Vantron HAP101 User Manual

Wi-fi halow access point
Hide thumbs Also See for HAP101:
Table of Contents

Advertisement

Quick Links

Download this manual
Vantron
| Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
HAP101 Wi-Fi HaLow Access Point
User Manual
Version: 2.2
© Vantron Technology, Inc. All rights reserved.
www.vantrontech.com
Vantron | Public
HAP101 User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAP101 and is the answer not in the manual?

Questions and answers

Related Manuals for Vantron HAP101

Summary of Contents for Vantron HAP101

  • Page 1 | Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions HAP101 Wi-Fi HaLow Access Point User Manual Version: 2.2 © Vantron Technology, Inc. All rights reserved. www.vantrontech.com Vantron | Public HAP101 User Manual...

  • Page 2: Revision History

    1. Updated the screenshots as per the function update of the web V2.1 portal; Dec. 16, 2024 2. Added description for the use of ACL, DHCP, and DPP features V2.2 Updated the description of the device interfacing with BlueSphere GWM Dec. 18, 2024 www.vantrontech.com Vantron | Public HAP101 User Manual...

  • Page 3: Table Of Contents

    Error indicator ......................16 Serial Port ......................... 16 CHAPTER 2 GETTING STARTED ..................... 17 Setting up the Device ....................18 Pairing Two HAP101 Devices ..................19 2.2.1 Pairing via station setup on the web portal.............. 19 2.2.2 HaLow DPP pairing via hardware setup ..............23 2.2.3...
  • Page 4 3.10.6 Reboot ........................84 3.11 Logout ........................84 CHAPTER 4 USE CASE ........................85 Application Topology ....................86 Wiring ........................87 Setup of HAP101-STA ....................88 4.3.1 HaLow ........................88 4.3.2 2.4GHz Wi-Fi ......................90 Viewing Camera IPs ....................91 CHAPTER 5 DEBUGGING THE DEVICE ...................

  • Page 5: Foreword

    World-leading provider of embedded/IoT products and solutions Foreword Thank you for purchasing HAP101 Wi-Fi HaLow Access Point (“the device” or “the Product”). This manual intends to provide guidance and assistance necessary on setting up, operating or maintaining the Product. Please read this manual and make sure you understand the structure and functionality of the Product before putting it into use.

  • Page 6: Technical Support And Assistance

    Symbology This manual uses the following signs to prompt users to pay special attention to relevant information. Caution for latent damage to system or harm to personnel Attention to important information or regulations Vantron | Public HAP101 User Manual www.vantrontech.com...

  • Page 7: General Safety Instructions

    The use or placement of the operation tools shall comply with the code of practice of such tools to avoid short circuit of the Product. • Cut off the power before inspection of the Product to avoid human injury or product damage. Vantron | Public HAP101 User Manual www.vantrontech.com...
  • Page 8 Clean with a damp cloth • • Do not try to clean exposed electronic components unless with a dust collector Power off and contact Vantron technical support engineer in case of the following faults: • The Product is damaged The temperature is excessively high •...

  • Page 9: Chapter 1 Device Introduction

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 1 DEVICE INTRODUCTION Vantron | Public HAP101 User Manual www.vantrontech.com...

  • Page 10: Product Overview

    World-leading provider of embedded/IoT products and solutions Product Overview Vantron HAP101 Wi-Fi HaLow access point is designed in compliance with the prominent IEEE 802.11ah (Wi-Fi HaLow) standard and IEEE 802.11 b/g/n (2.4GHz Wi-Fi) standard. It offers a complete Wi-Fi connectivity solution for IoT developers who seek for wireless connections with energy efficiency, extended coverage, obstacle penetration, effortless accessibility, etc.

  • Page 11: Terminologies And Acronyms

    Dynamic Channel Selection: once enabled, the device will automatically select the channel with the strongest signal within the selected bandwidth for optimal performance. Unless otherwise stated, Wi-Fi in this manual refers to 2.4GHz Wi-Fi, and HaLow refers to Wi-Fi HaLow. Vantron | Public HAP101 User Manual www.vantrontech.com...

