Bene Inox 41 Series Manual

Press fitting connectors, 3-part pn16 female/female valve for press fitting - m-profile - 316 stainless steel
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

41153
Model
– 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287
Béné Inox
Tel. N°: +33 (0)4 78 90 48 22 – Fax N°: +33 (0)4 78 90 69 59 – www.bene-inox.com – bene@bene-inox.com
Technical information, illustrations and photographs are provided for information only, they are not contractual. Some may vary according to the tolerances accepted in the profession and the applicable standards. All
instructions for use, disassembly and maintenance are recommendations only. These could also vary depending on product usage conditions, its installation environment and purchaser requirements – of which the purchaser
3-part PN16 female/female valve for
press fitting - M-profile - 316 stainless
steel
alone is responsible for their definition.
Specifications
Dimensions:
Ø15 to Ø76.1
Connection:
For press fitting - M-profile
Operating pressure:
Temperature:
-20°C to +120°C (standard)
Material:
316 or CF8M stainless steel
PTFE gaskets (valve)
EPDM ACS gaskets (connections)
e
Rang
41
PRESS FITTING
CONNECTORS
-0.95 to 16 bar
41153-B V1024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 41 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Bene Inox 41 Series

  • Page 1 Rang PRESS FITTING CONNECTORS 3-part PN16 female/female valve for 41153 Model press fitting - M-profile - 316 stainless steel Specifications Dimensions: Ø15 to Ø76.1 Connection: For press fitting - M-profile Operating pressure: -0.95 to 16 bar Temperature: -20°C to +120°C (standard) Material: 316 or CF8M stainless steel PTFE gaskets (valve)
  • Page 2 Rang PRESS FITTING CONNECTORS Ø15 to Ø28 Ø Weight Part number (mm) (mm) (mm) (mm) (mm) (mm) (kg) 641153-15 15,2 12,5 54,2 0.40 18,2 15,0 55,7 0.54 641153-18 22,2 20,0 0.64 641153-22 28,2 25,0 0.98 641153-28 – 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287 Béné...
  • Page 3 Rang PRESS FITTING CONNECTORS Ø35 to Ø76 Ø Weight Part number (mm) (mm) (mm) (mm) (mm) (mm) (kg) 35,3 32,0 81,5 1.78 641153-35 42,3 38,0 94,5 2.90 641153-42 641153-54 54,4 50,0 4.48 76,7 7.35 641153-76 – 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287 Béné...
  • Page 4 Rang PRESS FITTING CONNECTORS Ø15 to Ø28 N° Part Name Material BODY CF8M FLANGE (END FOR PRESS FITTING) CF8M BALL AISI 316 SEAT PTFE BODY GASKET PTFE FLANGE END O-RING EPDM SHAFT FLAT SHAFT GASKET PTFE SHAFT PACKING PTFE SHAFT NUT (GLAND) AISI 304 BOLT (TIE ROD) AISI 304...
  • Page 5 Rang PRESS FITTING CONNECTORS Ø35 to Ø76 N° Part Name Material BODY CF8M FLANGE (END FOR PRESS FITTING) CF8M BALL AISI 316 SEAT PTFE BODY GASKET PTFE FLANGE END O-RING EPDM SHAFT FLAT SHAFT GASKET PTFE SHAFT PACKING PTFE SHAFT NUT (GLAND) AISI 304 BOLT (TIE ROD) AISI 304...

  • Page 6: Pressure And Temperature

    Rang PRESS FITTING CONNECTORS This valve is a full bore shut-off valve: it must be either fully open or fully closed. Do not leave the valve partially open: an opening default, or leaving the ball valve partially open to decrease flow, could lead to cavitation which is likely to damage the valve.

  • Page 7: Installation

    Rang PRESS FITTING CONNECTORS Assembly and maintenance instructions Installation You can install the valve in any position. However, check that there is enough space to move the valve’s handle where you are planning to install the valve. Check that the installation is clean and free from foreign bodies that could damage the valve. Check that all piping is perfectly aligned and that the piping support structure is dimensioned so that the valve is not subject to any external stresses.

  • Page 8: Assembly / Disassembly

    Rang PRESS FITTING CONNECTORS Assembly / Disassembly The maintenance and removal/installation of the valve must be carried out by personnel who are qualified and trained for this type of intervention. Warning: Before you work on the valve, check that the installation has been stopped and that the piping is empty and is not pressurised.

  • Page 9: Standards And Compliance

    Rang PRESS FITTING CONNECTORS Standards and compliance • EPDM gaskets comply with ACS certification. • PTFE gaskets comply with FDA certification. • This valve complies with European Pressure Equipment Directive (PED) 2014/68/EU (formerly 97/23/EC) • Leak testing according to EN 12266 / API 598 –...
