User Manual
NMEA 2000 Run Indicator YDRI-04N
Firmware version
1.06
2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NMEA 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Yacht Devices NMEA 2000

Summary of Contents for Yacht Devices NMEA 2000

  • Page 1 User Manual NMEA 2000 Run Indicator YDRI-04N Firmware version 1.06 2024...
  • Page 2 © 2019–2024 Yacht Devices Ltd. Document YDRI-04-008. September 10, 2024 Web: http://www.yachtd.com/ NMEA 2000® is a registered trademark of the National Marine Electronics Association. SeaTalk NG is a registered trademark of Raymarine UK Limited. Garmin® is a registered trademark of Garmin Ltd.

  • Page 3: Table Of Contents

    Contents Introduction Warranty and Technical Support I. Product Specification II. Device Installation and Connection III. NMEA 2000 Digital Switching Support IV. Typical Use Cases for the Device V. Device Configuration and Settings VI. LED Signals VII. Firmware Updates VIII. Configuring CZone Appendix А.

  • Page 4: Introduction

    NMEA 2000 Digital Switching PGN 127501 «Binary Status Report» and the proprietary CZone extension. Device can be set up to turn NMEA 2000 Digital Switching equipment ON or OFF via standard PGNs 127502 «Switch Bank Control» (Yacht Devices products) and «Write Fields» command for 127501 «Binary Status Report»...

  • Page 5: Warranty And Technical Support

    Warranty and Technical Support The Device warranty is valid for two years from the date of purchase. If a Device was purchased in a retail store, the sale receipt may be requested when applying for a warranty claim. The Device warranty is terminated in case of violation of the instructions in this Manual, case integrity breach, or repair or modification of the Device without the manufacturer’s written permission.

  • Page 6: Product Specification

    I. Product Specification Figure 1. Drawing of YDRI-04 The Device is supplied with a NMEA 2000 Micro Male connector commonly used by a wide range of manufacturers. — 6 —...
  • Page 7 Operating temperature range −20..+50 °С Yacht Devices Ltd declares that this product is compliant with the essential requirements of EMC directive 2004/108/EC. Dispose of this product in compliance with the WEEE Directive or local regulations. Do not dispose of it with household or industrial waste.

  • Page 8: Device Installation And Connection

    Depending on the measurement results, the Device can switch ON or OFF any of the 28 «virtual» digital switches in its own bank (which can be read by other NMEA 2000 devices and software to check and display the status of the DC channel) and/or in other banks of Digital Switching devices, e.g. to trigger an audible alarm or switch other equipment ON or OFF (see Section III).
  • Page 9 switches fuses Figure 2. An example connection to DC current loads and voltage sources; note the common ground wire connected to GND input. You can program rules to manage other equipment using a set of command strings (see Section V). Each of the eight measurement channels may contain up to 8 rules, each rule can be modified and set to be active or inactive.
  • Page 10 The factory default rules set the Device to detect the flow of the current (above 0.2 A or below −0.2 A) in DC circuits connected to the Device's four input channels. The result is mapped to channels 1–4 of the Device’s own Digital Switching bank, which can be read by other devices, and visualized by channel Status LEDs (see Section V.1).
  • Page 11 After connecting the Device, close the NMEA 2000 connector lock to ensure its water resistance and reliability. After you power on your NMEA 2000 network, the Device Status LED gives a short green blink confirming a successful initialization. Three further green flashes indicate a successful connection to the NMEA 2000 network.
  • Page 12 Figure 3. NMEA devices list on a Raymarine Axiom MFD The Device information will appear in the list of NMEA 2000 devices (SeaTalk NG, SimNet, Furuno CAN), or in the common list of external devices on your MFD (see picture above). In most models, you can access this list via the «Diagnostics», «External Interfaces», or «External devices»...

