- Page 1 Bluetooth® dongle Type VT-ZBT-1-1X Replaces: 12.19 Operating instructions English RE30581-B/07.2020 Mat.no. R901533383...
- Page 2 © This document, as well as the data, specifications and other information set forth in it, are the exclusive property of Bosch Rexroth AG. It may not be reproduced or given to third parties without its consent.
-
Page 3: Table Of Contents
Installation and setup of the app Operation Display elements Maintenance and repair 10.1 Cleaning and care 10.2 Spare parts 10.3 Repair Demounting and replacement Disposal 12.1 Environmental protection 12.2 Return to Bosch Rexroth AG 12.3 Packaging 12.4 Materials used RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG... - Page 4 4/28 Extension and modification Troubleshooting Technical data Annex 16.1 List of addresses Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020...
-
Page 5: About This Documentation
Document no. Document type Hydraulic valves for RE 07600-B Operating instructions industrial applications EU declaration of DCTC-31000- Certificate conformity for VT-ZBT-1-1X Radio Transmission DCTC-31000- Certificate Equipment Type Approval Certificate China Type Approval Certificate DCTC-31000- Certificate India VT-ZBT-1-1X RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG... -
Page 6: Representation Of Information
The hazard avoidance measures described must be observed. Safety instructions are structured as follows: SIGNAL WORD Type and source of danger! Consequences in case of non-compliance ▶ Hazard avoidance measures ▶ <Enumeration> Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... - Page 7 The following symbols indicate notices which are not safety-relevant but increase the comprehensibility of the documentation. Tabelle 3: Meaning of the symbols Symbol Meaning If this information is disregarded, the product cannot be used or operated in an optimum manner. RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG...
-
Page 8: Safety Instructions
Meaning Electrostatic discharge Federal Communications Commission Rich Site Summary Safety instructions About this chapter The product has been manufactured according to the generally accepted codes of practice. However, there is still a risk of personal Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 9: Intended Use
The product is an electronic component. The VT-ZBT-1-1X allows data to be exchanged with special Bluetooth ® - capable Bosch Rexroth hydraulic valves using radio wave technology. The user has to agree to the exchange of data. The product is intended exclusively for professional use and not for private usage. -
Page 10: Improper Use
• Insufficient cleanliness for storing and installation. • Incorrect installation. • Operation outside the permissible environmental conditions. Bosch Rexroth AG does not assume any liability for damage caused by improper use. The user assumes all risks involved with improper use. Qualification of personnel... -
Page 11: General Safety Instructions
• in particular, completely understanding the correlations regarding safety equipment and • knowledge of the function and structure of hydraulic components, Bosch Rexroth offers training courses that support your qualification in specific fields. An overview of the training contents can be found on the Internet at: http://www.boschrexroth.com... -
Page 12: Product-Specific Safety Instructions
Risk of burning! ▶ During operation, touch the valve and the VT-ZBT-1-1X only with heat-resistant gloves. Allow the valve and the VT-ZBT-1-1X to cool down to room temperature before touching it directly with your hands. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 13: Obligations Of The Machine End-User
The operation of installations, systems and machines basically requires the implementation of a holistic IT security concept which is state-of-the-art in terms of technology. Accordingly, Bosch Rexroth products and their properties must be considered as components of installations, systems and machines for their holistic IT security concept. -
Page 14: General Notes On Damage To Property And Damage To The Product
Check the scope of delivery for completeness. ▶ Check the scope of delivery for possible transport damage, see chapter 6 “Transport and storage”. In case of complaints, please contact Bosch Rexroth AG, see chapter 16.1 “List of addresses”. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 15: About This Product
Improper storage may damage the product. Storage Bluetooth ® dongles can be stored for up to 12 months under the following conditions: ▶ Do not store the VT-ZBT-1-1X outdoors but in a well ventilated room. RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG... -
Page 16: Mounting
The valve may only be connected and disconnected by or under the supervision of a skilled electrician. To comply with FCC RF exposure compliance requirements, the device must be installed to provide a separation distance of at least 20 cm from all persons. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... - Page 17 Remove the protective cover from the base and keep it safe for returns in case any repairs become necessary later. Check that the O-ring is properly installed on the dongle. Mount the VT-ZBT-1-1X, see Fig. 2. RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG...
-
Page 18: Commissioning
The display of your mobile device will show you all further steps that are required to connect the valve with your mobile device. More detailed information can be found directly in the app from Bosch Rexroth. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 19: Operation
• Blue Tabelle 6: Display elements Dongle state Diagnostic LED 0.5 s 0.5 s 0.5 s 0.5 s De-energized No error GREEN GREEN GREEN GREEN No Sync GREEN GREEN between dongle and valve (not connected) RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG... -
Page 20: Maintenance And Repair
VT-ZBT-1-1X. ▶ Never use solvents or aggressive cleaning agents. ▶ Clean the components exclusively with a paintbrush. Moreover, do not use water. ▶ Remove dust and dirt accumulations on the VT-ZBT-1-1X at regular intervals. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 21: Spare Parts
The VT-ZBT-1-1X may only be replaced as a complete unit. Unauthorized modifications to devices are not permitted for safety reasons! Repairs may only be carried out by Bosch Rexroth AG. For repairs send the device to the service address given in Chapter 16.1. -
Page 22: Disposal
Notes on the usage in China: Marking according to China RoHS 2: Date of production, see product (example FD: 07/2020) The table of substances contained in the product and restricted by China RoHS 2 can be found at: https://www.boschrexroth.com.cn/zh/cn/home_2/china_rohs2 Select the keyword “Electronics” in the table Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 23: Return To Bosch Rexroth Ag
Upon request, reusable systems can be used for regular deliveries. The material for disposable packaging is mostly cardboard. It can be recycled without any problems. For ecological reasons, disposable packaging should not be used for returning products to Bosch Rexroth. 12.4 Materials used Components from Bosch Rexroth do not contain any hazardous substances that could be released when used as intended. -
Page 24: Troubleshooting
Is the distance to the mobile Reduce the distance between the mobile device and the VT-ZBT-1-1X. device too long? Is the valve with VT-ZBT-1-1X Inspect the connection and the voltage mounted ready for operation? supply of the valve. Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... -
Page 25: Technical Data
2.360 GHz ... 2.500 GHz Output power +4 dBm System requirements Mobile device Android 6 (and higher) (tablet, smartphone) iOS 10 (and higher) Electrical data Supply voltage 3.3 VDC Maximum current 0.1 A (power supply from valve consumption electronics) RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG... -
Page 26: Annex
Headquarters Bosch Rexroth AG Zum Eisengiesser 1 97816 Lohr am Main Germany Phone +49 (0) 9352/40 30 20 my.support@boschrexroth.com The addresses of our sales and service network and sales www.boschrexroth.com organizations can be found at Bosch Rexroth AG, VT-ZBT-1-1X, RE30581-B/07.2020... - Page 27 Annex 27/28 RE30581-B/07.2020, VT-ZBT-1-1X, Bosch Rexroth AG...
- Page 28 Bosch Rexroth AG Zum Eisengiesser 1 97816 Lohr a. Main Germany Phone +49 (0) 9352/40 30 20 my.support@boschrexroth.com www.boschrexroth.com Subject to revision Printed in Germany RE30581-B/07.2020...
