LG 27BA75QB Owner's Manual

LG 27BA75QB Owner's Manual

Led lcd monitor
Hide thumbs Also See for 27BA75QB:

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and
retain it for future reference.
27BA75QB
27BA65QB
www.lg.com
Copyright © 2024 LG Electronics Inc. All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 27BA75QB and is the answer not in the manual?

Questions and answers

Related Manuals for LG 27BA75QB

Summary of Contents for LG 27BA75QB

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27BA75QB 27BA65QB www.lg.com Copyright © 2024 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 OPEN SOURCE SOFTWARE NOTICE The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered INFORMATION ..........

  • Page 3: Open Source Software Notice

    The power cord provided may differ depending upon the region. other relevant documents, please visit https://opensource.lge.com. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Supported Drivers and Software such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

  • Page 4: Product And Button Description

    Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. Basic Functions Press the joystick button once with your finger Power on to turn on the monitor.

  • Page 5: Moving And Lifting The Monitor

    Moving and Lifting the Monitor Installing on a Table • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or the wall to ensure sufficient ventilation.

  • Page 6: Adjusting The Stand Height

    Adjusting the Stand Height Adjusting the Angle Place the monitor mounted on the stand base in an upright position. Place the monitor mounted on the stand base in an upright position. Handle the monitor with both hands for safety. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°...

  • Page 7: Pivot Feature

    Pivot Feature Rotate the monitor 90° clockwise and -90° counter clockwise as shown in the figure. The pivot feature allows the monitor to rotate 90° clockwise and -90° counter clockwise. Raise the monitor to the maximum height. Adjust the angle of the monitor in the direction of the arrow as shown in the figure. Complete the installation by rotating the monitor 90°...
  • Page 8 WARNING NOTE • • Auto Pivot feature of the display is not supported. Take care when rotating the monitor if the cable is connected. • • To avoid injury when rotating the display, do not place your fingers between the display and the stand base. The screen can be rotated easily using the screenpivot shortcut key provided with your Windows operating system.

  • Page 9: Swivel Stand

    Swivel stand Using the cable holder • Image shown may differ from your Monitor set. Arrange the cables using the cable holder as shown in the illustration. Swivel 90 degrees and adjust the angle of the Monitor set to suit your view. Rotate Set(Pivot) and put connectors.

  • Page 10: Using The Kensington Lock

    Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NOTE at http://www.kensington.com.
  • Page 11 Wall Mount Plate Back of the Monitor NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. Wall Mount Plate •...

  • Page 12: Using The Monitor

    USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from actual product. NOTE Press the tact key button, go to Settings Input, and then select the input option. •...

  • Page 13: Connecting Lan

    Connecting LAN Connecting AV Devices (27BA75QB) LAN connection HDMI Connection Connect the router or switch to the monitor. HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE NOTE • • The LAN cable is sold separately.

  • Page 14: Usb Device Connection

    Connecting Peripherals USB Device connection The USB port on the product functions as a USB hub. Headphones Connection NOTE Connect peripherals to the monitor via the headphones port. • It is recommended you install all Windows Updates to keep your Windows up-to-date before connecting to the product for use.

  • Page 15: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu Press the joystick button on the right back of the monitor. Move the joystick up/down and left/right to set the options. Press the joystick button once more to exit the main menu.

  • Page 16: Main Menu Features

    Main Menu Features Main Menu Description Input Sets input mode. Power Off Turns off the monitor. Settings Configures the screen settings. Picture Mode Sets the picture mode. Exit Exits the main menu. Menu Settings To view the OSD menu, press the joystick button on the right back of the monitor and then enter the Settings. Move the joystick up/down and left/right to set the options.

  • Page 17: Quick Settings

    Quick Settings Settings > Quick Settings Description Brightness Adjusts the contrast and brightness of the screen. Contrast Adjusts the volume. Volume NOTE • You can adjust Mute / Unmute by pressing the button in the Volume menu. The user can adjust it to red, green, or blue by customization. Custom Sets the screen color to a reddish tone.

  • Page 18: Input List

    Input Settings > Input Description Input List Selects the input mode. When automatic input switch is set to On, display will automatically switch to new input when connected. Auto Input Switch Enables Auto Input Switch. Disables Auto Input Switch. Adjusts the aspect ratio of the screen. Aspect Ratio Full Wide Displays the video in widescreen, regardless of the video signal input.
  • Page 19 Picture [Picture Mode] on SDR (Non HDR) signal Settings > Picture Description Custom Allows the user to adjust each element. Vivid Heightens contrast, brightness and sharpness to display vivid images. HDR Effect Optimizes the screen for high dynamic range. Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu. Reader Optimizes the screen to improve the visual effects of a video.
  • Page 20 [Picture Mode] on HDR signal Settings > Picture Description Custom Allows the user to adjust each element. Vivid Optimized the screen for HDR vivid colors. Cinema Optimized the screen for HDR video. This HDR mode is optimized for FPS games. Picture Mode This HDR mode is optimized for RTS games.
  • Page 21 Settings > Picture Description Brightness Adjusts the contrast and brightness of the screen. Contrast Sharpness Adjusts the sharpness of the screen. High Optimizes the screen for crystal clear images. Best for high-definition video or games. Middle Optimizes the screen for comfortable viewing, with images at the middle level between the low and high modes. Best for UCC or SD videos. Optimizes the screen for smooth and natural images.
  • Page 22 Settings > Picture Description Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use Fast. When there is a lot of motion, it is recommended that you use Faster. Setting to Faster may cause image sticking.
  • Page 23 Settings > Picture Description Mode 1, Mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes. Gamma Mode 3 Mode 4 If you do not need to adjust the gamma settings, select Mode 4. Set your own color temperature.
  • Page 24 General Settings > General Description Language Sets the menu screen to the desired language. USB Selection Select the USB upstream cable connection port to use USB hub of the monitor. Conserve energy by using luminance compensation algorithm. High Saves energy using the high-efficiency SMART ENERGY SAVING feature. Saves energy using the low-efficiency SMART ENERGY SAVING feature.
  • Page 25 Settings > General Description Set DP OUT for Multi Stream Transport. Enables DP OUT(MST) function Disables DP OUT(MST) function. DP OUT NOTE • Make sure that the graphics card supports the MST function. • Mac OS does not support DP OUT. This feature lets you set the sound generated from Buzzer when your monitor powers on.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the No Signal message being displayed? This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check the cable and reconnect it. •...
  • Page 27 Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message? • Have you installed the display driver? Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.

  • Page 28: Product Specification

    PRODUCT SPECIFICATION Color Depth 8-bit color is supported. Max Resolution 2560 x 1440 @ 100 Hz Resolution Recommended Resolution 2560 x 1440 @ 60 Hz Power Sources Power Rating 100-240 V ~50/60 Hz 2.5A Temperature 0 °C to 40 °C Operating Conditions Humidity Less than 80 %...

  • Page 29: Factory Support Mode (Preset Mode, Pc)

    Factory Support Mode (Preset Mode, PC) HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 1920 x 1080 67.5 Recommended Timing 2560 x 1440 88.787 59.951...

  • Page 30: Hdmi Timing (Video)

    DP / USB-C Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 1920 x 1080 67.5 Recommended Timing - Input Compatibility Version : 1.2 2560 x 1440 88.787 59.951...
  • Page 31 ® This Product qualifies for ENERGY STAR The model and serial number of the product are located on the back and on one side of the product. Changing the factory default configuration and settings or enabling certain optional features Record them below in case you ever need service. and functionalities may increase energy consumption beyond the limits required for ENERGY ®...
