SERIES 3

User Guide

Table of Contents

Need help?

Do you have a question about the 3 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Flite 3 Series

Page 1 SERIES 3 User Guide...
Page 3 Find Freedom. Take Flite.
Page 4 FLITESCOOTER YOU AGREE THAT YOU DO SO AT YOUR OWN RISK. CAUTION: THIS PRODUCT HAS BEEN KNOWN TO DRAMATICALLY IMPROVE YOUR LIFE AND HAPPINESS LEVELS. For the latest version Watch our video Authorised Flite and translations of this tutorials at Service, Resellers guide visit and Fliteschools fliteboard.com/locations...
Page 5 Flitescooter User Guide...
Page 6: Safety And Disclaimer
All safety and disclaimer Flitescooter is for operation by information is subject to change at one person only. It is not designed the sole discretion of Flite. for passengers or towing. Please For up-to-date product information check your local regulations for visit fliteboard.com/support...
Page 7: Propulsion System
Propulsion system Learning to Flitescooter The Flitescooter propulsion system We recommend learning to includes a powerful jet. Flitescooter with an instructor at an authorised Fliteschool. Fliteschool KEEP BODY, FINGERS AND TOES locations can be found at AWAY FROM FLITESCOOTER’S fliteboard.com/locations IMPELLER.
Page 8 How to Flitescooter video Before attempting to Flitescooter for the first time, read this User Guide and pay 3. Avoid contact with the wings and Flite Jet special attention to the warnings and COVER disclaimers. Most injuries can be avoided by using proper technique when learning.
Page 9 Wireless safety key Model: WSK1 Battery: CR2032 coin battery, 220mAh, 3.0V Operating temperature range: -20 to 60 �C / -4 to 140 �F FCC warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 10 DO NOT CHARGE OR USE A DAMAGED FLITECELL. IF YOUR water resistant marine battery. If the FLITECELL IS COMPROMISED, Flitecell is damaged (for example CONTACT FLITE OR AN during transportation or handling) AUTHORISED SERVICE PARTNER the seal may become compromised. FOR FURTHER ASSISTANCE.
Page 11: Warranty
Flitecell. Refer to the included MSDS regarding Only an Authorised Service shipping your Flitecell by sea. Partner or Flite HQ can carry out the mandatory initial service, any ongoing yearly / 100 hrs service, warranty repairs and non-warranty repairs.
Page 12: What's In The Box
Cruiser 1800 wing and Flite 500 stabiliser wing. Cruiser 1800 wing comes with a cover, Tef-Gel, Hex Key M6 and associated bolts and Fuselage cover. Flite 500 stabiliser comes with a cover and the required shims can be found in the accessories pouch.
Page 13 Box 2 Flitecell Note: please place this FLITECELL TI logo above on the image replacing old text Within the included padded Flitecell bag you will find either Flitecell Explore or Flitecell Sport, depending on your choice. Flitecell Flitecell Flitecell Sport travel bag Explore + spacer...
Page 14 Box 4 Flitescooter eFoil Within the included travel case you will find the eFoil system. eFoil travel bag eFoil System Flite Jet Prop guard removal tool kit eFoil system 60cm / 24" Fuselage tail + O-Ring Ring Nut tool Shoulder strap...
Page 15 Tef-Gel + Brush Mast Flange Seal + spare FAST FASTENERS REQUIRED FASTENERS REQUIRED M6 x 35 M6 x 35 Flite Controller Flite Controller Stabiliser wing shims USB wall charger 6 x styles (0–5) and charging cable FASTENERS REQUIRED M6 x 35...
Page 16: Getting Started
User Guide prior to assembly, setup or use. FLITESCOOTER IS INTENDED FOR USE WITH THE SUPPLIED FLITE JET, EFOIL AND WINGS ONLY. FLITESCOOTER IS INTENDED FOR USE WITH THE SERIES 2.2 AND LATER FLITE CONTROLLER ONLY.
Page 17 Controller. Attach the magnetic charging plug, ensuring the charging pins are connected. Plug in the USB Wall Charger and turn on. When the Flite Controller is charging correctly, the screen will show a charging message. Be careful not to disconnect the magnetic charging plug whilst charging.
Page 18 CHARGE NEAR FLAMMABLES OR EXPLOSIVES. DO NOT DISASSEMBLE THE CHARGER: THERE IS A DANGER OF HIGH VOLTAGE IN THE CHARGER CASE. FLITE DOES NOT BEAR ANY RESPONSIBILITY FOR INCORRECT USE OF THE CHARGER. USERS MUST OPERATE THE CHARGER ACCORDING TO THE USER GUIDE.
