Trikke Skki 2025 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

by
Made in Poland
OWNER'S MANUAL
Trikke Skki 2025 Owner's Manual - V1 03/11/24 - ENG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Skki 2025 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trikke Skki 2025

  • Page 1 Made in Poland OWNER’S MANUAL Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 2 5 - Przedni widelec 8 - Torba na narty 11 - Gumowa osłona 3 - Osłona, wspornik 6 - Tylnie narty (2x) 9 - Torba, przedni widele 12 - Narzędzia Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 3 2 - Handlebar 5 - Front fork 8 - Bag, blades 11 - Cap, rubber 3 - Cover, stem 6 - Blade, rear ski (2x) 9 - Bag 12 - Tools Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 4 AND SLIDE IT UP LOWER YOUR RIGHT AND LEFT ARMS DOWN, FOLDING OUT SKKI TRIKKE LOWER DOWN AND LOCK ARM FOLDING SYSTEM LOCKS AFTER UNFOLDING, LOWER IT DOWN AND UNLOCK ARM LOCK PIN Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...

  • Page 5: Front Fork Installation

    FRONT FORK INSTALLATION PUSH PIN TO SLIDE INSERT FRONT FORK INSERT SO THAT THE LOCK PIN HIT THIS HOLE THESE TWO SCREWS TIGHTEN 6MM ALLEN WRENCH Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...

  • Page 6: Handlebar Assembly

    Adjust the handlebar by aligning the axis ALEN WRENCH of the front ski with the handlebars (you may need to loosen the bracket screws to adjust the alignment of the handlebars if they are tight). Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...

  • Page 7: Adjusting Handlebar Height

    ADJUSTING HANDLEBAR HEIGHT OPEN CLAMP MOVE THE STEERING WHEEL UP TO THE SELECTED HEIGHT CLOSE CLAMP Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...

  • Page 8: Front Bumper Assembly

    FRONT BUMPER ASSEMBLY UNPLUG THE STRAPS. PLACE THE FRONT BUMPER ON THE HEAD TUBE TO COVER CAMBERING WRAP AND FASTEN VELCRO STRAPES, SHORTER AT THE TOP Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 9 WE TAKE THE SKI OUT OF THE BAG FRONT SKI IS FIRST FROM THE TOP. BAG IS CLOSED WITH A FLAP ON A VELCRO. ALWAYS FASTEN SKIS WITH FRONT LEVER CLAMP! Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 10 USE THE INCLUDED SCREWDRIVER/LEVER TO EASILY FASTEN AND UNFASTEN QR LEVER OF YOUR SKIS. INSERT IT INTO THE QR LEVER HOLE. AT THE END, FASTEN SAFETY LEASH TO THE FRONT HOOK Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 11 FOLDING FOR STORAGE OR TRANSPORT UNLOCK THE QUICK RELEASE, RAISE STEM ALL THE WAY AND TURN HANDLEBAR UNLOCK PIN AND LIFT LEVER FOLD SKKI AND INSERT HANDLEBAR INTO THE ENDS OF THE PLATFORMS Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 12 1. INSERT FRAME WITH WHEELS INTO HOLES UNDER ARMS 2.VELCRO STRAP FASTENS TO FRAME AND HANDLEBAR 3. PULLING STRAP IS PUT ON THE SHOE ON THE FRONT FORK VELCRO STRAP TIGHTENED ON FRAME AND HANDLEBAR Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 13 LEVERS ADJUSTED WITH TWO SCREWS, WHICH ARE UNDERNEATH THE ARMS OF ARM EXTENSION ADJUSTMENT SHOULD BE MADE WITH A 3 MM ALLEN WRENCH BY GENTLY SCREWING OR UNSCREWING THE SCREW REGULATORY Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 14 TO THE ANKLE TO THE WRIST 1. SAFETY LEASH FASTENED TO THE HANDLEBAR OR ANKLE - DOUBLE BRAID WITH A METAL BUCKLE 2. ALWAYS KEEP YOUR LEASH ON WHILE EVERY RIDE! Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 15 Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 16 Follow and respect the rules and regulations of each ski resort where you ride. Rules of where to use and how to take your Trikke SKKI on the lifts may vary depending on each resort's mountain and lift operations management.
  • Page 17 POSITION ON SKKI TRIKKE WHILE RIDING PRAWIDŁOWA RIGHT Na stoku ON SLOPE NIEPRAWIDŁOWA INCORECT Slope Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 18 SKKI TRIKKE IS TURNED IN SUCH A WAY THAT THE FRONT SKI IS DIRECTIONAL DURING THE TURN UP THE SLOPE Prawidłowe PRAWIDŁOWA RIGHT DOWN SLOPES Dół stoku DRIVING LEARNING - TRAVERSING, RIDING ACROSS THE SLOPE Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 19 BRAKING Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 20 TURN - SMOOTH TURNS Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 21 Learning to ride is very simple and you only need to spend 15 minutes to ride efficiently on the slopes. Below you can see an abbreviated course on learning to ride a Skki Trikke. Please keep in mind a few basic rules during your first ride.
  • Page 22 It is necessary to “throw” the Skki and force it into the snow. You can find the en re driving lessons process on our website: www.skki-trikke.eu/drive-learning/ Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...

  • Page 23: Technical Notes

    1. When you ride our winter ski equipment three skis please pay a en on to thoroughly clean CAMBERING 3CV and the Trikke assembly area from snow a er a day of riding. This area should not be le all in snow, in ice!!
  • Page 24 Distribution, copying and use without knowledge of Trikke Tech. or Trikke Poland proprietary materials from this instructions, the Trikke logo or the use of the patent is prohibited and will be prosecuted with the full force of international law. Here you will find all videos and instruc ons: www.skki-trikke.eu...
  • Page 25 NOTES LUXSURY LUXSURY SAFETY SAFETY SKIING SKIING SKIING SKIING ROCK YOUR WORLD with SKKI TRIKKE Trikke Skki 2025 Owner’s Manual - V1 03/11/24 - ENG...
  • Page 26 Trikke Poland ul. Rysia 6, 87-800 Włocławek Poland e-mail: info@trikke.pl tel. +48 694 468 182 skki-trikke.eu Facebook: Trikke Poland YouTube: Trikke Poland...
