Bioventus bioness L360 Thigh System User's Reference Card

Thigh System
User's Reference Card
Putting On the L360 Thigh Cuff
Wet and attach the Thigh Cloth Electrodes to the L360 Thigh Cuff.
1
2 For placement on the quadriceps while seated, place the L360 Thigh Cuff on your thigh,
positioning at the midline of the thigh and center on bulk of quadriceps muscle.
Make sure to place the L360 Thigh Cuff in the fitting position determined by your clinician.
3
See Figure 3 (Front view – Quadriceps).
For placement on hamstrings, while seated or standing, place the L360 Thigh Cuff at the
4
midline of the thigh and center on bulk of hamstring muscle, right under the gluteal fold.
See Figure 4 (Back view – Hamstrings).
1
Operating the L360 Thigh System
Status Indicator Light
Press the on/off button to turn on the EPG.
1
Select either gait or training mode:
2
• To select gait mode, press the
• To select training mode, press and hold the
The EPG will acknowledge the new mode with audio and tactile feedback. To exit
training mode, press and hold the
If necessary, adjust the stimulation intensity level by pressing the
3
button.
For a complete list of all contraindications, warnings, adverse reactions, precautions,
and care instructions please review the User's Guide.
Bioventus and the Bioventus logo are registered trademarks of Bioventus LLC.
L360, Bioness and the Bioness Logo are trademarks of Bioness Inc. in the United States or other countries | BionessRehab.com
© 2022 Bioventus LLC 612-01411-001 Rev. A
2
Plus Button
Minus Button
Charging Port
12/2022
3
Power Button
Stim Button
Battery Indicator Light
mode button briefly.
mode button for 3 seconds.
mode button for 3 seconds.
4
plus or minus
Rx Only
(US only)