  • Page 12: Specifications

    Black plastics, UL94, SP6 compliant (Optional: White casing) Installation Wall mounting IP rating IP40 (Optional: IP54, enhanced with a waterproof kit) Input 9V ~ 40V DC Power Port 3-pin terminal (Over-current protection, reverse polarity protection) Vantron | Public HAP101 User Manual www.vantrontech.com...

  • Page 13: Interfaces And Indicators

    Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions HAP101 Operating system VantronOS Device management Vantron BlueSphere GWM (Optional) Upgrade Local upgrade, OTA upgrade OpenVPN Software Network protocol IPV4, HTTPS, TCP & UPD, NTP client and server, ARP, TLS...

  • Page 14: Back View

    Mounting brackets (screws recommended: M3 x 8mm) 1.5.2 Back view Interface Description Diversity 2.4GHz Wi-Fi antenna connector Wi-Fi HaLow antenna connector Primary 2.4GHz Wi-Fi antenna connector Mounting brackets (screws recommended: M3 x 8mm) Vantron | Public HAP101 User Manual www.vantrontech.com...

  • Page 15: Dip Switches

    Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions DIP Switches HAP101 offers two DIP Switches (2 x 2) that can be configured to different modes as detailed below. Table 1-2 Switch 1...

  • Page 16: Button State: Halow Dpp & Factory Reset

    2, the action will NOT be confirmed, and the device will continue to operate Reset state in 5s after release in its previous state. Please refer to 2.2.2 2.2.3 for the steps to set up the AP and STA in HaLow DPP mode for fast pairing. Vantron | Public www.vantrontech.com...

  • Page 17: Button State In Combination With Switches & Leds

    When the device is ready for factory reset, the indicator blinks at 2Hz. After the user confirms the state, the indicator will blink at 4Hz, indicating the device is undergoing a factory reset. Upon successful factory reset, the indicator will turn solid green. Vantron | Public www.vantrontech.com...

  • Page 18: Halow Indicator

    • When no client device is connected to the current device via 2.4GHz Wi-Fi AP or HaLow AP: OFF; • When Wi-Fi HaLow AP/2.4GHz Wi-Fi AP pairing is completed with success: Blinking at 4Hz for 3s and later transitioning to solid green. Vantron | Public www.vantrontech.com...

  • Page 19: Restore Indicator

    • Firmware upgrade initiated: Blinking at 4Hz. • Device ready for Factory Reset: Blinking at 2Hz; following user confirmation for the state: Blinking at 4Hz, indicating the device is undergoing a factory reset; upon successful factory reset: transitioning to solid green. Vantron | Public www.vantrontech.com...

  • Page 20: Error Indicator

    The ERR indicator turns off when there is no abnormality detected. Serial Port HAP101 offers an RS485 connector for serial communication. The default baud rate of the port is 115200, The pinout description is as follows: Table 1-4...

  • Page 21: Chapter 2 Getting Started

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 2 GETTING STARTED Vantron | Public www.vantrontech.com...

  • Page 22: Setting Up The Device

    World-leading provider of embedded/IoT products and solutions Setting up the Device When mounting HAP101 on a vertical surface, please ensure that the device is oriented with the LED indicators pointing down. This positioning allows the LEDs to be visible to the user on the ground.

  • Page 23: Pairing Two Hap101 Devices

    2.4GHz WLAN IP address as the login address. For other login methods, please refer to 2.3. 1. Power on HAP101-AP and use an Ethernet cable to connect it to a router that functions as a DHCP server;...
  • Page 24 3. Connect the host computer to the 2.4GHz Wi-Fi of HAP101-STA using the default SSID and password provided on the device label as shown below; 4. Use the default WLAN Login IP provided on the device label of HAP101-STA as the address for VantronOS login;...
  • Page 25 Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions 6. Navigate to Network > HaLow WIFI and change the HaLow mode of HAP101-STA to Client, then wait a few seconds to allow the change to apply;...
  • Page 26 9. Navigate to Network > HaLow WIFI. Under the Wifi Client Setting tab, select the SSID of HAP101-AP from the list and enter the password for HaLow connection; 10. If the target SSID is not included in the HaLow SSID list, click the SCAN WIFI button to refresh the list;...

