V-TAC VT-5002 Installation Instruction

Wifi mini smart socket-usb
Hide thumbs Also See for VT-5002:

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTION
WIFI MINI SMART SOCKET-USB
works with
Thank you for selec�ng and buying V-TAC Product. V-TAC will serve you the best. Please read
these instruc�ons carefully before star�ng the installa�on and keep this manual handy for
future reference. If you have any other query, please contact our dealer or local vendor from
whom you have purchased the product. They are trained and ready to serve you at the best.
The warranty is valid for 2 years from the date of purchase. The warranty does not apply to
damage caused by incorrect installa�on or abnormal wear and tear.The company gives no
warranty against damage to any surface due to incorrect removal and installa�on of the
product.
Note:
1. This device requires Wi-Fi Frequency 2.4Ghz
2. Indoor use only
3. Working Condi�on: -20°C to 60°C
4. Store Humidity: RH10% - RH80%
5. Opera�ng frequency (maximum transmi�ed power) 2400MHz -2483.5MHz (20dBm)
INTRODUCTION & WARRANTY
WEEE Number: 80133970

Advertisement

loading
Need help?

Need help?

Do you have a question about the VT-5002 and is the answer not in the manual?

Questions and answers

Related Manuals for V-TAC VT-5002

Summary of Contents for V-TAC VT-5002

  • Page 1 INTRODUCTION & WARRANTY Thank you for selec�ng and buying V-TAC Product. V-TAC will serve you the best. Please read these instruc�ons carefully before star�ng the installa�on and keep this manual handy for future reference. If you have any other query, please contact our dealer or local vendor from whom you have purchased the product.

  • Page 2: Specifications

    SPECIFICATIONS Model Number Input Voltage Max Current Wireless Standard Material Max Wa� VT-5002 8416 AC:90-250V, 50/60Hz Wi-Fi 2.4Ghz 2200 8428 AC:90-250V, 50/60Hz 2200 VT-5002-BS Wi-Fi 2.4Ghz APP INSTALLATION Download eWeLink APP by via APP Store Google Play Store (OR) Scan the below QR...
  • Page 3 Step 1: Open the eWeLink App and Step 2: To Add a New device tap on the “+” register. If you already have an exis�ng sign(as shown) account with eWeLink, please proceed to logging in. Step 3: Make sure your Smart device is powered ON 1) Tap and hold on the power bu�on for 5 seconds to make the device available in pairing mode.
  • Page 4 Step 5: Give a name to your device (Ex: Smart Step 4: Select your Wifi name and enter Plug/ smart switch) & tap on complete. the password and tap on Next. Step 6: Your device is now paired and will appear (Ex: as shown in the below image). a) To turn the device ON /OFF tap on the ON/OFF icon(as shown in the below image).
  • Page 5 Step 7: eWeLink offers mul�ple features such as; a) Share - This func�on allows you to share the access with another user. b) Schedule: Schedule �mer allows you to turn the device ON/OFF with flexibility of choosing date and �me. This feature also allows Repeat mode using which you can set the desired configura�on to daily OR any day of the week.
  • Page 6 ALEXA SETTINGS Step 2: Once you are on the Amazon Alexa Step 1:Install the Amazon Alexa app via the home page, tap on the lower right icon –– App Store (iOS) or the Play Store (Android) where the arrow is pointed–– to add a new and register.
  • Page 7 Step 8: a)Once you have successfully linked Step 7: Enter Login creden�als of eWeLink and V-TAC Skill close the window & (b)tap on then tap on Log In. If you do not have a exis�ng Discover device. Make sure Smart device is account please register by tapping on the paired with eWeLink app.
  • Page 8 Step 9: Discover your smart device on Alexa. Once you have enabled the skill A) You can use voice command ”Alexa discover devices” to the Alexa device which you have. B) To add device manually on home page tap on and tap on Add device , select the device (Ref Image B) which you are adding and tap on discover device.
  • Page 9 GOOGLE HOME SETTINGS Step 1: a&b) Install the Google Home app via the App Store (iOS) or the Play Store (Android) and register. If you already have an exis�ng account with Google Home, please proceed to logging in. c) Create a New Home/choose from the exis�ng home if any. d) Power ON the Google Home device and connect it to the App.
  • Page 10 Step 3: Make sure the Smart device is paired Step 4: Type “eWeLink” on the search bar and with eWeLink app before star�ng step 3. Tap tap on eWeLink icon from the drop down op�ons as shown below. on the arrow sec�on as highlighted in the below image.
  • Page 11 Step 7: Select the Home where you would Step 8: You have successfully added V-TAC like to add the Smart Device under. (Or) you Smart device to your Google home App. can create a New home in order to add the Smart Device to it.
  • Page 12 1. eWeLink App & Google Home App 2. Make sure you have Google Home Device 3. Smart Home Device 4. Stable Wifi network In case of any query/issue with the product please reach out to us at support@vtacexports.com V-TAC EUROPE LTD, Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B...

This manual is also suitable for:

Vt-5002-bs84168428
