Recording system
Tape speed
Fast winding time
Frequency response
Speaker
Power output
Input
Output
SPECIFICATIONS
4-track 2-channe{ monaural
(L channel for electronic index signals, R channel for sound signais)
4.8 cm/s (17/s in./s), 2.4 cm/s ("5/16 in./s)
Approx. 2 min. 20 sec. with Sony cassette DC-90
200
- 5,000 Hz (at 2.4 cm/s)
200-8,000 Hz (at 4.8 cm/s)
Approx. 5.7 cm (21/4 inches) dia.
350 mW (at 10% distortion)
TELEPHONE PICKUP (minijack)
Sensitivity 0.2 mV
Input impedance 10 kohms
EARPHONE (minijack)
for 8-300-ohm earphones
CONTROL UNIT connector
Power requirements
Power consumption
Dimensions
Weight
Supplied accessory
for HU-80 or FS-75
gv DC
DC IN 9 V jack accepts the supplied AC power adaptor for use on
120 V AC, 60 Hz (US, Canadian
model)
220 V AC, 50 Hz (AEP, E model)
240 V AC, 50 Hz (UK model)
14 W (US, Canadian
model) (with the supplied AC power adaptor)
13 W (AEP, UK, E model) (with the supplied AC power adaptor)
Approx. 200 x 70 x 245 mm (w/h/d) (77/s x 27/e x 93/, inches)
including projecting parts and controls
Approx. 1.2 kg (2 Ib 11 02)
AC power adaptor (1)
Design and specifications subject to change without notice.
MICROFILM
Model Name Using Similar Mechanism
BM-88
Tape Transport Mechanism Type
MB-88-59
SAFETY-RELATED
COMPONENT
WARNINGI!!
COMPONENTS
IDENTIFIED
BY MARK
A OR DOTTED
LINE WITH MARK
A ON THE SCHEMATIC
DIAGRAMS
AND
IN THE
PARTS
LIST
ARE
CRITICAL
TO SAFE
OPERATION.
REPLACE
THESE
COMPONENTS
WITH
SONY
PARTS
WHOSE
PART
NUMBERS
APPEAR
AS
SHOWN
IN THIS MANUAL
OR
IN SUPPLEMENTS
PUB-
LISHED
BY SONY.
ATTENTION
AU
COMPOSANT
AYANT
RAPPORT
A LA SECURITE!
LES COMPOSANTS IDENTIFIES PAR UNE MARQUE /\
SUR LES DIAGRAMMES SCHEMATIQUES ET LA LISTE
DES
PIECES SONT
CRITIQUES
POUR
LA SECURITE
DE FONCTIONNEMENT.
NE REMPLACER
CES COM.
POSANTS
QUE
PAR
DES PIECES SONY
DONT
LES
NUMEROS
SONT
DONNES
DANS
CE
MANUEL
OU
DANS LES SUPPLEMENTS PUBLIES PAR SONY.
DICTATOR
/ TRANSCRIBER
ONY.
US Model
Canadian Model
AEP Model
UK Model
E Model
