The RMS Controller
A quick look at the basic functions of the
Remote Manual Slider Controller by
1
2
covered in this manual
rms-12 v2.07, rms-8 v3.01, rms-4 v1.48 and later
CHANNELS
3
4
5
6
7
8
01
PAGE
Controller Layout
Recall a Preset
Adjust Light Levels
Program Presets
Enable/Disable Programming
9
10
11
12
PRESETS
1
3
5
7
OFF
55
FADE
2
4
6
8
ON
Advertisement
Table of Contents
Summary of Contents for Marlin RMS
- Page 1 A quick look at the basic functions of the Remote Manual Slider Controller by CHANNELS PRESETS PAGE FADE covered in this manual Controller Layout Recall a Preset Adjust Light Levels Program Presets Enable/Disable Programming rms-12 v2.07, rms-8 v3.01, rms-4 v1.48 and later...
- Page 2 For the RMS 8, channels 1 - 8 comprise the first page; and with 8 pages, this means that the RMS 8 can control up to 64 channels. For the RMS 12, channels 1 - 12 comprise the first page; and with 8 pages, this means that the RMS 12 can control up to 96 channels.
- Page 3 Blinking LED is 5% increment, steady LED is 10% to page #8. 96 channels can be controlled for all 8 pages; only on the RMS 8 and RMS 12 2. Channel Adjust Buttons Raise and lower the light levels of each channel by 6.
- Page 4 1234 1. External Inputs 3. Physical Address Inputs for motion sensors and door switches Identifies the RMS on the lighting system network 2. Configuration Dip Switches 4. RS-485 Communication bus connector Each switch enables/disables the following Connects to the dimmer panel and other lighting...
-
Page 5: Recall A Preset
5a. adjust light levels Follow the procedure to manually adjust the brightness of each channel. 1. If using the RMS 8 or 12, press the PAGE button to select the desired page number (see figure 5b). 2. Press the channel adjust button... -
Page 6: Program A Preset
1. Press and hold the preset number you wish to set. Once the preset button’s LED begins to flash, you are in programming mode. (See figure 6a.) 2. Press the PAGE button (for RMS 8 and 12) to select the page number. The page window will display the selected page (See figure 6b). - Page 7 Disabling preset programming prevents users from modifying presets that have already been saved (see Program a Preset). Before proceeding, remove the RMS faceplate, unscrew the RMS from the wall, and unplug the green connector (See figure 7a). 1. Using a small screwdriver or pencil, flip switch #4 of the 4-pin configuration dip switch on the back of the RMS controller.
-
Page 8: Corporate Headquarters
Marlin Controls, Inc. Corporate Headquarters: 11011 Regency Crest Dr. Suite 200 Dallas, TX 75238 Mailing Address: P.O. Box 550457 Dallas, TX 75355 (800) 788-5750 (toll free) (214) 553-1011 (fax) www.marlincontrols.com sales@marlincontrols.com rms-12 v2.07, rms-8 v3.01, rms-4 v1.48 and later last edit 07/27/2016...
