Summary of Contents for RecPro iRV29
- Page 1 USER MANUAL USB MEDIA PLAYER Please read the instruction carefully before operating the unit.
-
Page 2: Installation
Installation ATTENTIONS OF INSTALLATION 1.This player should be installed by professional technician. 2. please read the instruction and operation of equipment carefully before installing. 3. Make sure to connect other wires before power connection. 4. To avoid short circuit. Please make sure all the exposed wire are insulating. 5. -
Page 3: Wiring Connection
Installation WIRING CONNECTION 1. This player can only be used by the 12V DC cathode grounding electrical system. 2. Don’t connect to the battery until the player is absolutely well connected. 3. Please make sure to connect the yellow wire to the positive of the battery (+). 4. -
Page 4: Operation
OPERATION iRV29 LOCATION OF KEYS 1.POWER/SOURCE. 2. FAST FORWARD. 3. PLAY/PAUSE. 4. FAST REWIND. 5. USB PORT. 6. DIGITAL SIGNAL INPUT. ZONE 2+ ON/OFF. 8. ROTARY VOL. ZONE 1+ ON/OFF. 10. LCD DISPLAY. -
Page 5: Key Function
KEY FUNCTION KEYS RADIO ACTION Power on/change Power on/change Power on/change Power on/change Short source source source source power off power off power off power off Long seek up next file next file Short turn up reset（5 seconds） Long seek down previous file previous file Short... -
Page 6: Radio Operation
OPERATION Turn on/off the unit Press /SRC button to turn on the unit. When the unit is on. Press and hold it for 2 seconds to turn off the unit. Sound and setting adjustment Press and hold VOL(rotary) knob into the setting menu as below: BASS-TRE-BAL –EQ-LOUD-BEEP-DX-STEREO-BT In each item rotating the VOL knob to set them. - Page 7 OPERATION the first file of this folder. Search song For panel operation: Press VOL knob. It shows NUM 0000. Rotating VOL to select the numbers then press VOL to play. For remote controller operation: Press AMS button. It shows NUM 0000. Directly enter the number then press SEL button to play.
-
Page 8: Remote Control
REMOTE CONTROL REMOTE CONTROL REMOTE CONTROL KEY FUNCTIONS KEYS ACTION RADIO Short power on/off power on/off power on/off power on/off Long mute on/off for mute on/off for mute on/off for mute on/off for Short zone 1 zone 1 zone 1 zone 1 Long ZONE1... - Page 9 REMOTE CONTROL BASS-TRE-BAL-EQ- BASS-TRE-BAL- BASS-TRE-BAL- BASS-TRE-BAL-EQ LOUD-BEEP-DX-ST- EQ-LOUD-BEEP-DX Short EQ-LOUD-BEEP-DX- -LOUD-BEEP-DX-ST- BT(off/link)/ -ST-BT(off/link ST-BT(off/link) BT(off/link) Search: Enter Long CLASS-ROCK-POP-F CLASS-ROCK-POP-F CLASS-ROCK-POP- CLASS-ROCK-POP- Short LAT- LAT-OFF FLAT-OFF FLAT-OFF Long LOUD ON/OFF LOUD ON/OFF LOUD ON/OFF LOUD ON/OFF Show ID3 Short clock info/Show play clock clock...
-
Page 10: Troubleshooting
TROUBLE SHOOTING GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 123(W) x 116(D) x 65(H) Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power : 4 x 40 watts Current Drain : 10 Ampere (max.) RADIO...
