True Manufacturing Company TRM Owner's Manual

Retail merchandiser

Advertisement

Quick Links

TRUE
TRM2M
Be sure to read and fully understand
before installing, operating, maintaining or servicing
this appliance. Failure to do so can result in appliance
failure, property damage, serious injury or death.
Appliance failure, injury or property damage due to
improper installation is not covered by warranty.
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O'Fallon, Missouri 63366-4434
(636) 240-2400 • FAX (636)-272-2408
International FAX (636)272-7546 • (800)-325-6152
Parts Department (800)-424- TRUE
Parts Department FAX (636)-272-9471
North America – Canada
and Caribbean
Warranty Phone: +1 855 878 9277
Warranty Fax: +1 636 980 8510
Technical Phone: +1 855 372 1368
Warranty Email:
warrantyinquiries@truemfg.com
Technical Email:
service@truemfg.com
7:00 – 6:00 CST Monday – Friday.
8:00 – 12:00 Saturday.
TEC_TM_180 | REV. F | EN
MANUFACTURING CO., INC.
TRM3M
WARNING!
this document
Mexico
Phone: +52 555 804 6343/44
service-mexicocity@truemfg.com
9:00 am – 5:30 pm M–F
Latin America
Phone: +52 555 804 6343/44
servicelatam@truemfg.com
9:00 am – 5:30 pm M–F
RETAIL MERCHANDISER (TRM®)
TRUE tracks the history of your appliance
For easy reference, record your appliances full model name and
serial number below. This information is on your serial label.
Serial label location varies by appliance.
Model Name:
Serial Number:
INSTALLATION MANUAL
RETAIL MERCHANDISER (TRM
UK, Ireland, Middle East,
Africa and India
Phone: +44 (0) 800 783 2049
service-emea@truemfg.com
8:30 am – 5:00 pm M–F
12/12/2024
OWNER'S MANUAL
TRM4M
USER ACTION!
by its serial number.
Original Instructions
European Union and
Australia
Commonwealth of
Phone: +61 2 9618 9999
Independent States
service-aus@truemfg.com
Phone: +41 61 563 0705
8:30 am – 5:00 pm M–F
service-emea@truemfg.com
8:00 am – 5:00 pm M–F
®)
Page 1 of 48
842860-F

Advertisement
