Summary of Contents for 4CleanPro MIRA 40
- Page 1 SCRUBBER- DRYER MIRA 40 USE AND MAINTENANCE MANUAL Revision: 2.0 Translation of the original instructions Edition: 11/09/2019...
-
Page 3: Table Of Contents
SCRUBBER-DRYER MIRA 40 Table of contents GENERAL INFORMATION ....................5 1.1 MANUFACTURER IDENTIFICATION DATA ................5 1.2 AIM OF THE MANUAL ......................5 1.3 TERMINOLOGY AND SYMBOLS ..................... 6 1.4 INTENDED USE AND UNINTENDED USE................7 1.5 TECHNICAL MODIFICATIONS ....................7 1.6 PRODUCT IDENTIFICATION .................... - Page 4 SCRUBBER-DRYER MIRA 40 5.12.3 INDIRECT WASHING OR FOR VERY DIRTY SURFACES ............28 5.12.4 POST-CLEANING OPERATIONS ....................28 MAINTENANCE ........................29 6.1 TANKS ........................... 29 6.2 DETERGENT SOLUTION TANK FILTER ................29 6.3 SUCTION HOSE ........................29 6.4 SQUEEGEE ........................... 30 6.5 VACUUM FILTER ........................
-
Page 5: General Information
SCRUBBER-DRYER MIRA 40 GENERAL INFORMATION MANUFACTURER IDENTIFICATION DATA 4CLEANPRO S.r.l. Via dei Tigli, 20 50013 Campi Bisenzio (FI) - ITALY Telephone: +39 055 898139 Fax: +39 055 8969007 Website: www.4cleanpro.com The manufacturer accepts no liability for damage or injury caused by: •... -
Page 6: Terminology And Symbols
SCRUBBER-DRYER MIRA 40 TERMINOLOGY AND SYMBOLS For greater clarity and to adequately highlight the various aspects of the instructions described, specific terms and symbols have been used. These are defined and illustrated below: Term Definition Machine This replaces the commercial name of the machine to which this manual refers. -
Page 7: Intended Use And Unintended Use
INTENDED USE AND UNINTENDED USE The machine referred to in this manual (MIRA 40) is an operator-controlled hard floor scrubber-dryer. It must be used to scrub and vacuum liquids on flat, hard, horizontal, smooth or moderately rough and uniform floors that are free from obstacles in both civil and industrial environments. -
Page 8: Safety Information
SCRUBBER-DRYER MIRA 40 SAFETY INFORMATION BASIC RECOMMENDATIONS NOTE: Read the “instructions manual” before starting up, using, or carrying out scheduled or unscheduled maintenance or any other work on the machine. CAUTION Strictly comply with all the instructions provided in this manual and those regarding the batteries and battery chargers (pay particular attention to safety warnings and danger notices). - Page 9 SCRUBBER-DRYER MIRA 40 CAUTION Do not use the machine on slopes or ramps that are steeper than 2%. On sight slopes, never use the machine sideways, always manoeuvre it with care and never reverse. When transporting the machine on steep ramps or slopes, be very careful to prevent it tipping over and/or accelerating uncontrollably.
- Page 10 SCRUBBER-DRYER MIRA 40 DANGER! Do not place tools on top of the batteries: they may cause a short-circuit or an explosion. In the presence of particularly strong magnetic fields, asses the possible effect they may have on electronic control devices.
