Summary of Contents for Panasonic 4414 E
- Page 1 4414 E ADDRESS SETTING TOOL Fire alarm solutions technical description www.panasonic-fire-security.com...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ABBREVIATIONS GENERAL DESCRIPTION 3.1. TOOL 3.1.1. CONNECTION CABLE SET THE COM LOOP ADDRESS AND MODE CONNECTING AUTO-TURN-OFF TIME SETTING TECHNICAL DATA APPROVALS... -
Page 3: Introduction
4414 E ADDRESS SETTING TOOL - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 1. INTRODUCTION This document describes the address setting tool, type number 4414 E. The document contains information about the product and instructions on how to mount and connect it. -
Page 4: Abbreviations
2. ABBREVIATIONS Clear software... -
Page 5: General Description
4414 E ADDRESS SETTING TOOL - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 3. GENERAL DESCRIPTION The address setting tool is used to set the COM loop unit´s address (000-253) on the analog detectors and all other addressable COM loop units. Address 000 is only used for COM loop units that shall be automatically addressed by the EBL system. -
Page 6: Set The Com Loop Address And Mode
4. SET THE COM LOOP ADDRESS AND MODE Each COM loop unit has to have a unique COM loop address (001-253). See the COM loop unit respectively for mode information. M0 = NORMAL mode M1 = 2330 mode M2 = 2312 mode M3 = Advanced mode How to read a) Turn on the tool by pressing the On/Off / CLR button. -
Page 7: Connecting
4414 E ADDRESS SETTING TOOL - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 5. CONNECTING Analog detector´s contact pins (SA / SB) are plugged into the address setting tool´s snap connectors (SA / SB). The connection cable is used to connect to other units. Flying leads should be disconnected and thrown away after use. -
Page 8: Technical Data
7. TECHNICAL DATA All current consumptions are valid by nominal voltage and by 25 °C. Voltage: Allowed 4.5 – 6V DC Normal Current: Quiescent 0 mA Active 8.5 mA Address range 001-253 S/W version Short circuit isolator Internal battery Material ABS plastic Ambient temperature: Operating... -
Page 9: Approvals
4414 E ADDRESS SETTING TOOL - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 8. APPROVALS Notified body Applicable directive/ Approval Applicable standards EN61000-6-3 (Emission) Self declaration EN50130-4 (Immunity) RoHS EN IEC 63000 Self declaration... - Page 10 DOCUMENT NAME: TECHNICAL DESCRIPTION 4414 E DOCUMENT NUMBER: MEW02093 EN DATE OF ISSUE: 2017-04-25 REV: 2 DATE OF REVISION: 2024-02-26 Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Sweden Tel: +46 (0)40 697 70 00 www.panasonic-fire-security.com...
