  • Page 1 EN User Manual | Washing Machine EW8F169SAU...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...

  • Page 4: Safety Instructions

    • The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering. • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

  • Page 5: Water Connection

    2.4 Use • Always use a correctly installed shockproof socket. • Make sure that the parameters on the WARNING! rating plate are compatible with the Risk of injury, electric shock, fire, burns electrical ratings of the mains power or damage to the appliance. supply.

  • Page 6: Product Description

    • The SensiCare System detects the delicate fragrance exclusively developed laundry load size defining the programme by ELECTROLUX to add a pleasant duration in 30 seconds. The washing programme is tailored to the laundry load feeling of "just-washed" garment to the and the type of fabric without consuming removing odours and wrinkles action.

  • Page 7: Appliance Overview

    Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at electro‐...

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /65.8 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture ensured IPX4 by the protective cover, except where the low voltage equipment has no protection against moisture...

  • Page 9: Information For Installation

    WARNING! It is possible to see water flowing Do not put cardboard, wood or equivalent from the drain hose. This is because materials below the appliance feet to the washing machine has been adjust the level. tested at the factory. The inlet hose 4.
  • Page 10 WARNING! The inlet water shall not exceed 25 °C. Water drainage 3/4” The drain hose should stay at a height of no less than 60 cm and not more than 100 cm. You can extend the drain hose to 3/4” maximum 400 cm.

  • Page 11: Accessories

    6. ACCESSORIES 6.1 Available in www.electrolux.com/shop or from authorised dealer Only appropriate accessories approved by ELECTROLUX ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated. 6.2 Fixing plate kit If you install the appliance in a wooden floor, secure the appliance in the fixing plate.

  • Page 12: Pedestal With The Drawer

    6.4 Pedestal with the drawer WARNING! To raise your appliance and make loading Do not put the tumble dryer under the and unloading laundry easier. The drawer washing machine. Verify the compatible can be used for laundry storage e.g.: towels, stacking kit by checking the depth of your cleaning products and more.
  • Page 13 The options are not selectable with all washing programmes. Check the compatibility between options and washing programmes in the "AutoDose and options compatibility with programmes" paragraph in the "Programmes" chapter. An option can exclude another one, in this case the appliance doesn't allow you to set the incompatible options together. Make sure the screen and touch buttons are always clean and dry.
  • Page 14 When you select a washing programme, the appliance automatically proposes a default temperature. Touch this button repeatedly until the desired temperature value appears on the Температура display. touch button When the display shows the indicators , the appliance does not heat the water. It provides information about the setting programme.
  • Page 15 This option adds a steam phase followed by a short anti-crease phase at the end of the washing programme. The steam phase reduces fabric creasing and facilitates the fabric ironing. The indicator flashes on the display during steam phase. This option can increase the programme duration. +Пара...
  • Page 16 Touch this button to add the intensive phase to a programme. The corresponding indicator above the touch button illuminates. By pressing this button the indicator appears close to detergent symbol, and the appliance will automatically dose an extra amount of detergent when automatic de‐ tergent tank is enabled.
  • Page 17 This appliance is provided with different acoustic signals, that operate when: • You activate the appliance (special short tune). • You deactivate the appliance (special short tune). • You touch the buttons (click sound). • You make a wrong selection (3 short sounds). •...
  • Page 18 Door locked indicator. Delay start indicator. The digital indicator can show: • Programme duration: e. g. • Delay time: e. g. • Cycle end: • Warning code: e.g. • Error indicator: • Other setting messages. • When working with the APP: (access point), (update).