-
Page 11: Technical Support
SCRUBBER-DRYER MIRA 40 TECHNICAL SUPPORT DANGER! All maintenance work or the replacement of accessories must be carried out in areas with adequate lighting and only after having disconnected the machine from the power supply by unplugging the battery connector. NOTE:... -
Page 12: Handling Information
SCRUBBER-DRYER MIRA 40 HANDLING INFORMATION DIMENSIONS AND WEIGHT OF PACKAGE Weight: 38 kg Volume: 0.22 m 1250 mm 510 mm 520 mm LIFTING AND HANDLING THE PACKAGE CAUTION When lifting or transporting the machine, make sure that the packaged machine is securely anchored to prevent it from tipping over or falling accidentally. -
Page 13: Inspection Upon Delivery
SCRUBBER-DRYER MIRA 40 INSPECTION UPON DELIVERY When the goods are delivered (machine, battery or battery charger) by the carrier, carefully check the condition of the packaging and its contents. If the contents have been damaged, inform the carrier immediately and reserve the right, in writing (select the “accepted with reserve”... -
Page 14: Assembling The Machine
SCRUBBER-DRYER MIRA 40 ASSEMBLING THE MACHINE DANGER! All the operations described below must be carried out in areas having adequate lighting and only when the battery has been removed from the machine. After unpacking the machine, it must be assembled as described below (refer to the relevant sections in Chapter 5 for... -
Page 15: Technical Information
SCRUBBER-DRYER MIRA 40 TECHNICAL INFORMATION GENERAL DESCRIPTION OF COMPONENTS ON/OFF switch Power indicator light Brush / Brush+Water switch Vacuum motor switch Handle Recovery tank fastening clip Suction hose Battery Squeegee Brushes Solution tank Wheels Drain plug Vacuum motor fan Filler plug... -
Page 16: Control Panel (Version 3 And Below)
SCRUBBER-DRYER MIRA 40 CONTROL PANEL (VERSION 3 AND BELOW) Function Position Description Turns off the machine (indicator A off) Turns on the machine ON/OFF (indicator light A on) provided that switches 2 and 3 are in the position Brush Starts the brushes Brushes and dispensing of washing solution off. -
Page 17: Control Panel (Version 4 And Above)
SCRUBBER-DRYER MIRA 40 CONTROL PANEL (VERSION 4 AND ABOVE) FUNCTION DESCRIPTION ON/OFF Turns the machine on or off Activates or deactivates the Vacuum vacuum function The speed of the brushes is Brush speed increased or decreased by adjustment pressing the + or – buttons... -
Page 18: Using The Machine
SCRUBBER-DRYER MIRA 40 USING THE MACHINE PREPARING THE MACHINE DANGER! All maintenance work or the replacement of accessories must be carried out in areas with adequate lighting and only after having disconnected the machine from the power supply by unplugging the battery connector. -
Page 19: Recharging The Battery
SCRUBBER-DRYER MIRA 40 RECHARGING THE BATTERY Connect the battery extension cable 1 to the plug of the battery charger 2. Plug the battery charger into a mains socket and charge the battery as long as the red LED on the battery charger 2 remains on. -
Page 20: Brush Types
SCRUBBER-DRYER MIRA 40 BRUSH TYPES 5.3.1 Four different types of brush are supplied with the machine. Their characteristics differ according to their composition and abrasiveness. Their use depends on the type of floor or the specific application. Picture Brush name... - Page 21 SCRUBBER-DRYER MIRA 40 Picture Brush name Description LIGHT CLEANING BLUE DISC Light cleaning and spray cleaning. MEDIUM CLEANING Used for removing the surface layers of wax and to prepare GREEN DISC the floor for the next treatment. Use wet POWER CLEANING BROWN DISC Aggressive disc for wet or dry stripping, with wax removers.
-
Page 22: Moving The Machine
SCRUBBER-DRYER MIRA 40 MOVING THE MACHINE With the machine switched off, pressing and turning lever "A” at the front will make the machine rest on the three wheels and lifts the brushes off the floor. It is now possible to move the machine by manoeuvring it as when it is in operation without locking the handle. -
Page 23: Locking / Releasing, Raising The Squeegee
SCRUBBER-DRYER MIRA 40 LOCKING / RELEASING, RAISING THE SQUEEGEE When the squeegee is raised from the floor by plate “1” the catch “2” is engaged that allows the squeegee to remain in a raised position. To return the squeegee to the floor, lift the catch "2" to release... -
Page 24: Replacing The Squeegee Blades
SCRUBBER-DRYER MIRA 40 REPLACING THE SQUEEGEE BLADES Remove the squeegee A from its support (see previous section). Completely unscrew the rear knobs 1 and remove the pins 2. Remove the squeegee blade 4-6 clamping strips 3-7. Remove the rubber blades 4-6 from the body 5 of the squeegee by pulling them from one end. - Page 25 SCRUBBER-DRYER MIRA 40 Filling procedure: Remove the filler plug 1. Pour the required quantity of the chemical product into the tank, considering the percentage (%) indicated by the supplier, according to the full tank capacity indicated on the product sheet.
