Avenir SOLO Installation Manual

Installation Guide
OVERVIEW
nstalling ingle eated ails is done in se arate stages. The n
during wall construction. The In-kit is 900mm in length and must be installed vertically on either the left or the
right side of the rails. It can be cut to length or into 2 pieces for split installation locations. After rendering / tiling /
painting, the heated rails are connected and installed.
To ensure safety for young children, the bottom rail is at least 600mm from the floor.
IN-WALL KIT
Assemble the In-Wall Kit as follows:
• Insert the aluminium threaded spigots into the spacing template (max 5 per In-Wall Kit)
• Feed red and black wires in parallel to all installed spigots
• Slide the aluminium C-channel over the spigots
• Install the assembled In-Wall Kit below the wall surface (wall lining or render).
• Install the transformer in a serviceable and ventilated location - usually this is in the ceiling space above.
• Connect 240V switched supply to the primary of the transformer
• Tile / render over such that at least 10mm of thread protrudes.
THIS PRODUCT IS DESIGNED TO HEAT OPTIMALLY WITH THE SUPPLIED 2 METER WIRE
It is not recommended to extend of shorten this wire - if you have to extend the wires then increase the wire gauge
SINGLE HEATED RAILS
Install the heated rails as follows:
• Using the supplied double sided tape, stick the drilling templates on the wall by locating the large hole over the protruding spigots
• Using the drilling template as a guide, drill holes in the wall surface (remove templates after)
sing the su lied lugs scre s and ashers t the all mounting com onents
• Screw wall mounting components to each spigots
Connect and install heated rails
• Using the supplied bullet crimps, connect the element wires to the red and black supply wire from the spigots
• Feed the looped end of the element wires into the rails
• Fit the rails onto the mounting components
• Test - heating takes 30 minutes to reach full temperature.
Note: Non thermostatically controlled heated towel rails only heat to optimal temperature when covered with a towel.
Single Heated Towel Rails
all it is rst installed belo the all surface
INSTALLATION GUIDE
VERSION: 2017.08
