H158B Remote Control Manual
Remote control key diagram
Remote Control Function Description
Key label
1
Back motor extended, release to stop
2
Foot motor extended, release to stop
3
Back motor retracts, release to stop
4
Foot motor retracts, release to stop
One-button reset, all motors retracted to the minimum stroke
5
position, power-on reset
6
Back motor, foot motor out at the same time, release to stop
7
Back motor, foot motor retract at the same time, release stop.
8
Press the flashlight to turn on, release the flashlight to turn off
The motor runs to TV position with one click .
Reuse function: Press and hold TV for about 3 seconds, the backlight
9
will flash and the buzzer will sound, and the current motor position
will be recorded to TV
The motor runs to SNORE position with one click .
Reuse function: Press and hold SNORE for about 3 seconds, the
10
backlight will flash and the buzzer will sound, and the current motor
position will be recorded to SNORE
11
The motor runs to ZG position with one click .
Feature
1
Advertisement
Related Manuals for Richmat H158B
Summary of Contents for Richmat H158B
- Page 1 H158B Remote Control Manual Remote control key diagram Remote Control Function Description Key label Feature Back motor extended, release to stop Foot motor extended, release to stop Back motor retracts, release to stop Foot motor retracts, release to stop One-button reset, all motors retracted to the minimum stroke...
- Page 2 Reuse function: Press and hold ZG for about 3 seconds, the backlight will flash and the buzzer will sound, and the current motor position will be recorded to ZG Coding method: [Remote control foot rise + Back descent+ control box code key] Buzzer sounds, indicating successful code * The control box has a reset function for the code key * The control box is powered on and reset, all motors are reset at the same time, and the reset...
- Page 3 H158 Remote Control Manual Remote control key diagram Remote Control Function Description Key label Feature Back motor extended, release to stop Foot motor extended, release to stop Back motor retracts, release to stop Foot motor retracts, release to stop The motor runs to M1 position with one click . Reuse function: Press and hold M1 for about 3 seconds, the backlight will flash and the buzzer will sound, and the current motor position will be recorded to M1...
- Page 4 Coding method: [Remote control head rise + foot rise + control box code key] Buzzer sounds, indicating successful code * The control box has a reset function for the code key * The control box is powered on and reset, all motors are reset at the same time, and the reset process cannot be interrupted by any key Caution: This device complies with Part 15 of the FCC Rules.
- Page 5 H159 Remote Control Manual Remote control key diagram Remote Control Function Description Key label Feature Underbed light on/off (default: 15 minutes off) The motor runs to M1 position with one click . Reuse function: Press and hold M1 for about 3 seconds, the backlight will flash and the buzzer will sound, and the current motor position will be recorded to The motor runs to SNORE position with one click .
- Page 6 One-button reset, all motors retracted to the minimum stroke position, power-on reset Once the external drag rises, release the TILT to stop the third way Drag outward and lower, release and stop (TILT) the third way External drag two rises, release and stop (LUMBAR) the fourth way External drag two descent, release and stop (LUMBAR) the fourth way Head massager enhancement: Press the button, if the head massager is not activated, start the head massager and enter the "CONSTANT"...
- Page 7 Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