  • Page 27: Halow Dpp Pairing Via Hardware Setup

    DPP specifically to the fast-provisioning of the devices for a standard HaLow connection (“HaLow DPP”) in this manual. Scenario: An AP mode HAP101 (H1) and a station mode HAP101 (H2) are running in the normal operation state. Requirement: Connect H2 to H1 via HaLow DPP configurations.

  • Page 28: Halow Dpp Pairing Via Software Setup

    World-leading provider of embedded/IoT products and solutions 2.2.3 HaLow DPP pairing via software setup Except the method described in 2.2.1, you can pair an AP mode HAP101 (H1) and a station mode HAP101 (H2) in VantronOS, regardless of the physical settings of the devices.
  • Page 29 ‘netdev’ mode. The UP indicator on H1 and the DOWN indicator on H2 will blink at a frequency of 4Hz for 3s and later turn solid green; 9. The DPP push log indicates the success or failure state of the connection. Vantron | Public www.vantrontech.com...

  • Page 30: Web Login

    HAP101 provides one single Ethernet port, functioning as a WAN port by default. You have two options to determine the WAN port IP of HAP101. You can use the arp -a command in the shell of the router/switch to display the devices connected to it. By matching the MAC address with the one on the device label, you can identify the corresponding WAN port IP address.

  • Page 31: Login Via The 2.4Ghz Wlan Ip

    • HAP101 is operating in 2.4GHz Wi-Fi AP mode Steps: 1. Power on HAP101 and the 2.4GHz Wi-Fi will be operating in the AP mode by default; 2. Connect the host computer to the 2.4GHz Wi-Fi of the device using the SSID and default password provided on the device label as shown below;...
  • Page 32 4. Log in to VantronOS using the username and password on the device label; For higher permissions on VantronOS, log in as a superuser: Super user: root password: rootpassword 5. Navigate to Network > Interfaces to check the interface information of HAP101. Vantron | Public www.vantrontech.com...

  • Page 33: Login Via The Vlan Ip (Windows Pc)

    • The host computer supports VLAN settings (some may require installation of corresponding network adapter driver) Steps: 1. Connect the Windows host computer to the WAN port of HAP101; 2. Open the Network & Internet Settings on the host computer; 3. Right click the network adapter and select Properties;...
  • Page 34 5. Select Priority & VLAN from the list, and make sure the value is Priority & VLAN Enabled; 6. Move down to the VLAN ID attribute and input ‘10’ as the value, then click OK to confirm the settings; 7. Wait a moment and check the network adapter settings; Vantron | Public www.vantrontech.com...
  • Page 35 Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions 8. Use the IPv4 default gateway for VantronOS login to HAP101; 9. Log in to VantronOS using the username and password provided on the device label.

  • Page 36: Login Via The Vlan Ip (Linux Pc)

    2.3.3 Login via the VLAN IP (Linux PC) Steps: 1. Connect the Linux host computer to the WAN port of HAP101; 2. Open a terminal on the host computer and use the ifconfig command to figure out the Ethernet interface of the computer;...
  • Page 37 The VLAN interface is assigned with an IP of 172.18.2.114 by the VLAN gateway (HAP101). 7. Run the ip route command to check the IP address of the VLAN gateway (HAP101). The IP address of HAP101 is 172.18.2.1 in this case. Please note that when HAP101 switches to the HaLow station mode, its IP will change to 172.18.3.1 accordingly.

  • Page 38: Login Via The Wan Port Ip

    2. Connect the host computer to a router/switch using an Ethernet cable; 3. Connect HAP101 to the same router/switch using an Ethernet cable; 4. Navigate to Network > Interfaces to identify the WAN port address of HAP101; 5. Use the WAN port IP of HAP101 as the address for VantronOS login;...

  • Page 39: Ssh Login

    Option 2— If the host computer and HAP101 are on the same Ethernet WAN network: Use the WAN port IP of the device as the login address. Make sure the IP address of the host computer is on the same network as HAP101 before the SSH login of HAP101.

