MANUAL
Airmix model X
Extension for semi-closed greenhouses
Version: 2024-07
Pagina 1 van 28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Airmix X and is the answer not in the manual?

Questions and answers

Summary of Contents for VAN DER ENDE Airmix X

  • Page 1 MANUAL Airmix model X Extension for semi-closed greenhouses Version: 2024-07 Pagina 1 van 28...
  • Page 2: Foreword

    The user instructions and operating instructions are combined in a single document. The manual was produced by the inventor, Van der Ende Group (hereafter referred to as VDEG). Each chapter is numbered and, where necessary, divided into sections. The table of contents on page 3 gives an overview of the chapters and sections, with references to the page numbers.
  • Page 3: Table Of Contents

    TABLE OF CONTENT Foreword ..........................2 Table of content ........................3 Identification ........................4 Global description ......................4 1.1.1 Description of the system and machine ..............4 1.1.2 Specifications ......................4 1.1.3 Schematic view of the total system ................. 5 Controls and manual adjustment ..................
  • Page 4: Identification

    IDENTIFICATION This chapter will describe the global information about the system. The target of this chapter is to give a description about the application areas for the model X and in short the global way of operating. 1.1 Global description The Airmix model X is an extension on top of the existing horticultural ventilator Airmix model G, aimed at directly sucking air from outside the greenhouse.
  • Page 5: Schematic View Of The Total System

    1.1.3 Schematic view of the total system Figure 1: Schematic view Airmix model X Description Lattice Opening valve towards space above screen Linear actuator Airmix model G incl. mounting profiles Window model X Fitting plate (size is project-based) Suction hood model X Extension (size is project-based) Table 2: Parts overview Airmix model X Page 5 of 28...
  • Page 6: Controls And Manual Adjustment

    1.2 Controls and manual adjustment The model X has no internal control but is connected to the climate computer. Everything about the model X is controlled automatically and no form of manual control/control is required nor possible. The linear drive has the option of unlocking the drive by pressing a push button. Note!: This push button may only be used during the installation of the model X when there is no voltage and external steering signal is present on the installation.
  • Page 7: Relevant Directives

    1.8 Relevant directives The model X complies with the provisions of the following directives: • Machinery Directive 2006/42/EC • Low Voltage Directive 2006/95/EC • EMC Directive 2004/108/EC The model X is classified as a Class I device according to the Low Voltage Directive. 1.9 Residual risks It is expected that the user/operator adheres to all the above articles, in situations which are not described, the manufacturer/supplier must be informed at all times.
  • Page 8: Description

    DESCRIPTION 2.1 Function The function of the Airmix model X is to ventilate and dehumidify with the screen closed. The model X sucks air from the space above the screen or directly from outside and blows it into the cultivation area below the screen.
  • Page 9: Safety Instructions

    SAFETY INSTRUCTIONS This describes the safety instructions that must be followed when assembling the Airmix model X. − Always make sure that the plug of the fan is unplugged when working on the Airmix! This prevents accidental and/or unintentional starting of the fan. −...
  • Page 10: Installation

    INSTALLATION In this chapter is described how the model X must be installed. Before starting work on the installation, the entire manual must be read. 4.1 Mounting package contents Below is the list of what you need for one Airmix model X. This only contains the parts for the suction hood with the driveline.
  • Page 11: Installation Requirements

    4.2 Installation requirements − Choose a suitable place; Observe the installation drawing supplied by VDEG and/or your installer. Make sure there are no objects in the way; Make sure that no objects can get in front of the inlets and outlets of the Airmix; Make sure that people cannot reach the fan or drives without recourses (such as stairs);...
  • Page 12: Installation Of The Suction Hood To The Window

    4.4.1 Installation of the suction hood to the window The steps described in this chapter must be followed to mount the suction hood to the window. The following tools are minimally required for this; Quantity Description Open-ended wrench 13 mm Table 8: Required tools for installation to the roof plate This step must be performed by at least 2 people.
  • Page 13 Figure 2: Airmix model X installation to the roof Page 13 of 28...
  • Page 14: Installation And Adjusting The Driveline

    4.4.2 Installation and adjusting the driveline The following tools and parts are required for mounting and adjusting the window drive system and the flap to the space above the screen. Quantity Description Open-ended wrench 8 mm Open-ended wrench 10 mm Open-ended wrench 13 mm Hex key 4 mm Hex key 2.5 mm...
  • Page 15 Follow the steps below to adjust the drive system. Ensure that the motor handle (28) is connected to the linear actuator (29) Loosen the clamping part (27) of the motor handle (28) so it is no longer clamped (Not loosened completely!) by loosening bolts (16) and (20). Put the linear actuator (29) in its highest position by pressing the unlocking button on the linear actuator and make sure the window is closed.
  • Page 16 Figure 3: Installation and adjusting of the driveline Page 16 of 28...
  • Page 17: Installation Of The Extension Between Suction Hood And Airmix Model G

    4.4.3 Installation of the extension between suction hood and Airmix model G The connection between the Airmix model G and the suction duct is realized by the extension duct. At the bottom, the extension tube is undersized compared to the Airmix housing. The height depends on the ridge height of the greenhouse in which the Airmix model X is mounted.
  • Page 18 Figure 4: Installing the Airmix model G and the extension to the suction hood Page 18 of 28...
  • Page 19: Operation/Using For The First Time

    OPERATION/USING FOR THE FIRST TIME Operating the Airmix model X means that the fan, linear actuator and valve position indicator must be connected. The connection diagram for the fan is described and shown in the installation manual for the Airmix model G. The linear actuator and valve position indicator are shown below. 5.1 Lineair actuator The linear actuator (Figure 5) for the window drive is controlled via the climate computer with a 3-point control.
  • Page 20: Maintenance

    MAINTENANCE When servicing the Airmix, the fan must be unplugged and the drive disconnected to prevent unexpected and unwanted starting of the fan and window/valve drive. 6.1 Control and maintenance Make sure that there is no voltage on the system and that it is protected against re- activation before carrying out any maintenance work For the maintenance of the entire unit, the maintenance work of the Airmix model G must also be carried out.
  • Page 21: Declaration Of Conformity

    DECLARATION OF CONFORMITY EC Declaration of Conformity (In accordance with Annex IIA of the Machinery Directive 2006/42/EC) Van der Ende Pompen Aartsdijkweg 23 2676 LE Maasdijk The Netherlands Declare, under our sole responsibility, that the following machine; Airmix model X To which this declaration related is in conformity with the following directives;...
  • Page 22: Attachments

    ATTACHMENTS − CE declaration lineair gear rack drive − CE declaration Fan Page 22 of 28...
  • Page 23: Ce Declaration Lineair Gear Rack Drive

    CE declaration lineair gear rack drive CE declaration Fan Page 23 of 28...
  • Page 24 Page 24 of 28...
  • Page 25: Notes

    NOTES The information in this manual is provided to the best of our knowledge and ability, and no rights may be derived from this information. It is subject to printing and typesetting errors and changes in technology and working methods. Any liability for consequential damage is excluded.
  • Page 26 Page 26 of 28...
  • Page 27 Page 27 of 28...
  • Page 28 Aartsdijkweg 23, 2676 LE Maasdijk, The Netherlands +31 174 51 50 50 · info@vanderendegroup.com · www.vanderendegroup.com Page 28 of 28...