  • Page 13: Nmea 2000 Digital Switching Support

    The Device also has its own internal «virtual» Digital Switching bank with 28 two-state channels. Their statuses are available to other NMEA 2000 devices, and may be used, for example, for indication purposes. Products described in this Section may become a valuable addition to your Digital Switching system.
  • Page 14 Figure 4. Web Gauges screenshot Device's voltage and current data can be displayed with circular gauges or text databars used for batteries (see Figure 4), or as states of Digital Switching channels (upper bar is green – ON, lower bar is red – OFF). If you have external access to your boat’s network, Web Gauges is an ideal solution for remote monitoring of your boat.
  • Page 15 The Device cannot be used to control CZone or EmpirBus modules; they use proprietary protocols and cannot be managed with Standard NMEA 2000 messages. However, the Device can be set up to use CZone protocol to visualize electrical loads on MFDs (see IV.1).

  • Page 16: Typical Use Cases For The Device

    IV. Typical Use Cases for the Device The following examples do not represent a comprehensive list of potential applications for the Device. They are intended to provide an overview of the Device's capabilities in a number of real-life scenarios. 1. Monitor DC circuits on modern MFDs Figure 5.
  • Page 17 For compatibility with legacy displays, the Device sends voltage and current data in PGN 127508 «Battery Status» which is supported by most NMEA 2000 displays on the market. In this case, loads are visualized as four «virtual» batteries. You can turn off the transmission of PGN 127508 in the Device’s settings.
  • Page 18 Figure 6. Basic Digital Switching system that provides alerts on fresh water leaks If the vessel has a NMEA 2000 Alarm Button (see Section III) configured for bank #0 (see Figure 6), the rule will trigger an audio alert. The Alarm Button allows uploading of user sounds or voice messages.
  • Page 19 On most boats, sailors need to save water and do not to spend much time in the shower. Shower pumps are usually automatically activated, and drain the water in a few minutes. If the pump is on for too long, it can mean that there is a problem with intake or drain pipes, and it can lead to a malfunction.
  • Page 20 Run Indicator can be used to get the status of the ON/OFF switches, such as jamb switches installed on boat’s doors or portholes. You will need to connect one of the switch poles to the fused power source positive rail, the second switch pole to one of the Device’s input terminals, and connect Device’s GND terminal to the power source ground rail to close the circuit.

  • Page 21: Device Configuration And Settings

    They can be set with a PC software and a corresponding NMEA 2000 gateway hardware. Some models of NMEA 2000 display devices may also allow editing of «Installation Description» data fields. Please refer to your software or chart plotter documentation for details.
  • Page 22 Figure 7 on the previous page shows the process of configuring the Device with free CAN Log Viewer software (to open this window, select the item «NMEA 2000 Devices» in the «View» menu, refresh the list of devices, select the Device and click «Properties» button). You can download this free program (runs on Microsoft Windows, Mac OS X and Linux) at http://www.yachtd.com/downloads/, Yacht Devices...
  • Page 23 Table 1 continued YD:PGN <pgn> [OFF | 0 | YD:PGN 126993 60000 Sets the transmission interval for PGNs: 100..60000] YD:PGN 127501 10000 126993, 127501, 127506, 127508 and 127751 YD:PGN 127506 1500 (see Appendix B). Values from 100 to 60 YD:PGN 127508 1500 000 ms (1 minute) are allowed.
  • Page 24 YD:DOWNLOAD YD:DOWNLOAD Asks MFD to re-send CZone configuration stored on the MFD. Use if you got CZone «Configuration Conflict» error: first, de- configure CZone on all Yacht Devices' CZone-capable units YD:CZONE AUTO command, then issue command YD:DOWNLOAD. Observe CZone MFD uploads configuration in response.
  • Page 25 1. Setting channel rules YD:RULE command sets rules to turn Digital Switching channels ON and OFF. Each of the four Device input channels has two measurement channels: for current (A, B, C, D) and for voltage (VA, VB, VC, VD), see Figure 2.
  • Page 26 Comparison Direction Absolute Value or Negative Sign (optional) Reference Value Extended Mode Parameters YD:RULE A 1 ON 0 1 >~0.50 3600.00 INTERVAL 6 Value (2..255) Trigger Mode ID (COUNT or INTERVAL) Time Period (0..36000.00 s) Condition settings (see above) DS Channel Number (1..28) Switch Bank Number (0..252)
  • Page 27 The Device does not measure negative voltage values. Therefore, the absolute value sign (~) is ignored in any conditions related to voltage measurement (in rules for channels VA..VD). In extended mode, two additional keywords with a numeric value are used: •...
  • Page 28 Table 2. Default rules for Device’s channels Device input Measurement Default rules channel channel YD:RULE A 1 ON 1 1 >~0.20 0.10 YD:RULE A 2 OFF 1 1 <~0.20 0.10 YD:RULE B 1 ON 1 2 >~0.20 0.10 YD:RULE B 2 OFF 1 2 <~0.20 0.10 YD:RULE C 1 ON 1 3 >~0.20 0.10 YD:RULE C 2 OFF 1 3 <~0.20 0.10 YD:RULE D 1 ON 1 4 >~0.20 0.10...
  • Page 29 Select a single measurement channel (A..D or VA..VD), or all channels (ALL), then specify RESET parameter to reset all rules to factory defaults, or CLEAR to delete all rules. In the second case, the status LED of the channel will always be unlit (see Section VI). 2.
  • Page 30 Extended Mode Parameters YD:ON A 0 1 5 3 180 COUNT 4 Value (2..255) COUNT or INTERVAL Time Period (0..36000.00 s) Switch OFF Threshold (0..10 A or 0..40 V) Switch ON Threshold (0..10 A or 0..40 V) DS Channel Number (1..28) Switch Bank Number (0..252)