Page 19 Place the supplied magnet on the Flitecell for 5 - 10 seconds, as shown by arrow, to activate charging. If the magnet has been misplaced, you can use the base of Flite Controller to initiate charging.
Page 20 Flitescooter assembly Fitting the Flitescooter bladder to the core requires proper technique as the fitment between the two are tight for maximum strength. We recommend doing this process with two people, at least the first few times. Place the rigid core (Flitebox cavity side up) on a flat, smooth surface to avoid scratching the carbon finish on the core.
Page 21 Flitescooter assembly Inflating Flitescooter Twist the valve cap anti-clockwise to remove. To inflate, push the central valve down. Twist anti-clockwise to release. The valve will pop up. This ensures the bladder will not deflate when you remove the hose after inflation. In ating Flitescooter In ating Flitescooter Connect pump hose to valve and inflate bladder to 15 –...
Page 22 Connect the eFoil to Flitescooter Place the inflated Flitescooter upside down on a clear surface. Locate the Flitebox cavity on the bottom of the board and ensure the 4 retaining screws are removed. Check to ensure the orange o-ring is inserted, properly seated in the Flitebox cavity o-ring groove, clean and free of sand, grit or water.
Page 23 Connect the eFoil to the Flitescooter. Check the fuselage thread is clean and free of sand, grit or water. Check the Flite Jet thread is clean and free of sand, grit or water. Wipe clean if necessary. Apply a small amount of Tef-Gel to the thread of Flite Jet.
Page 24 place. Connect the fuselage tail Place the board upside down with the eFoil connected. Take the Insert the handlebars into the handlebar cavity. Turn the fuselage tail from the travel bag, add a light cover of Tef-Gel to the handlebar tail connection and install the tail into the fuselage.
Page 25 Connect the stabiliser wing Take the Flite 500 stabiliser from the travel bag and remove the wing cover. Make sure to use the provided Flite 500 shims. Take the correct stabiliser wing shim and fit between the stabiliser wing and the fuselage tail.
Page 26 Connect Flitecell to Flitescooter With the eFoil, fuselage tail and wings attached, it’s time to carefully turn your board over so it stands on BOTH the front wing and nose of the board. Twist the lid latches and open the board lid. DO NOT OPEN LID WHILST IN THE WATER UNDER ANY CIRCUMSTANCES.
Page 27 Download Flite App and update Flite App is available to download in the Apple App Store and Google Play Store . We recommend using ™ ™ Flite App to ensure your board and Flite Controller always have the latest software to deliver the best performance.
Page 28 Flite Controller overview — (Minus) button LCD display screen + (Plus) button Magnetic charge connection point Throttle trigger Mode button Pairing point and Flitecell switching magnet Wrist strap Handlebars overview Flite Controller cradle Thumb throttle Latch for Flite Controller...
Page 29 Turn on Flite Controller by holding down the + button AND Mode (bottom) button together for 3 seconds. After a 3 second press of both buttons, the Flite logo will appear with the software version number, and the Controller will move to the home screen with lock icon.
Page 30 CELLULAR NETWORK. DON’T USE THE PHONE FOR ANYTHING ELSE SUCH AS CALLS, TEXTS, OR OTHER APPS. MAKE SURE THE FLITESCOOTER LID REMAINS CLOSED DURING THE UPDATE PROCESS. ENSURE FLITE CONTROLLER IS TURNED OFF AS THE APP CAN ONLY CONNECT TO ONE DEVICE AT A TIME.
Page 31 Select ‘Flite Controller’ from the ’Devices’ list. When selected and connected, the current state of charge will be displayed. You will now be able to see the software version of the Flite Controller and perform any updates here. WHEN NEW SOFTWARE UPDATES ARE AVAILABLE, YOU’LL SEE AN ORANGE UPDATE ICON.
Page 32 Fasten the latches once paired successfully. Troubleshooting: If the lights are not solid blue, or the battery icon on your Flite Controller is crossed out, this indicates that the Flitecell has not paired, and the process needs to be repeated from Step 1.
Page 33 Alert (high temp, tilt, Red flashing overcurrent, system error) Blue flashing Armed Blue chasing Motor running Orange flashing Disconnected Flitecell / Controller Searching for new pair Orange chasing Flitecell / Controller Purple solid Flite App connected Purple chasing Flite App data transfer...