  • Page 19: Before First Use

    Touch Регулювання часу button to reduce The Регулювання часу is available only with the programme duration according to your the programmes in the table. needs. The display shows the new Регулювання часу with steam programme duration and a number of dashes programmes will decrease accordingly: When setting a steam programme, this button...
  • Page 20 AutoDose liquid detergent tank. AutoDose AutoDose fabric softener tank. Manual The appliance is pre-set by the factory to suit most users habits. Once started the programme, the appliance will automatically release the right amount of detergent and softener according to the real fabric load, if AutoDose is activated and the indicators and/or...
  • Page 21 fabric softener tank: the optimal If necessary, please contact your local configuration to meet majority of use water authority to check the water condition. The appliance will use these hardness in your area. settings to calculate the precise dosage 2. Identify the customized detergent for each wash based on load size.
  • Page 22 Levels Water hardness range °f 1) °d 2) °e 3) mmol/l Hard >25 >14 >17 >2.5 >250 French degrees German degrees English degrees Factory setting, able to satisfy most of the use conditions. 9.4 AutoDose configuration mode Enter the AutoDose configuration mode before proceeding with any programme setting.
  • Page 23 5. Lift down the AutoDose cover lid. 2. Lift up the AutoDose cover lid. 6. Gently close the detergent dispenser, till 3. Gently pour only liquid detergent in the click engagement. AutoDose detergent tank . Fill up to the maximum indicated level 9.6 AutoDose low level indication 4.
  • Page 24 If tank is not refilled, once a programme has started, the indicator will stop blinking and stay steadily lit. Once the programme is finished, it will start blinking again. Unless AutoDose is turned OFF, if a compartment has reached low level, the set dosage for that compartment will be shown by the display for a few seconds each time 9.8 Deactivating the AutoDose...
  • Page 25 2. Put the powder detergent in the Manual filling the liquid detergent compartment . When using liquid 1. Insert the container for liquid detergent. detergent, refer to "Manual filling the liquid detergent". 2. Pour the liquid detergent in the compartment 3.

  • Page 26: Programmes

    A sensor in the drawer detects if the drawer is open (or not properly closed) while the programme is running. In such case, the appliance will immediately be paused. If you press the Старт/Пауза button, an error sound is generated and everything in the display will turn off except the AutoDose indicators remain lit for a few seconds.
  • Page 27 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 800 rpm 2.0 kg Delicate fabrics such as acrylics, viscose and mixed fab‐ (1200- 400 rics requiring gentler washing. Normally and lightly soiled Тонкі...
  • Page 28 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 800 rpm 3.0 kg Single synthetic blanket, padded clothes, duvets, down (800 - 400 jackets and similar items. Пухові...
  • Page 29 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1200 rpm 1.5 kg Machine washable wool, hand washable wool and other (1200 - 400 fabrics with «hand washing» care symbol Вовна/Шовк...
  • Page 30 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ AutoDose Fabric Softener Others ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Віджим ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ No Spin ■ ■...

  • Page 31: Wi-Fi - Connectivity Setup

    10.3 Woolmark Wool Care - Green The wool wash cycle of this machine has been approved by The Woolmark Company for the washing of wool gar‐ ments labelled as «hand wash» provided that the prod‐ ucts are washed according to the instructions on the gar‐ ment label and those issued by the manufacturer of this washing machine.
  • Page 32 4. Start the application. Select the country and language and login with Your email As long as the appliance is activated, it and password. If you do not have an will keep trying to connect with saved account, create a new one following the credentials until the Wi-Fi is deactivated instructions in the App.

  • Page 33: Remote Start

    To remove the Remote Start, tap on the 11.3 Remote Start Remote start button and confirm by The Remote Start enables you to start a cycle pressing the Старт/Пауза button. in remote control. The Remote Control activates The reset position deactivates the automatically when you press the Старт/ Remote Start.

  • Page 34: Loading The Laundry

    12.4 Setting a programme 3. Press the Увімкн./Вимкн. button for a few seconds to activate the appliance. A short tune sounds. If you wish to change the automatic 12.2 Loading the laundry detergent or fabric softener dosage, enter 1. Open the appliance door. the AutoDose configuration mode before 2.

  • Page 35: Starting A Programme With The Delay Start

    12.7 The SensiCare System load detection The drain pump can operate shortly before the appliance fills water. The programme duration in the display is 12.6 Starting a programme with the referred to a medium/high load. delay start 1. Touch the Відкладений cтарт button After touching the Старт/Пауза...

  • Page 36: Interrupting A Programme And Changing The Options

    2. Wait for 1 second. The display shows The SensiCare detection is carried out Now, you can set a new washing programme. with complete washing programmes only and if the programme duration has not 12.10 Opening the door - Adding been reduced by means of the garments Регулювання...

  • Page 37: Stand-By Function

    3. Make sure that the drum is empty. 4. Press the Увімкн./Вимкн. button for a few 4. Keep the door and the detergent seconds to deactivate the appliance. dispenser slightly ajar to prevent mildew 12.13 Stand-by function and odours. The Stand-by function automatically 12.12 Draining water out after end deactivates the appliance to reduce the of cycle...

  • Page 38: Stubborn Stains

    • Wash stubborn stains with a special Special stain removers are available. Use the detergent. special stain remover that is applicable to the • Be careful with curtains. Remove the type of stain and fabric. hooks and put the curtains in a washing Do not spray stain remover on garments near bag or pillowcase.

