Emerson Appleton Areamaster Connect AMLCL3 Instruction Sheet

LED Driver Replacement Instructions for Appleton™ Areamaster Connect™
FOR PROPER AND SAFE INSTALLATION THIS PRODUCT, PLEASE READ THE FOLLOWING INSTRUCTIONS AND RETAIN FOR
FUTURE USE.
Product Safety
Signal Words Defined
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a hazardous
situation which, if not avoided, could result in death or serious injury. CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury. NOTICE addresses practices not related to physical injury.
Safety Instructions
WARNING:
• Do not open or remove luminaire with the circuit energized.
NOTICE:
• For wiring details, refer to the product instruction manual.
What's Included
• One (1) LED driver
• One (1) Instruction Sheet
• One (1) Cable Tie
NOTE: Mounting hardware is not included with driver replacement kit
Removing LED Driver
1. If antenna is perpendicular to the driver housing, rotate it counterclockwise until it is parallel to the driver housing. IMPORTANT!
Antenna must not be rubbed or cleaned with solvents or a dry cloth. Instead, use a damp cloth to clean antenna and enclosure.
To access the luminaire's interior, loosen the four (4) ¼"-20 captive screws located on the driver housing. For AMLCL3 / IAML-
2.
CL3, see Fig. 1A & 1B. For AMLCL6 / AMLCL8 / IAMLCL6 / IAMLCL8, see Fig. 2A & 2B.
3. If required, use a 5" screwdriver to pry the wiring compartment cover open. See Fig. 3 & 4.
NOTE: Do not place driver housing over plastic housing and antenna. Sufficient clearance must be maintained to avoid damaging the
plastic housing and antenna.
4. Loosen the customer terminal block screws holding the white (N) and black (L) wire leads. Remove the wires. See Fig. 14.
5. Cut the cable tie inserted into the ferrite core and move the ferrite core assembly to access the screws below it.
6. For AMLCL3 / IAMLCL3, remove the #6-32 screw holding the ground cable lug as shown in Fig. 10. For AMLCL6 / AMLCL8 /
IAMLCL6 / IAMLCL8, remove the #6-32 screw holding the ground cable lug and Ferrite core assembly lug as shown in Fig. 11.
7. Loosen the screws inside the DC connector holding the red and blue wire leads. Remove the wires. See Fig. 5, 6, 7 & 8.
NOTE: Avoid touching the APG Com board with bare hands to prevent static electricity from compromising its functionality.
8. Loosen the screws on the APG com Board holding the Vaux 12V (Red/White), Dim "–" (Black), and Dim "+" (Purple) wire leads.
Remove the wires. See Fig. 12 & 13.
9. Remove the four (4) #8-32 SEMS screws holding down the LED driver assembly.
10. Remove the old LED driver assembly.
11. Save the screws for reinstallation; hardware is not included with driver replacement kit.
Appleton • 1.800.621.1506 • www.appletonelec.com
NCC002649A000 INSTRUCTION SHEET
NCC002649A000_Rev. 00_MY9178 _28/OCT/24 • Page 1 of 9