  • Page 40: Wi-Fi Halow Mode

    VantronOS before you proceed. 2.5.1 AP mode HAP101 is operating in the HaLow AP mode by default. To check the general HaLow information, follow the steps below: 1. Log in to VantronOS for the AP mode HAP 101 via any of the options provided in 2.3;...
  • Page 41 HaLow will receive an IP address from the DHCP server; 8) Pressing the Start DPP Push buttons simultaneously on the web portals for the AP mode HAP101 and the station mode HAP101 will initiate a DPP pairing between the devices.
  • Page 42 To establish a HaLow connection, set up the station mode device using the HaLow SSID and key of the AP mode device. You can check the connection status in the web portal of the AP mode HAP101 (Network > HaLow WIFI > Associated Stations). Vantron | Public...

  • Page 43: Station Mode

    7. Navigate to Network > HaLow WIFI. Under the Wifi Client Setting tab, select the SSID of the target AP mode HAP101 from the list and enter the password for HaLow connection (refer to the SSID & password on the label of the AP mode device);...

  • Page 44: Mesh Mode

    HaLow devices to connect to it, like the following topology. To establish a HaLow mesh network, follow the steps below: 1. Connect an AP mode HAP101 (H1 in above topology) to a DHCP server via Ethernet or Wi-Fi;...
  • Page 45 After a device switches from the HaLow AP mode to the Client mode, its 2.4GHz Wi-Fi AP LAN IP will change to 172.18.3.1 accordingly. If you need to access the VantronOS web portal for it, use the updated IP address to log in after connecting the PC to the device. Vantron | Public www.vantrontech.com...

  • Page 46: Ethernet Port Modification

    HaLow interface is not bridged to the WAN port. Then save and apply the change; 3. Navigate to Network > Wireless (WIFI) to confirm that the 2.4GHz Wi-Fi interface is not bridged to the WAN port (NOT by default); Vantron | Public www.vantrontech.com...
  • Page 47 6. Uncheck the box before the VLAN interface and check the box before the Ethernet Adapter interface; 7. Save and apply the settings, then wait for them to be applied; 8. When VantronOS returns to the Interface page, the Ethernet port has been modified to a LAN port; Vantron | Public www.vantrontech.com...

  • Page 48: Lan Port Back To Wan Port

    To revert the LAN port back to its original WAN port function after the modification, follow the steps below: 1. Connect the host computer to the 2.4GHz Wi-Fi of the device and log in to VantronOS; 2. Navigate to Network > Interfaces; Vantron | Public www.vantrontech.com...
  • Page 49 5) Click the Submit button to finish creation. 5. Click the Physical Settings tab and check the settings; 6. Click the Save & Apply button to allow the settings to apply and VantronOS will return to the Interface page later; Vantron | Public www.vantrontech.com...
  • Page 50 WAN port; 10. Connect the device to a router or switch through the Ethernet port; 13. Restart the WAN port and you will see the WAN port IP allocated by the router or switch. Vantron | Public www.vantrontech.com...

  • Page 51: Password Change

    You can change the system language by navigating to System > System > System Properties > Language and Style in VantronOS. Auto: System language based on the browser language (default) English: English interface Simplified Chinese: Simplified Chinese interface Vantron | Public www.vantrontech.com...

  • Page 52: Factory Reset The Device

    2. Navigate to System > Backup/Flash Firmware > Backup/Restore in VantronOS; 3. Click the Perform reset button in red; 4. Customized settings will be restored to default. You can find more in 3.8.5 about backing up the current configurations before device reset in VantronOS. Vantron | Public www.vantrontech.com...

  • Page 53: Chapter 3 Device Setup In Vantronos

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 3 DEVICE SETUP IN VANTRONOS Vantron | Public www.vantrontech.com...

  • Page 54: Introduction To Vantronos

    Introduction to VantronOS VantronOS is an intelligent operating system developed by Vantron team, facilitating the configuration and management of Vantron IoT communication devices. It is built upon the Linux system and optimized for embedded hardware. The operating system follows a...

  • Page 55: Status

    Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions Status This page provides the overall information of HAP101, including stable operation duration, number of devices connected to the device, default routing, hardware information, traffic statistics, etc.

  • Page 56: Route Management

    Route Management 3.3.1 Automatic network routing Automatic routing might be beneficial when HAP101 is running in the 2.4GHz Wi-Fi station mode or Wi-Fi HaLow station mode. It ensures that the device maintains Internet access when multiple links are available. It features automatic link detection, automatic route switching, and recovery.