  • Page 39: Care And Cleaning

    • When using detergent tabs or pods, laundry can then be washed at a lower always put them inside the drum, not in temperature. the detergent dispenser and follow the • To use the correct quantity of detergent, manufacturer's recommendations . refer to the quantity suggested by the Insufficient detergent may cause: detergent producer and check the water...

  • Page 40: External Cleaning

    14.3 External cleaning fibers that fall off the clothes to be drained out with the water. Regularly examine the seal. Clean the appliance with mild soap and warm Coins, buttons, other small items can be water only. Fully dry all the surfaces. Do not recovered at the end of the cycle.
  • Page 41 3. Run a Бавовна programme with the highest temperature. 4. Add a manually small quantity of powder detergent or a specific product into the empty drum, in order to rinse out any left residues. Occasionally, at the end of a cycle the display may show the icon : this is a recommendation to perform the “drum...
  • Page 42 4. To remove any detergent residue or if you 7. Make sure that all detergent residue is place a wrong additives in the tanks, removed from the conveyor. Use only soft empty the drawer in a basin or in suitable damp clothes.

  • Page 43: Cleaning The Drain Pump

    b. Place the bottom cover and press till "click" sound. c. Place the top cover on the tanks compartment and press till "click" sound. d. Replace components on manual compartment. 11. Insert the detergent dispenser into the guide rails and gently close it till "click" sound.
  • Page 44 WARNING! • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot. Wait until the water cools down Proceed as follows to clean the pump: 1. Open the pump cover. 5.

  • Page 45: Cleaning The Inlet Hose And The Valve Filter

    14.10 Cleaning the inlet hose and the valve filter 11. Put the filter back into the special guides by turning it clockwise. Make sure that you tighten the filter correctly to prevent leakages. 12. Close the pump cover. When you drain the water with the emergency drain procedure, you must activate the drain system again: a.

  • Page 46: Frost Precautions

    2. Start the programme to drain the water. 14.12 Frost precautions If the appliance is installed in an area where the temperature can reach values around 0° C or drop below, remove the remaining water from the inlet hose and the drain pump. 1.
  • Page 47 With some problems, the display shows an alarm code and the Старт/ Пауза button may flash continuously: If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Старт/Пауза button until the indicator stops flashing (see the picture below).
  • Page 48 : Frequency of power supply is out of range. : Supply voltage is too high. : Supply voltage is too low. If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the washing machine check the table below for possible solutions.
  • Page 49 Problem Possible solution • Check the wireless signal. • Make sure that the wireless connection is on. Refer to paragraph "Configuring the washing machine wireless connection" in "Wi-Fi - Connectivity setup" chapter. The display does not show the wireless indicator •...

  • Page 50: Emergency Door Opening

    Problem Possible solution • Reduce the quantity of detergent. • When using AutoDose tanks, verify the pre-set detergent/fabric softener dos‐ Too much foam in the drum during the washing cycle. age. Refer to "Basic setting" paragraph in "The AutoDose Technology" chap‐ ter.

  • Page 51: Consumption Values

    16. CONSUMPTION VALUES Stated values are obtained in laboratory conditions with relevant standards. Different causes can change the data: the quantity and type of laundry and ambient temperature. Water pressure, the supply voltage and the temperature of inlet water may also affect the washing programme duration.

  • Page 52: Quick Guide

    Power consumption in networked standby Time to networked standby (min.) The information given in the chart above is compliant with the EU Commission regulation 1015/2010 implement‐ ing directive 2009/125/EC and EU commission regulation No. 1275/2008. 17. QUICK GUIDE 17.1 Daily use Connect the mains plug to the mains socket.

  • Page 53: Cleaning The Drain Pump Filter

    17.2 Cleaning the drain pump filter 180˚ Clean the filter regularly and, especially, if the alarm code appears on the display. 17.3 Programmes Programmes Load Product description 9.0 kg White cotton and coloured cotton. Бавовна White cotton and coloured cotton. Standard programmes for 9.0 kg the Energy Label consumption values.

  • Page 54: Environmental Concerns

    Programmes Load Product description 4.0 kg Denim clothing. Денім Coloured cottons and synthetics. Special programme for colour 5.0 kg protection at low temperature. Ультра прання 1.5 kg Machine washable wool, hand washable wool and delicates. Вовна/Шовк Washing programme. Washing programme and water repellent phase. 18.
  • Page 56 The software in this product contains components that are based on free and open source software. Electrolux gratefully acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://electrolux.opensoftwarerepository.com (folder NIUS)