  • Page 31: Led Signals

    10 seconds, it can be changed in the Device’s settings (refer to Section V). Status LED RED flash indicates an issue with NMEA 2000 communication. Refer to Appendix A. The Device's Channel LEDs indicate the state of the first four Digital Switching (DS) «virtual» switch statuses of the Device’s own DS bank.

  • Page 32: Firmware Updates

    Microsoft Windows, Mac OS X and Linux: http://www.yachtd.com/products/can_view.html The program must be connected to an NMEA 2000 network with a Yacht Devices USB Gateway YDNU-02, or a Wi-Fi Gateway YDWG-02, or an Ethernet Gateway YDEN-02, or a Wi-Fi Router YDNR-02.
  • Page 33 Figure 10. Firmware update with CAN Log Viewer — 33 —...

  • Page 34: Configuring Czone

    Back up your «known good configuration» ZCF files to avoid irrecoverable configuration loss! Our CAN Log Viewer software also can download the current configuration via NMEA 2000 and save it to ZCF file (menu Tools -> Download ZCF file). Double-check your new CZone configuration and make sure you got no DIP Switch conflict (each CZone device should have its unique DIP switch value), change DIP Switches on target devices via ZCF file or manually if necessary.

  • Page 35: Appendix А. Troubleshooting

    2. There is a NMEA 2000 network connection issue. Loose the plotter. No data comes connection in the data circuit. Treat the Device connector with a spray from the Device. for cleaning electrical contacts. Plug the Device into another NMEA 2000 connector. 1. Loose connection monitored circuit.

  • Page 36: Appendix B. Nmea 2000 Messages

    Appendix B. NMEA 2000 Messages Transmission Message name PGN # Receive Transmit Note interval, sec Acknowledge 59392 — ISO Request 59904 — ISO Transport Protocol (DT) 60160 — — ISO Transport Protocol (CM) 60416 — — ISO Address Claim 60928 —...
  • Page 37 Note 1: You can set the transmission interval for this message (see Section V). Note 2: Supports complex request messages by Battery Instance. Note 3: Disabled by default, set non-zero interval with YD:PGN to enable. Note 4: Transmitted only for channels with the type (YD:TYPE) other than UNKNOWN. —...
  • Page 38 Appendix C. LEDs, Connectors and Terminals Figure 11. Diagram of the Run Indicator YDRI-04 — 38 —...
  • Page 39 NOTES...