  • Page 57: Static Routing

    2. Input the host IP address of the destination 3. Input the subnet mask of the destination (255.255.255.255 by default) Input the IPv4 gateway address as the exit interface/next hop Set the gateway metric (The smaller the number, the higher the priority) Vantron | Public www.vantrontech.com...
  • Page 58 EINVAL error. The destinations are any cast addresses assigned to this host. They are Anycast mainly equivalent to local with one difference that such addresses are invalid when used as the source address of any packet. Vantron | Public www.vantrontech.com...

  • Page 59: Network

    4. Edit the interface settings 5. Delete the interface 6. Instantaneous traffic of the interface 7. Add a new interface The interfaces may differ from what is shown above depending on the Internet connection of the device. Vantron | Public www.vantrontech.com...

  • Page 60: Lan

    4. The LAN port subnet mask In the Advanced Settings next to the general setup: Description of the numbered areas 1. MAC address cloning 2. Set the MTU (keep the default setting) 3. Set a gateway metric (keep the default setting) Vantron | Public www.vantrontech.com...
  • Page 61 • General DHCP server The DHCP service dynamically allocates IP addresses to devices connected to HAP101 via the LAN port (2.4GHz Wi-Fi AP/HaLow AP/VLAN gateway). If either 2.4GHz Wi-Fi AP or HaLow AP is bridged to the Ethernet WAN port, the DHCP service on the corresponding interface will be disabled.

  • Page 62: Wan

    3.4.1.2 WAN • General settings Clicking on the Edit button behind the WAN port will allow you to access the configurations of the WAN port, and General Setup is displayed by default. Vantron | Public www.vantrontech.com...

  • Page 63: Advanced Settings

    If this option is disabled, you will need to define a DNS server. 5. Set a gateway metric 6. MAC address cloning 7. Set the MTU Be sure to save the settings before you exit the page. Vantron | Public www.vantrontech.com...
  • Page 64 When ‘unspecify or create’ is selected, you can remove the interface from the associated firewall zone or create a new zone. Refer to 2.6.1 2.6.2 to change the Ethernet port of the device to a LAN port or revert it to a WAN port depending on your needs. Vantron | Public www.vantrontech.com...

  • Page 65: Wireless (Wifi)

    6. Authentication method for the connection 7. Wi-Fi password (no less than 8 characters) Clicking the refresh icon will display/hide the password 8. Country code (00 applies to all regions) 9. Wi-Fi frequency band (determined by the hardware) Vantron | Public www.vantrontech.com...

  • Page 66: Wi-Fi - Client Mode

    13. List of client devices currently connected to the 2.4GHz Wi-Fi of the device 3.4.2.2 Wi-Fi – Client Mode When HAP101 is set as a 2.4GHz Wi-Fi client, you can further configure the device here and connect it to an AP.

  • Page 67: Wi-Fi Halow

    Wi-Fi HaLow settings for HaLow AP, Station, and Mesh modes. After setting an HAP101 to the HaLow client mode, the LAN IP of the device will change to 172.18.3.1. Please make sure the host computer and HAP101 are connected to the same network and use the updated IP address for VantronOS login when needed.
  • Page 68 Packets have been captured. The system supports up to 10 minutes (600 seconds) for the packet- based data capturing. The capture stops after reaching this limit, even if it has not reached the preset packet counts. Vantron | Public www.vantrontech.com...
  • Page 69 In the following scenario, the capture targets at all interfaces for the http packets from ‘tcp port 80’ for 30 seconds. Clicking the link will download the result to the local directory and you can open it with wireshark. Vantron | Public www.vantrontech.com...

  • Page 70: Services - Dhcp Server

    World-leading provider of embedded/IoT products and solutions Services – DHCP Server The DHCP service dynamically allocates IP addresses to devices connected to HAP101 via the LAN port (2.4GHz Wi-Fi AP/HaLow AP/VLAN gateway). If either 2.4GHz Wi-Fi AP or HaLow AP is bridged to the Ethernet WAN port, the DHCP service on the corresponding interface will be disabled.

