 2. Select and install desired high pressure spray tip. 3. Keep spray gun a safe distance from area you plan to spray. 4. Increase (decrease) spray pressure by turning pressure control knob clockwise (counter-clockwise).
Page 19 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Maintenance To ensure efficient operation and longer life of your pressure washer a routine maintenance schedule should be prepared and followed. If the equipment is used in unusual conditions such as high-temperature or dusty conditions more frequent maintenance checks will be required.
Page 20: Task Description
Maintenance Schedual (Petrol Engine) Item: Task Description Each Each Every 6 Every Month Season Months Year 20hrs 50Hrs 100hrs 300hrs Engine Oil: Oil Level Check Replace Reduction Gear Oil Oil Level Check (If Applicable) Replace Air Cleaner Filter Check Clean Replace Deposit Cup Clean...
Page 21 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Storage cont Preparation for Winter and Long-term Storage Note: It is recommended that you follow these steps to protect the internal seals of the pump when storing the equipment for more than 30 days and or when, freezing temperatures are expected.
Page 22 Trouble shooting www.jeffersontools.com...
Page 23 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Trouble shooting www.jeffersontools.com...
Page 24 Pressure Washer Exploded View & Parts List No. Description No. Description Nut,Axle Handle Wheel Hose Reel ASSY Axle Washer D8 Nut M8 Bolt M8x16 Anti-Vibration Feet M10x20 Frame Battery 12V/20AH Pump Bracket Nut M8 High Pressure Pump Washer D8 Bolt M8x25 Engine Bolt M8x45 Locking Pin M10x25...
Page 25 USER MANUAL JEFWASPGR090HP-DL JEFWASPGR130HP-PT v.1.1 Triplex Pump Exploded View & Parts List DESCRIPTION DESCRIPTION DESCRIPTION Bolt, crankcase cover Locating ring Gasket, unloader valve housing O-ring, locating ring Detergent injector fitting Oil drain plug O-ring, oil drain plug Low pressure water seal...
Page 26 Gearbox Exploded View & Parts List NO. DESCRIPTION NO. DESCRIPTION NO. DESCRIPTION 1. Gearbox Case 8. Snap Ring D40 15. 0-ring 55.25*2.62 2. Oil Plug 9. Ball Bearing 6008 16. Gearbox Cover 3. 0-ring 14.2*1.9 10. Snap Ring D68 17. Gasket Cover 4.
Page 27 JEFWASPGR090HP-DL JEFWASPGR130HP-PT v.1.1 EC Declaration of Conformity We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer, declare that the following equipment conforms to the requirements of the following: JEFWASPGR130HP-PT 2014/30/EU Electromagnetic Compatibility Directive EN 55012:2007+A1:2009...
Page 28 JEFWASPGR090HP-DL JEFWASPGR130HP-PT USER MANUAL v.1.1 Jefferson Professional Tools & Equipment 24 Lisgorgan Lane, Upperlands, BT46 5TE Tel: +44 (0)1244 646 048 (UK) +353 (0)1473 0300 (ROI) Email: info@jeffersontools.com www.jeffersontools.com...
