Micro 2-way radio set

Advertisement

Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these
instructions and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE OR PERSONAL INJURY
AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1 BATTERY SAFETY INSTRUCTIONS
charge batteries prior to first use. the batteries will have been shipped in a
low charge state.
use only the charger provided to charge the batteries.
 Do not charge batteries when room temperature is below 50°f (10°c) or
above 104°f (40°c).
 Do not attempt recharging the batteries by means of an engine generator
or a Dc power source.
 Do not short-circuit the batteries by linking both terminals with a metal
object, or your fingers etc.
 Do not store the batteries (or radio) in locations where the temperature
may exceed 104°f (40°c) such as outside sheds, above heaters, or metal
buildings in summer.
 WARNING! Dispose of spent batteries correctly. For safety and
environmental reasons DO NOT discard in domestic waste or by burning.
ONLY discard or recycle according to local waste authority regulations.
 WARNING! DO NOT allow a leaking battery to come into contact with your
skin. If you come into contact with battery fluid take immediate action:
a) Skin contact: Wash immediately with soap and water.
b) Eye contact: Flush eye immediately with cool, clean running water for
at least 15 minutes and seek immediate medical attention.
1.2 ELECTRICAL MAINS POWER SAFETY.
ONLY USE THE SUPPLIED CHARGER PLUG FOR CONNECTING UNITS TO THE MAIN
ELECTRICAL POWER SUPPLY.
 WARNING! it is the user's responsibility to read, understand and comply with the following electrical
instructions: You must ensure the risk of electric shock is minimised by the installation of appropriate
safety devices. An rccB (residual current circuit Breaker) should be incorporated in the main
distribution board. We also recommend that an rcD (residual current Device) is used with all electrical
products, particularly portable equipment which is plugged into an electrical supply not protected by an
rccB.You must also read and understand the following instructions concerning electrical safety.
1.3 the Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises,
to be tested by a qualified electrician, using a Portable Appliance tester (PAt), at least once a year.
1.4 The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe
condition of the appliance, and the safety of the appliance operator. If in any doubt about electrical
safety, contact a qualified electrician.
1.5 You must ensure that you:
inspect the charger plug, cables and adaptors for wear and damage to ensure items are safe before
connecting to the mains power supply. if worn or damaged Do not use.
check cable is protected against short circuit and overload.
important: check that the voltage marked on the charger plug is the same as the power supply to be used.
uncoil the power cable between charger and plug.
 Do not pull charger power lead, or pull the charger plug from the mains socket by the power lead.
 Do not use any other type of charger with this product.
 Do not place the power connector into any area of the product except the correct Ac jack inlet socket.
 Do not try to open or dis-assemble the charger plug.
 Do not use charger plug to charge or power any other electrical item.
 Do not get charger wet, or use in wet, damp conditions (for indoor use only).
 WARNING! NEVER substitute a standard 13Amp 3 pin plug, or any other type of plug, for the charger plug.
instructions for:
MICRO 2-WAY RADIO SET
moDEL: WT1
Original Language Version
Wt1
issue: 2 - 17/08/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WT1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sealey WT1

  • Page 1 MICRO 2-WAY RADIO SET moDEL: WT1 Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS.
  • Page 2: Operation

    Main Screen (Fig.1). 4. receiving mode (rX). 2. INTRODUCTION/SPECIFICATION 1. VoX indicator. 5. chan. no. Display (1-8). 2. call mode (call). 6. Battery Level indicator. super compact, 2-way radios that fit easily into the 3. transmitting mode (tX). 7. Key Lock indicator. palm of the hand or pocket yet have the features of a fully sized set, including, eight channels each with 38 full...
  • Page 3: Function Setup

    4.2.2 the channel numbers will index through the Selecting Sub-code. range and stop when a transmission is 3.4.1 Press MENU key twice within 1 detected. second to enter CTCSS 4.2.3 to stop scan press the or key. sub-code settings, ‘SC’ displayed on LCD (fig.4) after 1 Auto Squelch (SQ).
  • Page 4: Troubleshooting

    2 miles in clear, 79.7 123.0 192.8 unobstructed conditions. 82.5 127.3 203.5 6. PARTS 85.4 131.8 210.7 88.5 136.5 218.1 Part no: Description: Wt1.c charger 91.5 141.3 225.7 94.8 146.2 233.6 97.4 151.4 241.8 100.0 158.7 250.3 103.0 162.2 Original Language Version...
  • Page 5: Ec Declaration Of Conformity

    Description and Function:............................... Model/Type:..................................Manufacturing Date / Serial number (optional)......................... Manufacturer's authorised representative within the EC: Jack Sealey Ltd. Kempson Way, Suffolk Business Park, Bury St. Edmunds, Suffolk, IP32 7AR Conforms to the requirements of the following Directives, as indicated.