  • Page 71: Security - Acl

    Follow the steps below to create an ACL rule: 1. Select a whitelist or blacklist policy; 2. Control the access of HAP101 in a WAN network (“disable” indicates that the newly created rule will not be applied); 3. Control the access of HAP101 in a LAN network (“disable” indicates that the newly created rule will not be applied);...

  • Page 72: Whitelist Acl Rule

    If you have selected the whitelist policy, you need to configure the blacklist IP. Otherwise, the rule will not take effect. “Source IP” refers to the IP from which the access requirement is initiated towards HAP101 and “Destination IP” refers to the IP to which the access requirement is initiated from HAP101.
  • Page 73 2. Specify the IP that the device is not allowed to access; 3. Click Add to create the rule; Once the rule is created, you can delete it when it is not needed. 4. Navigate to Network > Diagnostics > Ping and Ping the destination IP. Vantron | Public www.vantrontech.com...

  • Page 74: Blacklist Acl Rule

    • A device in the same WAN network: 192.168.19.225 • Requirement: Only allow HAP101 to access a specified IP in the same WAN network. Network status before IP release: 4. Select the Blacklist policy; 5. Enable the “to WAN” rule;...
  • Page 75 2. Specify the IP that the device is allowed to access; 3. Click Add to create the rule; Once the rule is created, you can delete it when it is not needed. 4. Navigate to Network > Diagnostics > Ping and Ping the destination IP. Vantron | Public www.vantrontech.com...

  • Page 76: Advanced Features

    2. Click Upload to upload the file to the device (default path: /mnt/USER_SPACE/ipk/ upload/) 3. You can delete or install the file after the .ipk file is uploaded 4. You can also input a file path (in /mnt/USER_SPACE/ipk/upload/) to download a specific file to the local directory Vantron | Public www.vantrontech.com...

  • Page 77: Bluesphere

    Vantron IoT communication devices. By entering the customer ID copied from BlueSphere GWM, you can enroll HAP101 into BlueSphere GWM for remote control and view the device communication log directly in VantronOS.
  • Page 78 3) The device log will be automatically printed and you can click the link to download. 6. Wait for the UDMP Agent to download and install; The UDMP Agent is the application that allows HAP101 to interface with BlueSphere GWM.

  • Page 79: User Management

    3.9 User Management User management page displays the current user information and allows you to add new users or edit the existing users to assign different permissions to different roles. Key information of the current user: Vantron | Public www.vantrontech.com...
  • Page 80 To add a new user, click the Add New User button below the existing user. In the new page, you can create the user and enable certain features for the user. 1. Default password of the new user is “vantron”; 2. Input a username (no space allowed);...

  • Page 81: System

    5. NTP server candidates that can be used to synchronize the internal clock of the device with an accurate time source 6. Enable/Disable the NTP online time server HAP101 is used as an NTP server. For language settings, please refer to 2.8. Vantron | Public...

  • Page 82: Administration

    1. Make sure the Windows computer is on the same network as HAP101; 2. Navigate to System > Administration in VantronOS, and enable Dropbear; Depending on the connectivity of the host computer and HAP101, select a port to access (When “unspecified” is selected, SSH login is available through both ports);...
  • Page 83 22 (unless you’ve configured a different port); 6. Click OK to start the session; 7. Input the password (rootpassword) to log in. Example SSH login with the 2.4GHz WLAN IP of HAP101: Vantron | Public www.vantrontech.com...

  • Page 84: Log

    For the log-related settings, click the Basic Setting tab. Description of the numbered areas 1. Storage path of the system log 2. Buffer size allowed for storing the system log 3. Output level of the console log 4. Output level of the cron log Vantron | Public www.vantrontech.com...

  • Page 85: Terminal

    Step 1: Select enable from the drop-down list; Step 2: Save the change; Step 3: Click the link to open the web terminal. Login account: root Login password: rootpassword (invisible while typing) Vantron | Public www.vantrontech.com...