Page 34 Flite Controller screen guide Motor locked Motor armed Ready to arm. Motor unlocked with 5 seconds Flitecell 100% charged to squeeze the throttle trigger. Gear set to 1 Flitecell charge 50% Jet propulsion selected Current Speed / Gear Distance Speed 1.3km/h Travelled 6.4kms...
Page 35 Flite Controller displays LOOKING FOR NEW PAIR. Pairing required Battery not paired Flite Controller is not paired. Repeat pairing process Hold plus for 7 seconds (see page 32). until Flite Controller displays LOOKING FOR NEW PAIR.
Page 36 Flite Controller screen guide Charge remaining Flite Controller charging Flitecell 98% Flite Controller currently Flite Controller 66% at 10% state of charge. 50% Flitecell warning Flitescooter tilted Flitecell has 50% (or less) Flitescooter is disabled remaining charge. due to the tilt angle.
Page 37 50% each ride. conserve charge. Settings Flitescooter settings can be updated on the Flite App or the Flite Controller. To change settings on the Flite Controller, hold the Mode button until the settings screen is displayed.
Page 38 SEE PAGE 32 FOR PAIRING FLITE CONTROLLER THE SEAL IS A CRITICAL COMPONENT. IF DAMAGED CONTACT YOUR FLITE AUTHORISED SERVICE PARTNER FOR A REPLACEMENT PART. NEVER RIDE THE BOARD WITH A DAMAGED SEAL. THE FLITECELL AND CABLES ARE WATER RESISTANT; HOWEVER, ALWAYS KEEP FLITECELL, CABLES AND BOARD CAVITY DRY.
Page 39 From there, you can flip your Flitescooter and insert the handlebars. Ensure the eFoil is paired to Flite Controller before going in the water. Locate the handlebar cap and remove by gently pulling up.
Page 40 — Draw Fly Zones on the app to help avoid shallow water — Speed limiter which can be changed in the app or Flite Controller — Wireless safety key to cut off power when you are not on the board Select a suitable riding location A location with a minimum 1 metre / 3.3 feet depth is essential.
Page 41: Arming The Motor
Press and release the minus button. Press the thumb throttle within the 5 second countdown window to activate Flite Jet. Always verify the eFoil is clear and in a safe location before activating the motor. IMPORTANT: NEVER RUN THE MOTOR OUT OF WATER FOR MORE THAN 3 SECONDS, AS DOING SO CAN OVERHEAT AND DAMAGE THE SHAFT AND SEALS.
Page 42 Wireless safety key Press the face of the safety key to turn it on. You will now see 'Safety Key Detected' appear on Flite Controller. Set 4 points of contact with hands and feet Stand with feet shoulder You can simply step onto the width apart.
Page 43 Controller as it previously was showing all controls Press the thumb Within a few seconds, throttle all the way press and release the in and then release minus button on Flite it completely. Controller. Gradually throttle to plane Flitescootering for the rst time Press the thumb throttle...
Page 44 Speed variations The thrust from Flite Jet is part of the overall balance of the hydrofoil system. Make changes using the thumb throttle smoothly and slowly to maintain smooth and level flight.
Page 45 Flitescooter pro tips Fly as low as possible when learning and touch down often until confident. Once foiling, be aware of your weight position to help keep the board level. If you are taking off too quickly or aggressively, shift feet slightly further forward or change to a lower stabiliser shim number.
Page 46: Maintenance And Storage
Ensure that after each session, you visually inspect all elements of your Flitescooter including board, wings, mast, handlebars, Flitecell and Flite Controller for any damage or water ingress. Ensure that you perform the 6 Month Flitecell Checklist located on the Support page of the website.
Page 47 Flitescooter Post ride Open the board lid slowly, taking care to not let it fall on the nose of the board or the handlebars. After each ride, check to see if any water has leaked into the Flitecell cavity. If so, check the cause of the leak which may include: sand present on the sealing surface;...
Page 48 Ensure this area is dry before replacing the cover. Regular maintenance Pre and post season, the 3 torque screws on the underside of Flite Controller can be undone to release the trigger. This will allow you to thoroughly clean and inspect the trigger, spring and magnet. Regularly check that the Flite Controller trigger and handlebar throttle can move freely.