-
Page 26: Draining The Recovery Tank
SCRUBBER-DRYER MIRA 40 Emptying procedure: Unscrew the drain plug 3, together with the filter 4, located in the lower part of the tank. Wait for the tank to empty completely. Screw the drain plug back on tightly 3. DRAINING THE RECOVERY TANK 5.10... -
Page 27: Operating The Machine
SCRUBBER-DRYER MIRA 40 OPERATING THE MACHINE 5.11 Check that the switches on the control panel are turned off: • Panel A: position • Panel B: indicator lights off Lower the squeegee. Lift the lever 4 to release the handle 5. -
Page 28: Floor Cleaning Instructions
SCRUBBER-DRYER MIRA 40 FLOOR CLEANING INSTRUCTIONS 5.12 PREPARATION AND WARNINGS 5.12.1 Remove any loose solid residues from the surface to be treated (using suitable equipment such as vacuum cleaners, sweepers, etc.) If this is not done, the solid dirt could prevent the squeegee from working properly and prevent the floor from being dried correctly. -
Page 29: Maintenance
SCRUBBER-DRYER MIRA 40 MAINTENANCE DANGER! All maintenance work or the replacement of accessories must be carried out in areas with adequate lighting and only after having disconnected the machine from the power supply by unplugging the battery connector. NOTE: All work on the electrical system and all maintenance and repair work (especially work not specifically described in this manual) should only be carried out at authorised service centres or by skilled personnel with experience in the field and knowledge of the relevant safety regulations. -
Page 30: Squeegee
SCRUBBER-DRYER MIRA 40 SQUEEGEE CAUTION Do not handle the squeegee with bare hands: wear gloves and any other protective clothing that may be necessary. Remove the squeegee from the machine and clean it under running water using a sponge or brush. -
Page 31: Machine Body
SCRUBBER-DRYER MIRA 40 MACHINE BODY Use a sponge or a damp cloth to clean the outside of the machine and if necessary, use soft brush to eliminate stubborn dirt. The machine’s impact resistant surface is rough to make it harder to see scratches produced during use. However, this does not make it easy to remove stubborn stains from its surface. -
Page 32: Extraordinary Maintenance
SCRUBBER-DRYER MIRA 40 EXTRAORDINARY MAINTENANCE Even though the machine has been carefully built and conforms with the most stringent quality tests, the electrical and mechanical components are inevitably subject to wear and ageing after long periods of use. In order for the machine to provide safe and trouble-free service, it is recommended that your machine be thoroughly inspected every year at a service centre authorised by the manufacturer (or by someone specialised in the field who has the proper skills and who is familiar with all the relevant safety regulations contained in this manual). -
Page 33: Troubleshooting
SCRUBBER-DRYER MIRA 40 TROUBLESHOOTING CAUTION The content of this chapter is not exhaustive but it aims to provide information regarding the most common problems in order to help the user to troubleshoot faults. The instructions under the heading “SOLUTION” in the table below DO NOT AUTHORISE work to be carried out that can affect safety. -
Page 34: Accessories
SCRUBBER-DRYER MIRA 40 ACCESSORIES TRANSPORT TROLLEY This accessory (optional) can be mounted on a cleaning trolley in order to be transported more easily. POWER SUPPLY This accessory (optional) replaces the standard battery and provides greater run time when using the machine.