  • Page 86: Backup/Flash Firmware

    While the web portal may not show the completion of the firmware upgrade, you can monitor the LED indicators to track its progress. Once the upgrade is complete, the following indicators will turn solid green: the Wi-Fi HaLow indicator, the 2.4GHz Wi-Fi indicator, the power indicator, and the system indicator. Vantron | Public www.vantrontech.com...
  • Page 87 Description of the numbered areas 1. Input the configuration file or directory to be retained during the upgrade Click Submit to confirm the setting Open the list of configuration files kept during the upgrade Vantron | Public www.vantrontech.com...

  • Page 88: Reboot

    You will exit the web interface with a click on the Logout tab. If you need make changes to any of your settings, you can log in the web again with default account (root) and password (rootpassword). Make sure you have saved the changes before logout. Vantron | Public www.vantrontech.com...

  • Page 89: Chapter 4 Use Case

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 4 USE CASE Vantron | Public www.vantrontech.com...

  • Page 90: Application Topology

    1. Each HAP101 device operates in HaLow AP and 2.4GHz Wi-Fi AP modes, with default LAN IP set to 172.18.2.1; 2. When an HAP101 switches from HaLow AP mode to HaLow STA mode, its LAN IP will change to 172.18.3.1;...

  • Page 91: Wiring

    HAP101-AP to obtain an IP from the DHCP server. To retrieve this IP (depending on your needs): 1. Connect a PC (PC2 in the topology) to the 2.4GHz Wi-Fi of HAP101-AP using the WLAN SSID and WLAN password on the device label of HAP101-AP;...

  • Page 92: Setup Of Hap101-Sta

    2. Connect the host computer to the 2.4GHz Wi-Fi of HAP101-STA using the default SSID and password provided on the device label as shown below; 3. Use the default WLAN Login IP provided on the device label of HAP101-STA as the address for VantronOS login;...
  • Page 93 Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions 5. Navigate to Network > HaLow WIFI, and change the HaLow mode of HAP101-STA to Client; The LAN IP of the device will change to 172.18.3.1 when the HaLow mode switches to Client.

  • Page 94: Ghz Wi-Fi

    IP from the DHCP server (above screenshot for illustration only). The HaLow station interface is bridged with the ETH interface by default, and the device connected to HAP101-STA via Ethernet will obtain an IP from the DHCP server. 4.3.2 2.4GHz Wi-Fi 1.

  • Page 95: Viewing Camera Ips

    1. Connect HAP101-AP to the DHCP server via Ethernet; 2. Connect a PC (PC3 in the topology) to HAP101-STA via 2.4GHz Wi-Fi; 3. Log in to VantronOS of HAP101-STA using the WLAN IP (172.18.2.1 by default) and the provided username and password on the device label;...

  • Page 96: Chapter 5 Debugging The Device

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 5 DEBUGGING THE DEVICE Vantron | Public www.vantrontech.com...
  • Page 97 Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions In the event that you need to debug HAP101, please follow the steps below to set up the device. 1. Unscrew the upper cover of HAP101 from the bottom and remove it;...

  • Page 98: Chapter 6 Disposal And Product Warranty

    Vantron Embedded in your success, Embedded in your better life World-leading provider of embedded/IoT products and solutions CHAPTER 6 DISPOSAL AND PRODUCT WARRANTY Vantron | Public www.vantrontech.com...

  • Page 99: Disposal

    & electronic waste recycling/disposal center. Proper disposal of this sort of waste helps avoid harm and adverse effect upon surroundings and people’s health. Please contact local organizations or recycling/disposal center for more recycling/disposal methods of related products. Vantron | Public www.vantrontech.com...

  • Page 100: Warranty

    CUSTOMER’s location and no Product so inspected shall be returned to VANTRON unless the cause for the rejection or defect is determined to be the responsibility of VANTRON. VANTRON shall in turn provide the CUSTOMER turnaround shipment on defective Product within fourteen (14) working days upon its receipt at VANTRON.

  • Page 101: Appendix Regulatory Compliance Statement

    - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Vantron | Public www.vantrontech.com...
  • Page 102 La puissance de sortie rayonné de cet appareil est conforme aux limites de la ISDE Canada limites d’exposition aux fréquences radio. Cet appareil doit être utilisé avec une distance minimale de séparation de 20cm entre (8 pouces) l’appareil et le corps d’une personne. Vantron | Public www.vantrontech.com...
