Global Power Products TRIFESTA Instruction Manual

3-in-1 meter-mounted transfer switch
Hide thumbs

Advertisement

Table of Contents

3-in-1
Meter-Mounted
Transfer Switch
❖ Manual Transfer Switch
❖ Surge Suppression
❖ Service Lockout
Copyright © 2021 Global Power Products, Inc. All Rights Reserved ®.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIFESTA and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Power Products TRIFESTA

  • Page 1 3-in-1 Meter-Mounted Transfer Switch ❖ Manual Transfer Switch ❖ Surge Suppression ❖ Service Lockout Copyright © 2021 Global Power Products, Inc. All Rights Reserved ®.
  • Page 2 TABLE OF CONTENTS OVERVIEW SAFETY Provides three essential Safe for homeowners services in a single meter- and protects essential mounted appliance. utility line workers. INSTALLATION OPERATION Installed by a certified Easily control which electrician in less than power source is 15 minutes.
  • Page 3 COMPANY HISTORY Founded in 1995, Global Power Products has been manufacturing transfer switches, smart electric meters, and surge suppression devices for over 25 years. With over 150,000 units sold, the GenerLink Transfer Switch is our most popular product to date. All products are...
  • Page 4 TRIFECTA OVERVIEW...
  • Page 5 TRIFECTA OVERVIEW 3-in-1 Meter-Mounted Transfer Switch The Trifecta provides three essential services in a single meter-mounted appliance that can be installed in under 15 minutes! Service Lockout Manual Surge Transfer Suppression Switch...
  • Page 6 TRIFECTA OVERVIEW MANUAL TRANSFER SWITCH The Trifecta allows homeowners to safely connect portable generator power directly to the main breaker of their home in minutes!
  • Page 7 TRIFECTA OVERVIEW SERVICE LOCKOUT The Trifecta provides a simple way to disconnect the home from all power sources if maintenance on the load side of the electrical meter is required.

  • Page 8: Surge Suppression

    TRIFECTA OVERVIEW SURGE SUPPRESSION The Trifecta comes equipped with surge protection to protect sensitive equipment inside the home from being damaged by transient voltage surges.
  • Page 9 Generator Compatibility: 30-50 Ampere or less, 7-12kW Continuous Generator Protection: Supplemental 30-50A Overcurrent Protection Generator Connection: Proprietary GenerLok™ Cord Life Cycle: 300,000 Operations Temperature Range: -30°C to 60°C External Ambient Copyright © 2021 Global Power Products, Inc. All Rights Reserved ®.
  • Page 10 TRIFECTA OVERVIEW Copyright © 2021 Global Power Products, Inc. All Rights Reserved ®.
  • Page 11 TRIFECTA SAFETY...
  • Page 12 TRIFECTA SAFETY UL-Listed Device The listing from Underwriter Laboratories indicates that the Trifecta UL 1008M has undergone and passed rigorous safety UL-Listed and reliability tests. Components File: E491124 All components used Date: 07/2021 inside the Trifecta are individually UL-Listed to ensure reliance at every level.
  • Page 13 TRIFECTA SAFETY UTILITY SAFETY The 3-position handle on the Trifecta ensures that the home is only connected to one source of power at a time. This functionality prevents the portable generator from back- feeding utility lines and protects essential utility line workers.
  • Page 14 TRIFECTA SAFETY 2020 NATIONAL ELECTRIC CODE Section 706.2(B) of the 2020 NEC states, “Transfer switches installed between the utility meter and the meter enclosure shall be listed meter- mounted transfer switches and shall be approved.” This section shows an example of such approved equipment with an image of our GenerLink Transfer Switch.
  • Page 15 TRIFECTA INSTALLATION...
  • Page 16 TRIFECTA INSTALLATION The Trifecta can be installed in any 200- ampere ring or ring-less type 2S meter socket by a certified electrician. Most installations take less than 15 minutes! A representative from the utility company must be on-site to cut the meter seal.
  • Page 17 TRIFECTA INSTALLATION 5-Step Installation in Under 15 minutes! Install the Trifecta into the Install the electric meter to Remove cabinet cover or meter socket and replace the the top of Trifecta and add locking ring and remove cabinet cover or locking ring a locking ring to secure the the electric meter.
  • Page 18 TRIFECTA OPERATION...
  • Page 19 TRIFECTA OPERATION FEATURES • The 3-position handle controls which, if any, source of power is connected to the home. • The locking arm allows the unit to be locked in the OFF position while maintenance is being performed. • The GenerLok inlet allows for simple connection of generator power.

  • Page 20: Status Lights

    TRIFECTA OPERATION Status Lights • The Green Light indicates utility power is available for use. • The Blue Light indicates alternate source power is available for use. • The Yellow Light indicates power is connected to the home from the source selected by the 3-position handle.

  • Page 21: Manual Transfer Switch

    TRIFECTA OPERATION MANUAL TRANSFER SWITCH 5-Step Process to Connect Portable Generator Power. STEP STEP Turn off all breakers in Connect the GenerLok the breaker panel. cord to the generator and the inlet on the Trifecta. STEP STEP STEP Power on the Rotate the 3-position Turn on essential portable generator.
  • Page 22 TRIFECTA OPERATION SERVICE LOCKOUT Rotate the handle on the Trifecta to the OFF position to disconnect the home from all power sources when maintenance on the load side of the electrical meter is required. This functionality guarantees power is not being delivered to the home and creates a safe work environment.

  • Page 23: Transfer Switch

    THANKS! 3-in-1 Meter-Mounted Transfer Switch ❖ Manual Transfer Switch ❖ Surge Suppression ❖ Service Lockout Contact information: Email: info@globalpowerproducts.com Phone: (800)886-3837 Website: www.trifectaswitch.com Copyright © 2021 Global Power Products, Inc. All Rights Reserved ®.