Page 49 PRESENT. INSPECT THE SIGHT GLASS AND CONFIRM THAT WATER IS NOT PRESENT BEFORE CHARGING AND USING A FLITECELL THAT HAS BEEN IMMERSED IN WATER. IF A FLITECELL HAS BEEN DROPPED OR DAMAGED, CONTACT FLITE IMMEDIATELY AND DO NOT USE THE FLITECELL. Regular maintenance Examine the charger regularly for damage to the cord, plug, enclosure or other parts.
Page 50: Troubleshooting
See Flite Controller charging instructions (page 17). Slow down or decrease power consumption to cool Flite Controller the Flitecell down. The Flite Controller will warn you shows a battery when the Flitecell temperature reaches 55°C and or temperature again at 60°C.
Page 51 Troubleshooting guide Flitescooter needs the wireless safety key to operate. Press the face of the wireless safety key to turn it on. If 'Safety Key Detected' does not appear on Flite Flite Controller Controller move away from other Flite Controllers shows 'Safety and wireless safety keys and try again.
Page 52: Technical Specifications
Technical specifications Load range RECOMMENDED WARRANTY LIMIT Flitescooter with Flite Jet 120kg / 265lbs 120kg / 265lbs Ride time 85kg rider Up to 1 hr 30 min (Flitecell Explore) Using a large wing at slow foiling speed, it’s possible to ride for over 2 hours.
Page 53 Flite eFoil system Input power 5,000 Watts Max output power at shaft 3,600 Watts Nominal voltage Maximum current 100A Motor type Brushless Motor speed 4500 rpm peak Protections Overheating, overcurrent Flite Jet diameter 90mm Flite Controller Communication type Bluetooth Speed control...
Page 54 Flitecell Explore Size 390mm x 305mm x 80mm (15” x 12” x 13”) Capacity 40Ah / 2016Wh Weight 14.5kg / 32lbs Protection IP67 Max charge voltage 58.8V Min voltage Nominal voltage 50.4V Rated continuous discharge current 100A Rated charge current Rated cycles >80% capacity 400 Cycles Temperature discharge limits...
Page 55 Flitecell Sport Size 305mm x 305mm x 80mm (12” x 12” x 13”) Capacity 29.4Ah / 1487Wh Weight 10.6kg / 23.4lbs Protection IP67 Max charge voltage 58.8V Min voltage Nominal voltage 50.4V Rated continuous discharge current 100A Rated charge current Rated cycles >80% capacity 400 Cycles Temperature discharge limits...
Page 56 (if applicable) Country & State Purchased from Date of purchase Board type & serial number eFoil 60cm Propulsion Flite Jet Flitecell type Explore Sport eFoil serial number Flitecell serial number(s) Flite Controller serial number(s) Flitecell Charger type & serial number...
Page 57: Maintenance Schedule
Inspected Replaced Mast Seals Fuselage Flitebox Flitebox Gore vent Cables Cables Handlebars Handlebars Flite Jet Flite Jet Flitecell health Anode Wireless safety key Safety key coin cell Flite Controller Flite Controller Comments eFoil Hours of use Date Name of Technician...
Page 58 Inspected Replaced Mast Seals Fuselage Flitebox Flitebox Gore vent Cables Cables Handlebars Handlebars Flite Jet Flite Jet Flitecell health Anode Wireless safety key Safety key coin cell Flite Controller Flite Controller Comments eFoil Hours of use Date Name of Technician...
Page 59 Inspected Replaced Mast Seals Fuselage Flitebox Flitebox Gore vent Cables Cables Handlebars Handlebars Flite Jet Flite Jet Flitecell health Anode Wireless safety key Safety key coin cell Flite Controller Flite Controller Comments eFoil Hours of use Date Name of Technician...
Page 60 Inspected Replaced Mast Seals Fuselage Flitebox Flitebox Gore vent Cables Cables Handlebars Handlebars Flite Jet Flite Jet Flitecell health Anode Wireless safety key Safety key coin cell Flite Controller Flite Controller Comments eFoil Hours of use Date Name of Technician...
Page 61 Inspected Replaced Mast Seals Fuselage Flitebox Flitebox Gore vent Cables Cables Handlebars Handlebars Flite Jet Flite Jet Flitecell health Anode Wireless safety key Safety key coin cell Flite Controller Flite Controller Comments eFoil Hours of use Date Name of Technician...
Page 62 Congratulations on becoming a Flitescooter owner. Now it's time to get out there and experience the freedom of Flite.
Page 63 FliteScooter_Series3_User Guide_200723_FA2...
