Summary of Contents for RVMP flex POWER RVMP-220168
- Page 1 OWNER’S MANUAL Read this manual carefully before operation. This manual includes important guidance for safety operation. Visit rvmp.co • Copyright© 2023 RV Mobile Power, LLC. All Rights Reserved.
-
Page 2: Table Of Contents
Welcome to the FLEX POWER® Family! Product Dimensions Product Features Overview Approvals Intelligent Battery Management System Bluetooth Enabled Product Specifications General Performance Specifications Charge Specifications Discharge Specifications Storage Specifications BMS Specifications Selecting A Battery For Application Selection of LiFePO4 Based on Power Draw Environmental Factors Impact of Ambient Temperature on Capacity Cycle Life (Including the Effects of Ambient Temperature) -
Page 3: Welcome To The Flex Power® Family
Welcome to the FLEX POWER® Family! Thank you for choosing the Flex Power® LiFePO4 Battery. This Li-ion rechargeable battery is 12.8 volts (V) 100 Ampere-hours (Ah). This battery has been specifically engineered for efficiency, performance, and safety. Before using, please read this manual carefully and carefully follow all instructions and safety precautions. -
Page 4: Bluetooth Enabled
Bluetooth Enabled Monitor the State of Charge (SoC), State of Health (SoH), current, capacity, temperature, number of cycles, and voltage levels of the battery and individual cells from our app: https:// rvmp-lifepo4-battery-app.rvmp.co Product Specifications General Performance Specifications Item... -
Page 5: Discharge Specifications
Max Charge Current 100A at 68°F (20°C) Recommended Charge Current Charge Cut-off Voltage 0.33C constant current charge Standard Charge to 14.6V then constant voltage 14.6V charge until charge current declines to ≤0.05C Discharge Specifications Item Values Discharge Temperature Range -4~140°F (-20~60°C) Recommended Output Voltage Range 2.8~10.8V Max Continuous Discharge Current... -
Page 6: Bms Specifications
We recommend cycling the battery once every 6 months if it is in long-term storage. BMS Specifications Item Values 14.6V Charging Voltage Balance 13.8V Self-discharge ≤3%/month Continuous current Max Charging ≤100A Max Discharging ≤100A Over-charging 3.75±0.05V Voltage Over-charging Protection Over-charge Delay 1~3S Time Over-charging... -
Page 7: Selecting A Battery For Application
temperature release (50~55°C) Discharge high 167±41°F temperature protection (75±5°C) Discharge high 131±149°F temperature release (55±65°C) Charging low 0±41°F temperature protection (0±5°C) Charging low temperature 41~50°F release (5~10°C) Low Temperature Protection Discharge low temperature -4±41°F protection (-20±5°C) Discharge low 14~5°F temperature release (-10~-15°C) Selecting A Battery For Application Choosing the appropriate LiFePO4 battery for any application, whether the application is based on current draw or... -
Page 8: Environmental Factors
For instance, a voltage of a lithium battery can be assumed to be a constant 12.8 V during discharge, hence if 256 Whr are require for the application to be delivered for a 2 to 4 hour discharge a 10 Ah battery can be used (e.g 12.8 V x 5 Ah x 4 Hr = 256 Whr and 12.8V x 10 Ah x 4 Hr = 256 Whr) to deliver constant power. -
Page 9: Transport & Store
Please read and follow the handling instructions before use. Improper use may cause heat, fire,rupture, damage or capacity deterioration of the battery. RV Mobile Power, LLC (RVMP) is not responsible for any accidents caused by the usage without following our handling instructions. -
Page 10: Warranty
Warranty This Limited Warranty ("Warranty") outlines applicable coverage and claims procedures for Products, as defined herein, sold as Flex Temp™ Aftermarket Division which is referenced herein as "Warrantor", "we", "us" or "our". Coverage. Subject to the following terms and conditions, we warrant ONLY to you as the original consumer ("you" or "your") who purchases the product directly from Flex Temp™... - Page 11 CIRCUMSTANCES WILL OUR LIABILITY FDR ANY DEFECT IN THE GOODS, WHETHER BASED ON CONTRACT, TORT, WARRANTY, OR ANY OTHER THEORY, EXCEED THE PURCHASE PRICE OF THE PRODUCTS. YOU ACKNOWLEDGE AND DECLARE THAT THESE LIMITATIONS AND WAIVERS HAVE BEEN BROUGHT TO YOUR ATTENTION AND EXPLAINED, THAT YOU HAVE READ AND UNDERSTAND ALL TERMS AND AGREE TO BE SO BOUND, AND THAT YOUR RECEIPT OF THE WARRANTY AND PRODUCT, AND ANY PAYMENT FOR THESE, SIGNIFIES THAT YOU HAVE VOLUNTARILY AND KNOWINGLY CONSENTED TD ALL TERMS, INCLUDING THE WAIVERS AND LIMITATIONS CONTAINED HEREIN.
- Page 12 To ensure trouble free warranty coverage it is important that you register your hot water heater. You may register on-line at the links presented below or by filling out and returning to RVMP the warranty registration card supplied with your hot water heater.
